2011 INFINITI QX56 Factory Service Manual

turn signal manual transmission low beam transmission oil lane assist refrigerant type

Page 2377 of 5598

INFINITI QX56 2011 Factory Service Manual
P0461 FUEL LEVEL SENSOREC-353
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0461 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288330
DTC DETECTION LOGIC
NOTE:

If DTC P0461 is d

P0461 FUEL LEVEL SENSOREC-353
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0461 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288330
DTC DETECTION LOGIC
NOTE:

If DTC P0461 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
If DTC P0461 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-378, "
DTC Logic".
Driving long distances naturally affect fuel gauge level.
This diagnosis detects the fuel gauge malfunction of the gauge not moving even after a long distance has
been driven.
DTC CONFIRMATION PROCEDURE
1.PERFORM COMPONENT FUNCTION CHECK
Perform Component Function Check. Refer to EC-353, "
Component Function Check".
Use component function check to check the overall function of the fuel level sensor. During this check, a 1st
trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-354, "
Diagnosis Procedure".
Component Function CheckINFOID:0000000006288331
1.PRECONDITIONING
WARNING:
When performing the following procedure, alw ays observe the handling of the fuel. Refer to FL-2,
"General Precautions".
TESTING CONDITION:
Before starting component function check, preparation of draining fuel and refilling fuel is required.
>> GO TO 2.
2.PERFORM COMPONENT FUNCTION CHECK
NOTE:
Start from step 8, if it is possible to confirm that the fuel cannot be drained by 30 (7-7/8 US gal, 6-5/8
Imp gal) in advance.
1. Prepare a fuel container and a spare hose.
2. Release fuel pressure from fuel line. Refer to EC-153, "
Work Procedure".
3. Remove the fuel feed hose on the fuel level sensor unit. Refer to FL-5, "
Removal and Installation".
4. Connect a spare fuel hose where the fuel feed hose was removed.
5. Turn ignition switch ON.
6. Drain fuel by 30 (7-7/8 US gal, 6-5/8 Imp gal) from the fuel tank using proper equipment.
7. Confirm that the fuel gauge indication varies.
8. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal).
9. Confirm that the fuel gauge indication varies.
Is the inspection result normal?
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0461 FUEL LEVEL SENSOR
(Fuel level sensor circuit
range/performance) The output signal of the fuel level sensor
does not change within the specified
range even though the vehicle has been
driven a long distance. Harness or connectors
(The CAN communication line is open or short-
ed)
Harness or connectors (The sensor circuit is open or shorted)
Combination meter
Fuel level sensor
Revision: 2010 May2011 QX56

Page 2378 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-354
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0461 FUEL LEVEL SENSOR
YES >> INSPECTION END
NO >> Proceed to
EC-354, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006288332
1.CHECK DTC WITH �

Page 2379 of 5598

INFINITI QX56 2011 Factory Service Manual
P0462, P0463 FUEL LEVEL SENSOR
EC-355
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0462, P0463 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288333
DTC DETECTION LOGIC
NOTE:

If

P0462, P0463 FUEL LEVEL SENSOR
EC-355
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0462, P0463 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288333
DTC DETECTION LOGIC
NOTE:

If DTC P0462 or P0463 is displayed with DTC UXXXX, first perform the trouble diagnosis for DTC
UXXXX.
If DTC P0462 or P0463 is displayed with DTC P0607, first perform the trouble diagnosis for DTC
P0607.Refer to EC-378, "
DTC Logic".
This diagnosis indicates the former, to detect open or short circuit malfunction.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-355, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288334
1.CHECK DTC WITH “COMBINATION METER”
Refer to MWI-30, "
CONSULT-III Function".
Is any DTC detected?
YES >> Perform trouble diagnosis of detected DTC.
NO >> GO TO 2.
2.CHECK FUEL LEVEL SENSOR SIGNAL CIRCUIT
Check fuel level sensor signal circuit. Refer to MWI-69, "
Component Function Check".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Perform trouble diagnosis of fuel level sensor signal circuit. Refer to MWI-69,
"DiagnosisProcedure".
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0462 FUEL LEVL SEN/CIRC
(Fuel level sensor circuit low
input) An excessively low voltage from the
sensor is sent to ECM.
Harness or connectors
(The CAN communication line is open or shorted)
Harness or connectors (The sensor circuit is open or shorted)
Combination meter
Fuel level sensor
P0463 FUEL LEVL SEN/CIRC
(Fuel level sensor circuit high
input) An excessively high voltage from
the sensor is sent to ECM.
Revision: 2010 May2011 QX56

Page 2380 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-356
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0500 VSS
P0500 VSS
DescriptionINFOID:0000000006217857
The vehicle speed signal is sent to the “combination me
ter” from the “ABS actuator and electric

EC-356
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0500 VSS
P0500 VSS
DescriptionINFOID:0000000006217857
The vehicle speed signal is sent to the “combination me
ter” from the “ABS actuator and electric unit (control
unit)” by CAN communication line. The “combination meter” then sends a signal to the ECM by CAN commu-
nication line.
DTC LogicINFOID:0000000006217858
DTC DETECTION LOGIC
NOTE:
If DTC P0500 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
If DTC P0500 is displayed with DTC P0607, first pe rform the trouble diagnosis for DTC P0607. Refer
to EC-378, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.INSPECTION START
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
Will CONSULT-III be used?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK VEHICLE SPEED SIGNAL
NOTE:
This procedure may be conducted with the drive wheels lifted in the shop or by driving the vehicle. If a
road test is expected to be easier, it is unnecessary to lift the vehicle.
WITH CONSULT-III
1. Start engine (VDC switch OFF).
2. Read “VHCL SPEED SE” in “DATA MONITOR” mode with CONSULT-III.
The vehicle speed on CONSULT-III should exceed 10 km/h (6 MPH) when rotating wheels with suitable
gear position.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-357, "
Diagnosis Procedure".
3.PERFORM DTC CONFIRMATION PROCEDURE
1. Select “DATA MONITOR” mode with CONSULT-III.
2. Warm engine up to normal operating temperature.
3. Maintain the following conditions for at least 50 consecutive seconds. CAUTION:
Always drive vehicle at a safe speed.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0500 VEH SPEED SEN/CIRC
(Vehicle speed sensor) The vehicle speed signal sent to
E C M i s a l m o s t 0 k m / h ( 0 M P H ) e v e n
when vehicle is being driven. Harness or connectors
(The CAN communication line is open or shorted)
Harness or connectors (The vehicle speed signal circuit is open or shorted)
Wheel sensor
Combination meter
ABS actuator and electric unit (control unit)
ENG SPEED More than 1,500 rpm
COOLAN TEMP/S More than 70 °C (158 °F)
Revision: 2010 May2011 QX56

Page 2381 of 5598

INFINITI QX56 2011 Factory Service Manual
P0500 VSSEC-357
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to
EC-357, "Diagnosis Procedure".
NO >> INSPECTION END
4.

Page 2382 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-358
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0506 ISC SYSTEM
P0506 ISC SYSTEM
DescriptionINFOID:0000000006217861
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment

EC-358
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0506 ISC SYSTEM
P0506 ISC SYSTEM
DescriptionINFOID:0000000006217861
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor detects the
actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000006217862
DTC DETECTION LOGIC
NOTE:
If DTC P0506 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is ou t of the specified value, perform EC-148, "
Work Procedure", before con-
ducting DTC Confirmation Procedure.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
Always perform the test at a temperature above −10 °C (14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Restart engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-358, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217863
1.CHECK INTAKE AIR LEAKAGE
1. Start engine and let it idle.
2. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
YES >> Discover air leakage location and repair.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0506 ISC SYSTEM
(Idle speed control system
RPM lower than expected) The idle speed is less than the target idle
speed by 100 rpm or more.
Electric throttle control actuator
Intake air leakage
Revision: 2010 May2011 QX56

Page 2383 of 5598

INFINITI QX56 2011 Factory Service Manual
P0506 ISC SYSTEMEC-359
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> GO TO 2.
2.REPLACE ECM
1. Stop engine.
2. Replace ECM.
3. Perform additional service when replacing ECM

Page 2384 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-360
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0507 ISC SYSTEM
P0507 ISC SYSTEM
DescriptionINFOID:0000000006217864
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment

EC-360
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0507 ISC SYSTEM
P0507 ISC SYSTEM
DescriptionINFOID:0000000006217864
The ECM controls the engine idle speed to a specified leve
l through the fine adjustment of the air, which is let
into the intake manifold, by operating the electric thrott le control actuator. The operating of the throttle valve is
varied to allow for optimum control of the engine idli ng speed. The crankshaft position sensor detects the
actual engine speed and sends a signal to the ECM.
The ECM controls the electric throttle control actuator so that the engine speed coincides with the target value
memorized in the ECM. The target engine speed is t he lowest speed at which the engine can operate steadily.
The optimum value stored in the ECM is determined by taking into consideration various engine conditions,
such as during warming up, deceleration and engine load (air conditioner, power steering and cooling fan
operation, etc.).
DTC LogicINFOID:0000000006217865
DTC DETECTION LOGIC
NOTE:
If DTC P0507 is displayed with ot her DTC, first perform the trouble diagnosis for the other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If the target idle speed is ou t of the specified value, perform EC-148, "
Work Procedure", before con-
ducting DTC Confirmation Procedure.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
Always perform the test at a temperature above −10 °C (14 °F).
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and run it for at least 1 minute at idle speed.
6. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-360, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217866
1.CHECK PCV HOSE CONNECTION
Confirm that PCV hose is connected correctly.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0507 ISC SYSTEM
(Idle speed control system
RPM higher than expected) The idle speed is more than the target idle
speed by 200 rpm or more. Electric throttle control actuator
Intake air leakage
PCV system
Revision: 2010 May2011 QX56

Load next 8 pages

Page: < prev 1-10 ... 2345-2352 2353-2360 2361-2368 2369-2376 2377-2384 2385-2392 2393-2400 2401-2408 2409-2416 ... 5600 next >

jack points homelink ECO mode engine air conditioning charging
