2011 INFINITI QX56 Factory Service Manual

instrument panel fuse box location inflation pressure coolant reservoir brakes winter tyres

Page 2361 of 5598

INFINITI QX56 2011 Factory Service Manual
P0452 EVAP CONTROL SYSTEM PRESSURE SENSOREC-337
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
8. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to
EC-337, "Diagnos

Page 2362 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-338
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0452 EVAP CONTROL S
YSTEM PRESSURE SENSOR
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair short to ground or short to power in harness or conne

EC-338
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0452 EVAP CONTROL S
YSTEM PRESSURE SENSOR
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair short to ground or short to power in harness or connectors.
6.CHECK COMPONENTS
Check the following.
Crankshaft position sensor (Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".)
Camshaft position sensor (bank 1) (Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".)
Battery current sensor (Refer to EC-414, "
Component Inspection (Battery Current Sensor)".)
Refrigerant pressure sensor (Refer to EC-520, "
Component Function Check".)
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace malfunctioning component.
7.CHECK APP SENSOR
Refer to EC-470, "
Component Inspection (Accelerator Pedal Position Sensor)".
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 8.
8.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly.
Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASS IST SYSTEM : Removal and Installation"
(Without distance control assist system)
Refer to ACC-4, "
MODELS WITH DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation" (With
distance control assist system).
>> INSPECTION END
9.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP control system pressure sensor harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 10.
10.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between EVAP control system pressure sensor and ECM
E80 133EVAP control system pressure sen-
sor
C17 3
Battery current sensor E63 2
Refrigerant pressure sensor E77 1
131 APP sensor 2 (Without ICC) E110 1
APP sensor 2 (with ICC) E67 9
ECM Sensor
Connector Terminal Name Connector Terminal
EVAP control system pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 1 E80 150 Existed
Revision: 2010 May2011 QX56

Page 2363 of 5598

INFINITI QX56 2011 Factory Service Manual
P0452 EVAP CONTROL SYSTEM PRESSURE SENSOREC-339
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Loose or poor connection for each connector and harness
>> Repair open circuit, sh

P0452 EVAP CONTROL SYSTEM PRESSURE SENSOREC-339
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
11 .CHECK EVAP CONTROL SYSTEM PRESSURE SENS OR INPUT SIGNAL CIRCUIT FOR OPEN AND
SHORT
1. Check the continuity between EVAP control syst em pressure sensor harness connector and ECM har-
ness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 13.
NO >> GO TO 12.
12.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between EVAP c ontrol system pressure sensor and ECM
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
13.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR
Refer to EC-335, "
Component Inspection (EVAP Control System Pressure Sensor)".
Is the inspection result normal?
YES >> GO TO 14.
NO >> Replace EVAP control system pressure sensor. Refer to FL-10, "
Exploded View".
14.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (EVAP Cont rol System Pressure Sensor)INFOID:0000000006288363
1.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR
1. Turn ignition switch OFF.
2. Remove EVAP control system pressure sensor with its harness connector. Always replace O-ring with a new one.
3. Install a vacuum pump to EVAP control system pressure sensor.
4. Turn ignition switch ON and check output voltage between ECM harness connector terminals under the following conditions.
CAUTION:
Always calibrate the vacuum pu mp gauge when using it.
EVAP control system
pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 2 E80 143 Existed
ECM Condition
[Applied vacuum kPa (kg/cm
2, psi)] Voltage (V)
Connector +–
Terminal Terminal
E80 143 150 Not applied 1.8 - 4.8
-26.7 (-0.272, -3.87) 2.1 to 2.5 lower than above value
Revision: 2010 May2011 QX56

Page 2364 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-340
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0452 EVAP CONTROL S
YSTEM PRESSURE SENSOR
Never apply below -93.3 kPa (-0.952 kg/cm2, -13.53 psi) or pressure over 101.3 kPa (1.033 kg/cm2,
14.69 psi).
Is

Page 2365 of 5598

INFINITI QX56 2011 Factory Service Manual
P0453 EVAP CONTROL SYSTEM PRESSURE SENSOREC-341
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0453 EVAP CONTROL SYSTEM
PRESSURE SENSOR
DTC LogicINFOID:0000000006288322
DTC DETE

P0453 EVAP CONTROL SYSTEM PRESSURE SENSOREC-341
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0453 EVAP CONTROL SYSTEM
PRESSURE SENSOR
DTC LogicINFOID:0000000006288322
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Always perform test at a temperature of 5 °C (41 °F) or more.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON.
6. Select “DATA MONITOR” mode with CONSULT-III.
7. Check that “FUEL T/TM P SE” is more than 0°C (32 °F).
8. Start engine and wait at least 20 seconds.
9. Check 1st trip DTC.
WITH GST
1. Start engine and warm it up to normal operating temperature.
2. Set voltmeter probes to ECM harness connector terminals under the following conditions.
3. Check that the voltage is less than 4.2 V.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0453 EVAP SYS PRES SEN
(EVAP control system pres-
sure sensor high input) An excessively high voltage
from the sensor is sent to
ECM. Harness or connectors
(EVAP control system pressure sensor circuit is short-
ed.)
(Crankshaft position sensor circuit is open or shorted.)
[Camshaft position sensor (bank 1) circuit is shorted.]
(Accelerator pedal position sensor 2 circuit is shorted.)
(Battery current sensor circuit is shorted.)
(Refrigerant pressure sensor circuit is shorted.)
EVAP control system pressure sensor
Crankshaft position sensor
Camshaft position sensor (bank 1)
Accelerator pedal position sensor 2
Battery current sensor
Refrigerant pressure sensor
EVAP canister vent control valve
EVAP canister
Rubber hose from EVAP canister vent control valve to
vehicle frame
ECM Ground
Connector +–
Terminal Terminal
E80 134
(Fuel tank temperature sensor signal) 175
Revision: 2010 May2011 QX56

Page 2366 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-342
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0453 EVAP CONTROL S
YSTEM PRESSURE SENSOR
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON.
6. Turn ignition switch OFF a

Page 2367 of 5598

INFINITI QX56 2011 Factory Service Manual
P0453 EVAP CONTROL SYSTEM PRESSURE SENSOREC-343
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair short to ground or sho

P0453 EVAP CONTROL SYSTEM PRESSURE SENSOREC-343
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair short to ground or short to power in harness or connectors.
6.CHECK COMPONENTS
Check the following.
Crankshaft position sensor (Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".)
Camshaft position sensor (bank 1) (Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".)
Battery current sensor (Refer to EC-427, "
Component Inspection (Battery Current Sensor)".)
Refrigerant pressure sensor (Refer to EC-520, "
Component Function Check".)
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace malfunctioning component.
7.CHECK APP SENSOR
Refer to EC-470, "
Component Inspection (Accelerator Pedal Position Sensor)".
Is the inspection result normal?
YES >> GO TO 19.
NO >> GO TO 8.
8.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly.
Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation"
(Without distance control assist system)
Refer to ACC-4, "
MODELS WITH DISTANCE CONTROL ASSI ST SYSTEM : Removal and Installation" (With
distance control assist system).
>> INSPECTION END
9.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EVAP control syst em pressure sensor harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 10.
ECM Sensor
Connector Terminal Name Connector Terminal
F110 76 Crankshaft position sensor F74 1
77 Camshaft position sensor (bank 1) F84 1
E80 133EVAP control system pressure sen-
sor
C17 3
Battery current sensor E63 2
Refrigerant pressure sensor E77 1
131 APP sensor 2 (Without ICC) E110 1
APP sensor 2 (with ICC) E67 9
EVAP control system
pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 1 E80 150 Existed
Revision: 2010 May2011 QX56

Page 2368 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-344
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0453 EVAP CONTROL S
YSTEM PRESSURE SENSOR
10.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between EVAP control system pressure

EC-344
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0453 EVAP CONTROL S
YSTEM PRESSURE SENSOR
10.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between EVAP control system pressure sensor and ECM
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
11 .CHECK EVAP CONTROL SYSTEM PRESSURE SEN SOR INPUT SIGNAL CIRCUIT FOR OPEN AND
SHORT
1. Check the continuity between EVAP control system pressure sensor harness connector and ECM har-
ness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 13.
NO >> GO TO 12.
12.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between EVAP control system pressure sensor and ECM
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
13.CHECK RUBBER TUBE
1. Disconnect rubber tube connected to EVAP c anister vent control valve. Refer to FL-10, "
Hydraulic Lay-
out".
2. Check the rubber tube for clogging.
Is the inspection result normal?
YES >> GO TO 14.
NO >> Clean the rubber tube using an air blower, repair or replace rubber tube.
14.CHECK EVAP CANISTER VENT CONTROL VALVE
Refer to EC-327, "
Component Inspection (EVAP Canister Vent Control Valve)".
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace EVAP canister vent control valve. Refer to FL-10, "
Exploded View".
15.CHECK EVAP CONTROL SYSTEM PRESSURE SENSOR
Refer to EC-335, "
Component Inspection (EVAP Control System Pressure Sensor)".
Is the inspection result normal?
YES >> GO TO 16.
NO >> Replace EVAP control system pressure sensor. Refer to FL-10, "
Exploded View".
16.CHECK IF EVAP CANISTER IS SATURATED WITH WATER
1. Remove EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
EVAP control system
pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
C17 2 E80 143 Existed
Revision: 2010 May2011 QX56

Load next 8 pages

Page: < prev 1-10 ... 2329-2336 2337-2344 2345-2352 2353-2360 2361-2368 2369-2376 2377-2384 2385-2392 2393-2400 ... 5600 next >

reset infotainment system spare tire location airbag disable parking sensors navigation air condition
