Page 2545 of 5598

INFINITI QX56 2011 Factory Service Manual
REFRIGERANT PRESSURE SENSOREC-521
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and refr

Page 2546 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-522
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
SNOW MODE SWITCH
SNOW MODE SWITCH
DescriptionINFOID:0000000006256403
The snow mode switch signal is sent to the combinat
ion meter from the snow mode switch.

EC-522
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
SNOW MODE SWITCH
SNOW MODE SWITCH
DescriptionINFOID:0000000006256403
The snow mode switch signal is sent to the combinat
ion meter from the snow mode switch. The combination
meter then sends the signal to the ECM via the CAN communication line.
The snow mode is used for driving or starting the vehicle on snowy roads or slippery areas. If the snow mode
is activated, the vehicle speed will not accelerate as quickly as normal to avoid vehicle slip. In other words,
ECM controls rapid engine torque change by controlling t he electric throttle control actuator operating speed.
Component Function CheckINFOID:0000000006256404
1.CHECK SNOW MODE SWITCH FUNCTION
1. Turn ignition switch ON.
2. Select “SNOW MODE SW” in “DATA MONITOR” mode with CONSULT-III.
3. Check “SNOW MODE SW” indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-522, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006256405
1.CHECK DTC WITH COMBINATION METER
Refer to MWI-30, "
CONSULT-III Function".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to MWI-57, "
Work flow".
2.CHECK SNOW MODE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect snow mode switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between snow mode switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
Fuse block harness connector M3
10 A fuse (No. 13)
Harness for open or short between snow mode switch and fuse.
>> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK SNOW MODE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
Monitor item Condition Indication
SNOW MODE SW Snow mode switch ON ON
OFF OFF
Snow mode switch
Ground Voltage
Connector Terminal
M54 12 Ground Battery voltage
Revision: 2010 May2011 QX56

Page 2547 of 5598

INFINITI QX56 2011 Factory Service Manual
SNOW MODE SWITCHEC-523
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2. Disconnect combination meter harness connector.
3. Check the continuity between snow mode switch
harness

Page 2548 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-524
< SYMPTOM DIAGNOSIS >[VK56VD]
ENGINE CONTROL SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
ENGINE CONTROL SYSTEM SYMPTOMS
Symptom TableINFOID:0000000006218028
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTO

Page 2549 of 5598

INFINITI QX56 2011 Factory Service Manual
ENGINE CONTROL SYSTEM SYMPTOMSEC-525
< SYMPTOM DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Mass air flow sensor circuit
1
12 2
222 2 EC-201
Engine coolant temperature sensor circuit
333
EC-2

Page 2550 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-526
< SYMPTOM DIAGNOSIS >[VK56VD]
ENGINE CONTROL SYSTEM SYMPTOMS
1 - 6: The numbers refer to the order of inspection.
(continued on next page)
SYSTEM — ENGINE MECHANICAL & OTHER
Manifold absolut

Page 2551 of 5598

INFINITI QX56 2011 Factory Service Manual
ENGINE CONTROL SYSTEM SYMPTOMSEC-527
< SYMPTOM DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Air Air duct
55555 5 EM-28
Air cleaner
EM-27
Air leakage from air duct
(Mass air flow sensor — el

Page 2552 of 5598

INFINITI QX56 2011 Factory Service Manual
E C -528
< SYMPTOM DIAGNOSIS >[VK56VD]
ENGINE CONTROL SYSTEM SYMPTOMS
1 - 6: The numbers refer to the order of inspection.Lubrica-
tion
Oil pan/Oil strainer/Oil pump/Oil
filter/Oil gallery/Oil coole
