INFINITI QX56 2011 Factory Service Manual
SEC-18
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM
VEHICLE SECURITY SYSTEM : System Description
INFOID:0000000006226185
The vehicle security system has two alarm functions (theft wa

SEC-18
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM
VEHICLE SECURITY SYSTEM : System Description
INFOID:0000000006226185
The vehicle security system has two alarm functions (theft warning alarm and panic alarm), and reduces the
possibility of a theft or mischief by activating horns and headlamps intermittently.
The panic alarm does not start when the theft warning alarm is activating, and the panic alarm stops when
the theft warning alarm is activated.
The priority of the functions are as per the following.
THEFT WARNING ALARM
The theft warning alarm function activates horns and headlamps intermittently when BCM detects that any
door or hood is opened by unauthorized means, whil e the system is in the ARMED state.
Security indicator lamp on combination meter always blinks when power supply position is any position other
than ON. Security indicator lamp blinking warns that the vehicle is equipped with a vehicle security system.
Operation Flow
Priority Function
1 Theft warning alarm
2 Panic alarm
JMKIA5416GB
No. System state Switching condition
1 DISARMED to PRE-ARMED When all conditions of A and
one condition of B is satis-
fied. AB
Power supply position: OFF/LOCK
All doors: Closed
Hood: Closed All doors are locked by:
Door key cylinder LOCK switch
LOCK button of Intelligent Key
Door request switch
2 PRE-ARMED to ARMED When all of the following
conditions are satisfied for
30 seconds. Power supply position: OFF/LOCK
All doors: Locked
Hood: Closed
3 ARMED to ALARM When one condition of A and
one condition of B are satis-
fied. AB
Intelligent Key: Not used Any door: Open Hood: Open
4 DISARMED to PRE-RESET When all conditions of A and
one condition of B is satis-
fied. AB
Power supply position: OFF/LOCK
All doors: Closed
Hood: Open All doors are locked by:
Door key cylinder LOCK switch
LOCK button of Intelligent Key
Door request switch
5 PRE-ARMED to PRE-RESET When one of the following
conditions is satisfied. Hood: Open
Revision: 2010 May2011 QX56

Page 4626 of 5598

INFINITI QX56 2011 Factory Service Manual
SYSTEMSEC-19
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NOTE:
BCM ignores the door key cylinder UNLOCK switch signal input for 1 second after the door ke

SYSTEMSEC-19
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
NOTE:
BCM ignores the door key cylinder UNLOCK switch signal input for 1 second after the door key cylinder LOCK switch signal input .
To lock/unlock all doors by operating remote controller button of Intelligent Key or door request switch, Intelligent Key must be within
the detection area of outside key antenna. For details, refer to DLK-18, "
INTELLIGENT KEY SYSTEM : System Description".
To open back door by operating back door opener switch, Intelligent Key must be within the detection area of outside key anten na. For
details, refer to DLK-18, "
INTELLIGENT KEY SYSTEM : System Description".
DISARMED Phase
The vehicle security system is not set in the DISARM ED phase. The vehicle security system stays in this
phase while any door is open, because it is assumed that the owner is inside or nearby the vehicle. Security
indicator lamp blinks every 2.4 seconds.
When the vehicle security system is reset, each phase switches to the DISARMED phase directly.
PRE-ARMED Phase
The PRE-ARMED phase is the transient state bet ween the DISARMED phase and the ARMED phase. This
phase is maintained for 30 seconds, so that the owner c an reset the setting due to a mis-operation. This phase
switches to the ARMED phase when vehicle conditions are not changed for 30 seconds. Security indicator
lamp illuminates while being in this phase.
To reset the PRE-ARMED phase, refer to the switching condition of No. 10 in the table above.
ARMED Phase
The vehicle security system is set, and BCM monitors all necessary inputs. If any door or hood is opened with-
out using Intelligent Key, vehicle security system switc hes to the ALARM phase. Security indicator lamp blinks
every 2.4 seconds.
To reset the ARMED phase, refer to the switching condition of No. 11 in the table above.
ALARM Phase
BCM transmits “Theft Warning Horn Request” signal and “High Beam Request” signal intermittently to IPDM
E/R via CAN communication. In this phase, horns and headlamps are activated intermittently for approxi-
mately 50 seconds to warn that the vehicle is accessed by unauthorized means. ON/OFF timing of horns and
headlamps are synchronized. After 50 seconds, the vehi cle security system returns to the ARMED phase. At
6ARMED to
PRE-RESET No conditions.
7 ALARM to PRE-RESET
8 PRE-RESET to DISARMED When one of the following
conditions is satisfied. Power supply positi
on: ACC/ON/CRANKING/RUN
Door key cylinder UNLOCK switch: ON
UNLOCK button of Intelligent Key: ON
Door request switch: ON
Back door opener switch: ON
UNLOCK switch of door lock and unlock switch: ON
Any door: Open
9 PRE-RESET to PRE-ARMED When all of the following
conditions are satisfied. Power supply position: OFF/LOCK
All doors: Closed
Hood: Closed
10 PRE-ARMED to DISARMED When one of the following
condition is satisfied. Power supply positi
on: ACC/ON/CRANKING/RUN
Door key cylinder UNLOCK switch: ON
UNLOCK button of Intelligent Key: ON
AUTO BACK DOOR button of Intelligent Key: ON
Door request switch: ON
Back door opener switch: ON
Any door: Open
11 A R M E D t o DISARMED When one of the following
condition is satisfied. Power supply positi
on: ACC/ON/CRANKING/RUN
Door key cylinder UNLOCK switch: ON
UNLOCK button of Intelligent Key: ON
AUTO BACK DOOR button of Intelligent Key: ON
Door request switch: ON
Back door opener switch: ON
12 ALARM to
DISARMED
13 RE-ALARM When one of the following condition is satisfied after the
ALARM operation is finished. Any door: Open
Hood: Open
No. System state Switching condition
Revision: 2010 May2011 QX56

Page 4627 of 5598

INFINITI QX56 2011 Factory Service Manual
SEC-20
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM
this time, if BCM still detects unauthorized access to t
he vehicle, the system is switched to the ALARM phase
again. This RE-ALARM o

Page 4628 of 5598

INFINITI QX56 2011 Factory Service Manual
DIAGNOSIS SYSTEM (BCM)SEC-21
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu nction (BCM - COMMO

DIAGNOSIS SYSTEM (BCM)SEC-21
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu nction (BCM - COMMON ITEM)INFOID:0000000006365349
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
×: Applicable item
*: This item is indicated, but not used.
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on
CONSULT-III.
Diagnosis mode Function Description
Work Support Changes the setting for each system function.
Self Diagnostic Result Displays the diagnosis results judged by BCM. Refer to BCS-57, "
DTCIndex".
CAN Diag Support Monitor Monitors the reception status of CAN communication viewed from BCM. Refer to CONSULT-III opera-
tion manual.
Data Monitor The BCM input/output signals are displayed.
Active Test The signals used to activate each device are forcibly supplied from BCM.
Ecu Identification The BCM part number is displayed.
Configuration Read and save the vehicle specification.
Write the vehicle specification when replacing BCM.
System Sub system selection item Diagnosis mode
Work Support Data Monitor Active Test
Door lock DOOR LOCK ×××
Rear window defo gger REAR DEFOGGER ××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ×××
— AIR CONDITONER* ××
Intelligent Key system
Engine start system INTELLIGENT KEY
×××
Combination switch COMB SW ×
Body control system BCM ×
IVIS IMMU ×××
Interior room lamp battery saver BATTERY SAVER ×××
Back door TRUNK ×
Vehicle security system THEFT ALM ×××
RAP system RETAINED PWR ×
Signal buffer system SIGNAL BUFFER ××
