Page 3209 of 5598
![INFINITI QX56 2011 Factory Service Manual
B2667, B2668 SUNLOAD SENSOR (PASSENGER SIDE)
HAC-103
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B2667, B2668 SUNLOAD SENS OR (PASSENGER SIDE)
DTC LogicIN INFINITI QX56 2011 Factory Service Manual
B2667, B2668 SUNLOAD SENSOR (PASSENGER SIDE)
HAC-103
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B2667, B2668 SUNLOAD SENS OR (PASSENGER SIDE)
DTC LogicIN](/manual-img/42/57033/w960_57033-3208.png)
B2667, B2668 SUNLOAD SENSOR (PASSENGER SIDE)
HAC-103
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B2667, B2668 SUNLOAD SENS OR (PASSENGER SIDE)
DTC LogicINFOID:0000000006275937
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to HAC-
72, "DTC Logic".
If DTC is displayed along with DTC U1010, fi rst perform the trouble diagnosis for DTC U1010. HAC-73,
"DTC Logic".
Sunload sensor may register a malfunction when indoors, at dusk, or at other times when light is insufficient.
When performing the diagnosis indoors, use a lamp (60 W or more) that is pointed at the sunload sensor.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Check DTC.
Is DTC detected?
YES >> Refer to HAC-103, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006275938
1.CHECK SUNLOAD SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect sunload sensor connector.
3. Turn ignition switch ON.
4. Check voltage between sunload sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK SUNLOAD SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harnes s connector and A/C auto amp. harness connector.
DTCItems
(CONSULT-III screen terms) DTC detection condition Possible cause
B2667 PASS SUNLOAD SENSOR Detected calorie at sunload sensor (passenger
side) 2832 W/m
2 (2436 kcal/m2·h) or more.
Sunload sensor
A/C auto amp.
Harness or connectors
[The sensor circuit (passenger
side) is open or shorted.]
B2668
Detected calorie at sunload sensor (passenger
side) 64.7 W/m
2 (55.6 kcal/m2·h) or less.
+
−Vol tag e
(Approx.)
Sunload sensor
Connector Terminal M74 1 Ground 5 V
Sunload sensor —Continuity
Connector Terminal
M74 3 Ground Existed
Revision: 2010 May2011 QX56
Page 3210 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-104
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2667, B2668 SUNLOAD SENS
OR (PASSENGER SIDE)
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK INFINITI QX56 2011 Factory Service Manual
HAC-104
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2667, B2668 SUNLOAD SENS
OR (PASSENGER SIDE)
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK](/manual-img/42/57033/w960_57033-3209.png)
HAC-104
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B2667, B2668 SUNLOAD SENS
OR (PASSENGER SIDE)
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK SUNLOAD SENSOR
Check sunload sensor. Refer to HAC-104, "
Component Inspection".
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Replace sunload sensor. Refer to HAC-149, "
Removal and Installation".
4.CHECK SUNLOAD SENSOR POWER SUPPLY CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between sunload sensor harne ss connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair harness or connector.
5.CHECK SUNLOAD SENSOR POWER SUPPLY CIRCUIT FOR GROUND SHORT
Check continuity between sunload sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK SUNLOAD SENSOR POWER SUPPLY CIRCUIT FOR POWER SHORT
1. Turn ignition switch ON.
2. Check voltage between sunload sensor harness connector and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Repair harness or connector.
Component InspectionINFOID:0000000006275939
1.CHECK SUNLOAD SENSOR
1. Turn ignition switch OFF.
2. Reconnect sunload sensor connector and A/C auto amp. connector.
3. Turn ignition switch ON.
4. Check input voltage from sunload sensor between A/C auto amp. harness connector and ground. Refer to
applicable table for normal value.
Sunload sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M74 1 M50 29 Existed
Sunload sensor —Continuity
Connector Terminal
M74 1 Ground Not existed
+ −Voltage
(Approx.)
Sunload sensor
Connector Terminal M74 1 Ground 0 V
Revision: 2010 May2011 QX56
Page 3211 of 5598
B2667, B2668 SUNLOAD SENSOR (PASSENGER SIDE)
HAC-105
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
NOTE:
When checking indoors, use a lamp of approximately 60 W. Move the lamp towards and away from the
sensor to check.
The sunload amount produced by direct sunshine in fa ir weather is equivalent to approximately 0.770
kW/m
2 (662 kcal/m2·h).
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace sunload sensor. Refer to HAC-149, "
Removal and Installation".
+
−
A/C auto amp.
Connector Terminal M50 29 Ground
JPIIA1659GB
Revision: 2010 May2011 QX56
Page 3212 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-106
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B266B, B266C REAR IN-VEHICLE SENSOR
B266B, B266C REAR IN-VEHICLE SENSOR
DTC LogicINFOID:0000000006275940
DTC DETECTION LOGIC
NOTE:
If INFINITI QX56 2011 Factory Service Manual
HAC-106
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B266B, B266C REAR IN-VEHICLE SENSOR
B266B, B266C REAR IN-VEHICLE SENSOR
DTC LogicINFOID:0000000006275940
DTC DETECTION LOGIC
NOTE:
If](/manual-img/42/57033/w960_57033-3211.png)
HAC-106
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B266B, B266C REAR IN-VEHICLE SENSOR
B266B, B266C REAR IN-VEHICLE SENSOR
DTC LogicINFOID:0000000006275940
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
HAC-
72, "DTC Logic".
If DTC is displayed along with DTC U1010, fi rst perform the trouble diagnosis for DTC U1010. HAC-73,
"DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Check DTC.
Is DTC detected?
YES >> Refer to HAC-106, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006275941
1.CHECK REAR IN-VEHICLE SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect rear in-vehicle sensor connector.
3. Turn ignition switch ON.
4. Check voltage between rear in-vehi cle sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK REAR IN-VEHCLE SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between rear in-v ehicle sensor harness connector and ground.
Is the inspection result normal?
DTC Items
(CONSULT-III screen terms) DTC detection condition Possible cause
B266B REAR IN-VEHICLE SEN The rear in-vehicle sensor recognition tempera-
ture is too high.
Rear in-vehicle sensor
A/C auto amp.
Harness or connectors
(The sensor circuit is open or short-
ed.)
B266C
The rear in-vehicle sensor recognition tempera-
ture is too low.
+
−Voltage
(Approx.)
Rear in-vehicle sensor
Connector Terminal B211 1 Ground 5 V
Rear in-vehicle sensor —Continuity
Connector Terminal
B211 2 Ground Existed
Revision: 2010 May2011 QX56
Page 3213 of 5598
![INFINITI QX56 2011 Factory Service Manual
B266B, B266C REAR IN-VEHICLE SENSORHAC-107
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK REAR IN- INFINITI QX56 2011 Factory Service Manual
B266B, B266C REAR IN-VEHICLE SENSORHAC-107
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK REAR IN-](/manual-img/42/57033/w960_57033-3212.png)
B266B, B266C REAR IN-VEHICLE SENSORHAC-107
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK REAR IN-VEHICLE SENSOR
Check rear in-vehicle sensor. Refer to HAC-107, "
Component Inspection".
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Replace rear in-vehicle sensor. Refer to HAC-148, "
REAR A/C UNIT ASSEMBLY : Removal and
Installation".
4.CHECK REAR IN-VEHCLE SENSOR POWER SUPPLY CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between rear in-vehicle sens or harness connector and A/C auto amp. harness connec-
tor.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair harness or connector.
5.CHECK REAR IN-VEHCLE SENSOR PO WER SUPPLY CIRCUIT FOR GROUND SHORT
Check continuity between rear in-v ehicle sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK REAR IN-VEHICLE SENSOR PO WER SUPPLY CIRCUIT FOR POWER SHORT
1. Turn ignition switch ON.
2. Check voltage between rear in-vehicle sensor harness connector and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Repair harness or connector.
Component InspectionINFOID:0000000006275942
1.CHECK REAR IN-VEHICLE SENSOR
1. Turn ignition switch OFF.
2. Disconnect rear in-vehicle sensor connector.
3. Check resistance between rear in-vehicle sensor terminals.
Rear in-vehicle sensor A/C auto amp. Continuity
Connector Terminal Connector Terminal
B211 1 M50 8 Existed
Rear in-vehicle sensor —Continuity
Connector Terminal
B211 1 Ground Not existed
+ −Vol tag e
(Approx.)
Rear in-vehicle sensor
Connector Terminal B211 1 Ground 0 V
Revision: 2010 May2011 QX56
Page 3214 of 5598
HAC-108
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
B266B, B266C REAR IN-VEHICLE SENSOR
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace rear in-vehicle sensor. Refer to
HAC-148, "
REAR A/C UNIT ASSEMBLY : Removal and
Installation".
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12 −
15 (5) 12.34
− 10 (14) 9.62
− 5 (23) 7.56
0 (32) 6.00
5 (41) 4.80
10 (50) 3.87
15 (59) 3.14
20 (68) 2.57
25 (77) 2.12
30 (86) 1.76
35 (95) 1.47
40 (104) 1.23 45 (113) 1.04
Revision: 2010 May2011 QX56
Page 3215 of 5598
![INFINITI QX56 2011 Factory Service Manual
B27B0 A/C AUTO AMP.HAC-109
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B27B0 A/C AUTO AMP.
DTC LogicINFOID:0000000006275946
DTC DETECTION LOGIC
NOTE:
I INFINITI QX56 2011 Factory Service Manual
B27B0 A/C AUTO AMP.HAC-109
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B27B0 A/C AUTO AMP.
DTC LogicINFOID:0000000006275946
DTC DETECTION LOGIC
NOTE:
I](/manual-img/42/57033/w960_57033-3214.png)
B27B0 A/C AUTO AMP.HAC-109
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
B27B0 A/C AUTO AMP.
DTC LogicINFOID:0000000006275946
DTC DETECTION LOGIC
NOTE:
If DTC is displayed along with DTC U1000, first per form the trouble diagnosis for DTC U1000. Refer to HAC-
72, "DTC Logic".
If DTC is displayed along with DTC U1010, fi rst perform the trouble diagnosis for DTC U1010. HAC-73,
"DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Check DTC.
Is DTC detected?
YES >> Refer to HAC-109, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006275947
1.PERFORM SELF DIAGNOSTIC
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Result” m ode of “HVAC” using CONSULT-III.
3. Touch “ERASE”.
4. Turn ignition switch OFF.
5. Turn ignition switch ON.
6. Perform “DTC CONFIRMATION PROCEDURE”. Refer to HAC-109, "
DTC Logic".
Is DTC detected again?
YES >> Replace A/C auto amp. Refer to HAC-146, "Removal and Installation".
NO >> INSPECTION END
DTC Items
(CONSULT-III screen terms) DTC detection condition Possible cause
B27B0 A/C AUTO AMP. A/C auto amp. EEPROM
system is mal-
functioning. A/C auto amp.
Revision: 2010 May2011 QX56
Page 3216 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-110
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
A/C AUTO AMP.
A/C AUTO AMP. : Diagnosis ProcedureINFOID:0000000006275948
INFINITI QX56 2011 Factory Service Manual
HAC-110
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
A/C AUTO AMP.
A/C AUTO AMP. : Diagnosis ProcedureINFOID:0000000006275948](/manual-img/42/57033/w960_57033-3215.png)
HAC-110
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
A/C AUTO AMP.
A/C AUTO AMP. : Diagnosis ProcedureINFOID:0000000006275948
1.CHECK FUSE
Check 10A fuse [No. 9, 19, and 4, located in the fuse block (J/B)].
NOTE:
Refer to PG-140, "
Fuse, Connector and Terminal Arrangement".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK A/C AUTO AMP. POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check voltage between A/C auto amp. harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector between A/C auto amp. and fuse block (J/B).
3.CHECK A/C AUTO AMP. GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between A/C auto amp. harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
FRONT AIR MIX DOOR MOTOR (DRIVER SIDE)
FRONT AIR MIX DOOR MOTOR (DRI VER SIDE) : Diagnosis ProcedureINFOID:0000000006275949
1.CHECK FRONT AIR MIX DOOR MOTO R (DRIVER SIDE) POWER SUPPLY
1. Turn ignition switch ON.
2. Check voltage between front air mix door motor LH harness connector and ground.
+
− Vo l ta g e
A/C auto amp. Ignition switch position
Connector Terminal OFF ACC ON
M50 4
Ground Approx. 0 V Battery voltage Battery voltage
23 Approx. 0 V Approx. 0 V Battery voltage 3 Battery voltage Battery voltage Battery voltage
A/C auto amp. —Continuity
Connector Terminal
M50 2
Ground Existed
22
37
Revision: 2010 May2011 QX56
