Page 1505 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P1272 FUEL PUMP EC-1127 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC DTC P1272 FUEL PUMPPFP:16700 DescriptionEBS011DP When the fuel pressure in fuel rail increases to excessively high, fuel pr

Page 1506 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1128 [YD (WITH EURO-OBD)] DTC P1272 FUEL PUMP : Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.) On Board Diagnosis LogicEBS011DQ DTC Confirmation Procedur

Page 1507 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P1272 FUEL PUMP EC-1129 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC Wiring DiagramEBS012AJ TBWA0574E

Page 1508 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1130 [YD (WITH EURO-OBD)] DTC P1272 FUEL PUMP Diagnostic ProcedureEBS011DS 1. CHECK FUEL TRANSPORT PUMP OPERATION Perform Diagnostic Procedure for fuel transport pump. Refer to EC-1194 . OK or N

Page 1509 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P1272 FUEL PUMP EC-1131 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC 3. CHECK FUEL PUMP POWER SUPPLY CIRCUIT FOR OPEN AND SHORT 1. Turn ignition switch OFF. 2. Disconnect ECM harness connector

Page 1510 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1132 [YD (WITH EURO-OBD)] DTC P1272 FUEL PUMP 8. REPLACE FUEL PUMP 1. Replace fuel pump. 2. Perform Fuel Pump Learning Value Clearing. Refer to EC-890, " Fuel Pump Learning Value Clearing" . >>IN

Page 1511 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P1272 FUEL PUMP EC-1133 [YD (WITH EURO-OBD)] C D E F G H I J K L MA EC Removal and InstallationEBS011DT FUEL RAIL Refer to EM-157, "INJECTION TUBE AND FUEL INJECTOR" . FUEL PUMP Refer to EM-161,

Page 1512 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1134 [YD (WITH EURO-OBD)] DTC P1273 FUEL PUMP DTC P1273 FUEL PUMPPFP:16700 DescriptionEBS011DU To control the amount of the fuel inhalation of the fuel pump, a plunger is built into the fuel pump
