Page 3185 of 5598
B257B, B257C AMBIENT SENSORHAC-79
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ambient sensor. Refer to HAC-147, "
Removal and Installation".
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12 −
15 (5) 12.73
− 10 (14) 9.92
− 5 (23) 7.80
0 (32) 6.19
5 (41) 4.95
10 (50) 3.99
15 (59) 3.24
20 (68) 2.65
25 (77) 2.19
30 (86) 1.81
35 (95) 1.51
40 (104) 1.27 45 (113) 1.07
Revision: 2010 May2011 QX56
Page 3186 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-80
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2581, B2582 INTAKE SENSOR
B2581, B2582 INTAKE SENSOR
DTC LogicINFOID:0000000006275915
DTC DETECTION LOGIC
NOTE:
If DTC is displayed al INFINITI QX56 2011 Factory Service Manual
HAC-80
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2581, B2582 INTAKE SENSOR
B2581, B2582 INTAKE SENSOR
DTC LogicINFOID:0000000006275915
DTC DETECTION LOGIC
NOTE:
If DTC is displayed al](/manual-img/42/57033/w960_57033-3185.png)
HAC-80
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2581, B2582 INTAKE SENSOR
B2581, B2582 INTAKE SENSOR
DTC LogicINFOID:0000000006275915
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
HAC-
72, "DTC Logic".
If DTC is displayed along with DTC U1010, fi rst perform the trouble diagnosis for DTC U1010. HAC-73,
"DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Check DTC.
Is DTC detected?
YES >> Refer to HAC-80, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006275916
1.CHECK INTAKE SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect intake sensor connector.
3. Turn ignition switch ON.
4. Check voltage between intake sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK INTAKE SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between intake sensor har ness connector and A/C auto amp. harness connector.
Is the inspection result normal?
DTC Items
(CONSULT-III screen terms) DTC detection condition Possible cause
B2581 INTAKE SENSOR The intake sensor recognition temperature is
too high.
Intake sensor
A/C auto amp.
Harness or connectors
(The sensor circuit is open or short-
ed.)
B2582
The intake sensor recognition temperature is
too low.
+
−Voltage
(Approx.)
Intake sensor
Connector Terminal M257 1 Ground 5 V
Intake sensor —Continuity
Connector Terminal
M257 2 Ground Existed
Revision: 2010 May2011 QX56
Page 3187 of 5598
![INFINITI QX56 2011 Factory Service Manual
B2581, B2582 INTAKE SENSORHAC-81
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Chec INFINITI QX56 2011 Factory Service Manual
B2581, B2582 INTAKE SENSORHAC-81
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Chec](/manual-img/42/57033/w960_57033-3186.png)
B2581, B2582 INTAKE SENSORHAC-81
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Check intake sensor. Refer to HAC-81, "
Component Inspection".
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Replace intake sensor. Refer to HAC-150, "
Removal and Installation".
4.CHECK INTAKE SENSOR POWER SUPPLY CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between intake sensor har ness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair harness or connector.
5.CHECK INTAKE SENSOR POWER SU PPLY CIRCUIT FOR GROUND SHORT
Check continuity between intake sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK INTAKE SENSOR POWER SU PPLY CIRCUIT FOR POWER SHORT
1. Turn ignition switch ON.
2. Check voltage between intake sensor harness connector and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Repair harness or connector.
Component InspectionINFOID:0000000006275917
1.CHECK INTAKE SENSOR
1. Turn ignition switch OFF.
2. Disconnect intake sensor connector.
3. Check resistance between intake sensor terminals.
Intake sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M257 1 M50 28 Existed
Intake sensor —Continuity
Connector Terminal
M257 1 Ground Not existed
+ −Vol tag e
(Approx.)
Intake sensor
Connector Terminal M257 1 Ground 0 V
Revision: 2010 May2011 QX56
Page 3188 of 5598
HAC-82
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2581, B2582 INTAKE SENSOR
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace intake sensor. Refer to
HAC-150, "
Removal and Installation".
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12 −
15 (5) 17.73
− 10 (14) 13.46
− 5 (23) 10.33
0 (32) 8.00
5 (41) 6.25
10 (50) 4.93
15 (59) 3.92
20 (68) 3.14
25 (77) 2.54
30 (86) 2.06
35 (95) 1.69
40 (104) 1.39 45 (113) 1.15
Revision: 2010 May2011 QX56
Page 3189 of 5598
![INFINITI QX56 2011 Factory Service Manual
B262A, B262B, B2657, B2658 EXHAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
HAC-83
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B262A, B262B, B2657, B2658 EXHAU INFINITI QX56 2011 Factory Service Manual
B262A, B262B, B2657, B2658 EXHAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
HAC-83
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B262A, B262B, B2657, B2658 EXHAU](/manual-img/42/57033/w960_57033-3188.png)
B262A, B262B, B2657, B2658 EXHAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
HAC-83
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B262A, B262B, B2657, B2658 EXHAU ST GAS/OUTSIDE ODOR DETECT-
ING SENSOR
DTC LogicINFOID:0000000006275918
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to HAC-
72, "DTC Logic".
If DTC is displayed along with DTC U1010, fi rst perform the trouble diagnosis for DTC U1010. HAC-73,
"DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Check DTC.
Is DTC detected?
YES >> Refer to HAC-83, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006275919
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 10A fuse [No.4, lo cated in fuse block (J/B)]
NOTE:
Refer to PG-140, "
Fuse, Connector and Terminal Arrangement".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK EXHAUST GAS / OUTSIDE ODOR DETECTING SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect exhaust gas / outside odor detecting sensor connector.
3. Turn ignition switch ON.
4. Check voltage between exhaust gas / outside odor detecting sensor harness and ground.
DTC Items
(CONSULT-III screen terms) DTC detection condition Possible cause
B262A GAS SENSOR Exhaust gas / outside odor detecting sensor
duty ratio 15% or less.
Exhaust gas / outside odor detect-
ing sensor
A/C auto amp.
Harness or connectors (The sensor circuit is open or short-
ed.)
B262B
Exhaust gas / outside odor detecting sensor
duty ratio 85% or more.
B2657 CAS SENSOR CIRCUIT Exhaust gas / outside odor detecting sensor
duty ratio 0%.
B2658 Exhaust gas / outside odor detecting sensor
duty ratio 100%.
+
−Vol tag e
(Approx.)
Exhaust gas / outside odor detect-
ing sensor
Connector Terminal E117 1 Ground Battery voltage
Revision: 2010 May2011 QX56
Page 3190 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-84
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B262A, B262B, B2657, B2658 EX
HAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harne INFINITI QX56 2011 Factory Service Manual
HAC-84
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B262A, B262B, B2657, B2658 EX
HAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harne](/manual-img/42/57033/w960_57033-3189.png)
HAC-84
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B262A, B262B, B2657, B2658 EX
HAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector between exhaust gas / outside odor detecting sensor and fuse block
(J/B).
3.CHECK EXHAUST GAS / OUTSIDE ODOR DETECTING SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between exhaust gas / outsi de odor detecting sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK EXHAUST GAS / OUTSIDE ODOR DETECTING SENSOR SIGNAL CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between exhaust gas / outside odor detecting sensor harness connector and ground.
Is the inspection result normal?
YES >> Replace exhaust gas / outside odor detecting sensor. Refer to HAC-151, "Removal and Installa-
tion".
NO >> GO TO 5.
5.CHECK EXHAUST GAS / OUTSIDE ODOR DETE CTING SENSOR SIGNAL CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp.connector.
3. Check continuity between exhaust gas / outside odor detecting sensor harness connector and A/C auto
amp. connector.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK EXHAUST GAS / OUTSIDE ODOR DETE CTING SENSOR SIGNAL CIRCUIT FOR GROUND
SHORT
Check continuity between exhaust gas / outside odor detecting sensor harness connector and ground.
Is the inspection result normal?
Exhaust gas / outside odor detect- ing sensor —Continuity
Connector Terminal
E117 2 Ground Existed
+
−Voltage
(Approx.)
Exhaust gas / outside odor detect-
ing sensor
Connector Terminal E117 3 Ground 5 V
Exhaust gas / outside odor detect- ing sensor A/C auto amp.
Continuity
Connector Terminal Connector Terminal
E117 3 M50 10 Existed
Exhaust gas / outside odor detect- ing sensor —Continuity
Connector Terminal
E117 3 Ground Not existed
Revision: 2010 May2011 QX56
Page 3191 of 5598
B262A, B262B, B2657, B2658 EXHAUST GAS/OUTSIDE ODOR DETECTING
SENSOR
HAC-85
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 7.
NO >> Repair harness or connector.
7.CHECK EXHAUST GAS / OUTSIDE ODOR DETE CTING SENSOR SIGNAL CIRCUIT FOR POWER
SHORT
Check voltage between exhaust gas / outside odor detecting sensor harness and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Repair harness or connector.
+
−Vol tag e
(Approx.)
Exhaust gas / outside odor detect-
ing sensor
Connector Terminal E117 3 Ground 0 V
Revision: 2010 May2011 QX56
Page 3192 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-86
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2630, B2631 SUNLOAD
SENSOR (DRIVER SIDE)
B2630, B2631 SUNLOAD SEN SOR (DRIVER SIDE)
DTC LogicINFOID:0000000006275920
DTC DETECTION LOGIC INFINITI QX56 2011 Factory Service Manual
HAC-86
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2630, B2631 SUNLOAD
SENSOR (DRIVER SIDE)
B2630, B2631 SUNLOAD SEN SOR (DRIVER SIDE)
DTC LogicINFOID:0000000006275920
DTC DETECTION LOGIC](/manual-img/42/57033/w960_57033-3191.png)
HAC-86
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2630, B2631 SUNLOAD
SENSOR (DRIVER SIDE)
B2630, B2631 SUNLOAD SEN SOR (DRIVER SIDE)
DTC LogicINFOID:0000000006275920
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to HAC-
72, "DTC Logic".
If DTC is displayed along with DTC U1010, fi rst perform the trouble diagnosis for DTC U1010. HAC-73,
"DTC Logic".
Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, use a lamp (60 W or more) that is pointed at the sunload sensor.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Check DTC.
Is DTC detected?
YES >> Refer to HAC-103, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006275921
1.CHECK SUNLOAD SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect sunload sensor connector.
3. Turn ignition switch ON.
4. Check voltage between sunload sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK SUNLOAD SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harne ss connector and A/C auto amp. harness connector.
DTCItems
(CONSULT-III screen terms) DTC detection condition Possible cause
B2630 SUNLOAD SENSOR Detected calorie at sunload sensor (driver side)
2832 W/m
2 (2436 kcal/m2·h) or more.
Sunload sensor
A/C auto amp.
Harness or connectors
[The sensor circui t (driver side) is
open or shorted.]
B2631
Detected calorie at sunload sensor (driver side)
64.7 W/m
2 (55.6 kcal/m2·h) or less.
+
−Voltage
(Approx.)
Sunload sensor
Connector Terminal M74 2 Ground 5 V
Sunload sensor —Continuity
Connector Terminal
M74 3 Ground Existed
Revision: 2010 May2011 QX56
