2011 INFINITI QX56 Factory Service Manual

sensor wheel alignment drain bolt headlights key fob air filter

Load previous 8 pages

Page 5177 of 5598

INFINITI QX56 2011 Factory Service Manual
DIAGNOSIS AND REPAIR WORK FLOWTM-89
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
6.IDENTIFY MALFUNCTIONING SYSTEM WI TH “DIAGNOSIS CHART BY SYMPTOM”
Use TM-165, "
Symptom

Page 5178 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-90
< BASIC INSPECTION >[7AT: RE7R01B]
DIAGNOSIS AND REPAIR WORK FLOW
Symptoms
�† Vehicle does not move ( �† Any position �† Particular position )

Page 5179 of 5598

INFINITI QX56 2011 Factory Service Manual
ADDITIONAL SERVICE WHEN REPLACING TRANSMISSION ASSEMBLY
TM-91
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
ADDITIONAL SERVICE WHEN REPL ACING TRANSMISSION ASSEMBLY
DescriptionI

Page 5180 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-92
< BASIC INSPECTION >[7AT: RE7R01B]
ADDITIONAL SERVICE WHEN RE
PLACING CONTROL VALVE & TCM
ADDITIONAL SERVICE WHEN REPLACING CONTROL VALVE & TCM
DescriptionINFOID:0000000006233274
Decel G sensor

Page 5181 of 5598

INFINITI QX56 2011 Factory Service Manual
CALIBRATION OF DECEL G SENSORTM-93
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
CALIBRATION OF DECEL G SENSOR
DescriptionINFOID:0000000006233272
Decel G sensor calibration must

Page 5182 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-94
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
A/T FLUID
ChangingINFOID:0000000006226791
CAUTION:
Use only Genuine NISSAN Matic S ATF. Never mix with other ATF.
Using ATF other than Genuine N

Page 5183 of 5598

INFINITI QX56 2011 Factory Service Manual
A/T FLUIDTM-95
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
d. When the ATF starts to drip, tighten the drain plug to the oil pan to the specified torque. Refer to TM-182,
"Ex

A/T FLUIDTM-95
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
d. When the ATF starts to drip, tighten the drain plug to the oil pan to the specified torque. Refer to TM-182,
"Exploded View".
CAUTION:
Never reuse drain plug and drain plug gasket.
e. Remove overflow plug from oil pan.
f. Install the charging pipe (A) to the overflow plug hole. CAUTION:
Tighten the charging pipe by hand.
g. Install the bucket pump hose (B) to the charging pipe. CAUTION:
Insert the bucket pump hose all the way to the end of the
charging pipe.
h. Fill approximately 3 liters (3-1/8 US qt, 2-5/8 lmp qt) of the ATF.
i. Remove the bucket pump hose to remove the charging pipe, and then temporarily tighten the overflow plug to the oil pan.
CAUTION:
Quickly perform the procedure to avoid ATF leakage from
the oil pan.
j. Lift down the vehicle.
k. Start the engine.
l. Make the ATF temperature approximately 40 °C (104 °F).
NOTE:
The ATF level is greatly affected by the temperat ure. Always check the ATF temperature on “ATF TEMP
1” of “Data Monitor” using CONSULT-III.
m. Park vehicle on level surface and set parking brake.
n. Shift the selector lever through each gear pos ition. Leave selector lever in “P” position.
o. Lift up the vehicle when the ATF temperature reaches 40 °C (104 °F), and remove the overflow plug from
the oil pan.
CAUTION:
Perform “Step 4-o” with the engine at idle.
p. When the ATF starts to drip, tighten the overflow plug to the oil pan to the specified torque. Refer to TM-
182, "Exploded View".
CAUTION:
Never reuse overflow plug.
AdjustmentINFOID:0000000006226792
CAUTION:
Use only Genuine NISSAN Matic S ATF. Never mix with other ATF.
Using ATF other than Genuine NI SSAN Matic S ATF will cause deteri oration in driveability and A/T
durability, and may damage the A/T, which is not covered by the INFINITI new vehicle limited war-
ranty.
When filling ATF, be careful not to sca tter heat generating parts such as exhaust.
Always maintain the ATF temperature within between 35 °C (95 °F) and 45 °C (113 °F) while checking
with CONSULT-III when the ATF level adjustment is performed.
JSDIA1335ZZ
Recommended fluid and fluid capacity : Refer to TM-296, "General Specification".
Revision: 2010 May2011 QX56

Page 5184 of 5598

INFINITI QX56 2011 Factory Service Manual
TM-96
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
1. Install the O-ring (315268E000) (A) to the charging pipe
(310811EA5A) (B).
2. Start the engine.
3. Make the ATF temperature approximately 40 °C

Load next 8 pages
