Page 3345 of 5598

INFINITI QX56 2011 Factory Service Manual
INL-78
< REMOVAL AND INSTALLATION >
PERSONAL LAMP
2. Press the pawls (B) on both sides as shown in the figure using asmall flat-bladed screwdriver (A), and then pull out personal
lamp case (2) from p

Page 3346 of 5598

INFINITI QX56 2011 Factory Service Manual
PUDDLE LAMPINL-79
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
PUDDLE LAMP
Exploded ViewINFOID:0000000006288665
Removal and InstallationINFOID:0000000006288666
CAUTION:
Disconnect

Page 3347 of 5598

INFINITI QX56 2011 Factory Service Manual
INL-80
< REMOVAL AND INSTALLATION >
PUDDLE LAMP
4. Disengage puddle lamp fixing pawls, and then remove puddlelamp (1) from base cover (2).
INSTALLATION
Install in the reverse order of removal.
: Pawl

Page 3348 of 5598

INFINITI QX56 2011 Factory Service Manual
LUGGAGE ROOM LAMPINL-81
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
INL
N
O P
LUGGAGE ROOM LAMP
Exploded ViewINFOID:0000000006288667
Removal and InstallationINFOID:0000000006288668
CAUTION:

Page 3349 of 5598

INFINITI QX56 2011 Factory Service Manual
INL-82
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Bulb SpecificationsINFOID:00000000062

Page 3350 of 5598

INFINITI QX56 2011 Factory Service Manual
INT-1
BODY INTERIOR
C
DE
F
G H
I
K L
M
SECTION INT
A
B
INT
N
O P
CONTENTS
INTERIOR
PRECAUTION ................ ...............................3
PRECAUTIONS ...........................................

INT-1
BODY INTERIOR
C
DE
F
G H
I
K L
M
SECTION INT
A
B
INT
N
O P
CONTENTS
INTERIOR
PRECAUTION ................ ...............................3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
3
Precaution for Procedure without Cowl Top Cover ......4
Precaution for Work ..................................................4
PREPARATION ............................................5
PREPARATION .............................................. .....5
Special Service Tools .......................................... ......5
Commercial Service Tools ........................................5
CLIP LIST ............................................................6
Clip List ............................................................... ......6
SYMPTOM DIAGNOSIS ...............................7
SQUEAK AND RATTLE TROUBLE DIAG-
NOSES ........................ ........................................
7
Work Flow ........................................................... ......7
Inspection Procedure ................................................9
Diagnostic Worksheet .............................................11
REMOVAL AND INSTALLATION ...............13
FRONT DOOR FINISHER .............................. ....13
Exploded View .................................................... ....13
Removal and Installation .........................................14
REAR DOOR FINISHER ....................................16
Exploded View .................................................... ....16
Removal and Installation .........................................16
BODY SIDE TRIM ..............................................18
Exploded View .................................................... ....18
DASH SIDE FINISHER .......................................... ....18
DASH SIDE FINISHER : Removal and Installation
....
18
FRONT PILLAR GARNISH .................................... ....19
FRONT PILLAR GARNISH : Removal and Instal-
lation ........................................................................
19
BODY SIDE WELT ................................................. ....20
BODY SIDE WELT : Removal and Installation ........20
KICKING PLATE INNER ....................................... ....20
KICKING PLATE INNER : Removal and Installa-
tion ...........................................................................
20
KICKING PLATE OUTER ...................................... ....21
KICKING PLATE OUTER : Removal and Installa-
tion ...........................................................................
21
CENTER PILLAR LOWER GARNISH ................... ....22
CENTER PILLAR LOWER GARNISH : Removal
and Installation ........................................................
22
CENTER PILLAR UPPER GARNISH ........................22
CENTER PILLAR UPPER GARNISH : Removal
and Installation .................................................... ....
22
FLOOR TRIM ....................................................24
Exploded View .........................................................24
FRONT FLOOR CARPET ...................................... ....25
FRONT FLOOR CARPET : Removal and Installa-
tion ....................................................................... ....
25
REAR FLOOR CARPET ........................................ ....27
REAR FLOOR CARPET : Removal and Installa-
tion ...........................................................................
27
HEADLINING ....................................................28
Exploded View .........................................................28
Removal and Installation .........................................29
LUGGAGE FLOOR TRIM .................................33
Exploded View .........................................................33
Revision: 2010 May2011 QX56

Page 3351 of 5598

INFINITI QX56 2011 Factory Service Manual
INT-2
LUGGAGE FLOOR REAR BOARD ..........................34
LUGGAGE FLOOR REAR BOARD : Removal and
Installation ..............................................................
34
LUGGAGE REAR PLATE .

Page 3352 of 5598

INFINITI QX56 2011 Factory Service Manual
PRECAUTIONSINT-3
< PRECAUTION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:00000000064

PRECAUTIONSINT-3
< PRECAUTION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006415653
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wh eel Rotation after Battery Disconnect
INFOID:0000000006415652
NOTE:
Before removing and installing any control units, first tu rn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnos is according to self-diagnosis results.
For vehicle with steering lock unit, if the battery is disconnected or discharged, the steering wheel will lock and
cannot be turned.
If turning the steering wheel is required with the batte ry disconnected or discharged, follow the operation pro-
cedure below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position. (At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock wil l remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
Revision: 2010 May2011 QX56
