Page 457 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-79 [QR (WITH EURO-OBD)] C D E F G H I J K L MA EC Basic InspectionEBS010LS 1. INSPECTION START 1. Check service records for any recent repairs that may indicate a related malfun

Page 458 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-80 [QR (WITH EURO-OBD)] TROUBLE DIAGNOSIS 3. CHECK TARGET IDLE SPEED With CONSULT-II 1. Run engine at about 2,000 rpm for about 2 minutes under no-load. 2. Rev engine (2,000 to 3,000 rpm) two or

Page 459 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-81 [QR (WITH EURO-OBD)] C D E F G H I J K L MA EC 6. PERFORM IDLE AIR VOLUME LEARNING Refer to EC-46, " Idle Air Volume Learning" . Is Idle Air Volume Learning carried out succe

Page 460 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-82 [QR (WITH EURO-OBD)] TROUBLE DIAGNOSIS 10. CHECK IGNITION TIMING 1. Run engine at idle. 2. Check ignition timing with a timing light. OK or NG OK >>INSPECTION END NG >> GO TO 11. 11 . PERFORM

Page 461 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-83 [QR (WITH EURO-OBD)] C D E F G H I J K L MA EC 14. CHECK TARGET IDLE SPEED AGAIN With CONSULT-II 1. Start engine and warm it up to normal operating temperature. 2. Read idle

Page 462 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-84 [QR (WITH EURO-OBD)] TROUBLE DIAGNOSIS 17. DETECT MALFUNCTIONING PART Check the following. Check camshaft position sensor (PHASE) and circuit. Refer to EC-254 . Check crankshaft position sen

Page 463 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual TROUBLE DIAGNOSIS EC-85 [QR (WITH EURO-OBD)] C D E F G H I J K L MA EC 1 - 6: The numbers refer to the order of inspection. (continued on next page)Throttle position sensor circuit 12 22222 2EC-168

Page 464 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-86 [QR (WITH EURO-OBD)] TROUBLE DIAGNOSIS SYSTEM — ENGINE MECHANICAL & OTHER SYMPTOM Reference page HARD/NO START/RESTART (EXCP. HA) ENGINE STALL HESITATION/SURGING/FLAT SPOT SPARK KNOCK/DETON
