Page 305 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ENGINE OIL LU-7 [QR] C D E F G H I J K L MA LU ENGINE OILPFP:KLA92 InspectionEBS00KO3 ENGINE OIL LEVEL NOTE: Before starting engine, put vehicle horizontally and check the engine oil level. If engin

Page 306 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual LU-8 [QR] ENGINE OIL 3. Disconnect harness connector at oil pressure switch, and remove oil pressure switch using a deep socket (commercial service tool). 4. Install oil pressure gauge and hose (spe

Page 307 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual ENGINE OIL LU-9 [QR] C D E F G H I J K L MA LU 3. Loosen oil filler cap and then remove drain plug. 4. Drain engine oil. 5. Install drain plug with new washer. Refer to EM-25, " OIL PAN AND OIL STRA

Page 308 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual LU-10 [QR] OIL FILTER OIL FILTERPFP:15208 Removal and InstallationEBS011TI REMOVAL 1. Open oil filter installation/removal cover on RH undercover. 2. Using an oil filter wrench (special service tool

Page 309 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual OIL COOLER LU-11 [QR] C D E F G H I J K L MA LU OIL COOLERPFP:21305 Removal and InstallationEBS00KO8 WARNING: Be careful not to get burned when engine and engine oil may be hot. CAUTION: When remov

Page 310 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual LU-12 [QR] OIL COOLER 2. Start engine, and make sure there is no leaks of engine oil or engine coolant. 3. Stop engine and wait for 10 minutes. 4. Check the engine oil level and the engine coolant l

Page 311 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual OIL PUMP LU-13 [QR] C D E F G H I J K L MA LU OIL PUMPPFP:15010 Removal and InstallationEBS00KO6 REMOVAL Remove front cover. Refer to EM-44, "TIMING CHAIN" . NOTE: Oil pump is built into front cove

Page 312 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual LU-14 [QR] OIL PUMP INSPECTION AFTER DISASSEMBLY Clearance of Oil Pump Parts Measure the clearance with a feeler gauge. –Clearance between outer rotor and oil pump body (position 1) –Tip cleara
