Page 1753 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P0341 CMP SENSOR EC-1375 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC Component InspectionEBS0121Z CAMSHAFT POSITION SENSOR 1. Loosen the fixing bolt of the sensor. 2. Disconnect camshaft

Page 1754 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1376 [YD (WITHOUT EURO-OBD)] DTC P0563 BATTERY VOLTAGE DTC P0563 BATTERY VOLTAGEPFP:24410 On Board Diagnosis LogicEBS01221 The MI will not light up for this self-diagnosis. DTC Confirmation Proce

Page 1755 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P0563 BATTERY VOLTAGE EC-1377 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 3. CHECK JUMPER CABLES INSTALLATION Check that the jumper cables are connected in the correct sequence. OK or NG O

Page 1756 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1378 [YD (WITHOUT EURO-OBD)] DTC P0605 ECM DTC P0605 ECMPFP:23710 DescriptionEBS01224 The ECM consists of a microcomputer and connectors for signal input and output and for power supply. The ECM

Page 1757 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P0605 ECM EC-1379 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 2. REPLACE ECM 1. Replace ECM. 2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer t

Page 1758 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1380 [YD (WITHOUT EURO-OBD)] DTC P0606 ECM DTC P0606 ECMPFP:23710 DescriptionEBS01228 The ECM consists of a microcomputer and connectors for signal input and output and for power supply. The ECM

Page 1759 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual DTC P0606 ECM EC-1381 [YD (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC 2. REPLACE ECM 1. Replace ECM. 2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer t

Page 1760 of 4179

NISSAN X-TRAIL 2003 Service Repair Manual EC-1382 [YD (WITHOUT EURO-OBD)] DTC P0628, P0629 FUEL PUMP DTC P0628, P0629 FUEL PUMPPFP:16700 DescriptionEBS0122C To control the amount of the fuel inhalation of the fuel pump, a plunger is built i
