Page 4145 of 5598

INFINITI QX56 2011 Factory Service Manual
PWC-60
< DTC/CIRCUIT DIAGNOSIS >
POWER WINDOW SERIAL LINK
Is the inspection result normal?
YES >> Replace rear power window switch RH. Refer to PWC-74, "Removal and Installation".
NO >> GO TO 2.
2.CH

Page 4146 of 5598

INFINITI QX56 2011 Factory Service Manual
POWER WINDOWS DO NOT OPERATE WITH POWER WINDOW MAIN SWITCHPWC-61
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
SYMPTOM DIAGNOSIS
POWER WINDOWS DO NOT OPERATE WITH POWER WINDOW MAIN
SWITCH
Di

Page 4147 of 5598

INFINITI QX56 2011 Factory Service Manual
PWC-62
< SYMPTOM DIAGNOSIS >
DRIVER SIDE POWER WINDOW ALONE DOES NOT OPERATE
DRIVER SIDE POWER WINDOW ALONE DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000006217321
1.CHECK DRIVER SIDE POWER WINDO

Page 4148 of 5598

INFINITI QX56 2011 Factory Service Manual
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
PWC-63
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
WHEN POWER WINDOW MAIN SWITCH IS

FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
PWC-63
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
WHEN POWER WINDOW MAIN SWITCH IS OPERATED
WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure
INFOID:0000000006217322
1.CHECK FRONT POWER WINDOW SWITCH (PA SSENGER SIDE) SERIAL LINK CIRCUIT
Check front power window switch (passenger side) serial link circuit.
Refer to PWC-56, "
FRONT POWER WINDOW SWITCH (PASSENGE R SIDE) : Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> GO TO 1.
WHEN FRONT POWER WINDOW SWIT CH (PASSENGER SIDE) IS OPERATED
WHEN FRONT POWER WINDOW SWITCH (P ASSENGER SIDE) IS OPERATED :
Diagnosis Procedure
INFOID:0000000006217323
1.REPLACE FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
Replace front power window switch (passenger side).
Refer to PWC-74, "
Removal and Installation"
>> INSPECTION END
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW
SWITCH ARE OPERATED
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW
SWITCH ARE OPERATED : Diagnosis Procedure
INFOID:0000000006217324
1.CHECK FRONT POWER WINDOW SWITCH (PASSENGE R SIDE) POWER SUPPLY AND GROUND CIR-
CUIT
Check front power window switch (passenger side) power supply and ground circuit.
Refer to PWC-36, "
FRONT POWER WINDOW SWITCH (PASSEN GER SIDE) : Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK PASSENGER SIDE PO WER WINDOW MOTOR CIRCUIT
Check passenger side power window motor circuit.
Refer to PWC-40, "
PASSENGER SIDE : Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> GO TO 1.
Revision: 2010 May2011 QX56

Page 4149 of 5598

INFINITI QX56 2011 Factory Service Manual
PWC-64
< SYMPTOM DIAGNOSIS >
REAR LH SIDE POWER WINDOW ALONE DOES NOT OPERATE
REAR LH SIDE POWER WINDOW ALONE DOES NOT OPERATE
WHEN POWER WINDOW MAIN SWITCH IS OPERATED
WHEN POWER WINDOW MAIN SWITCH

Page 4150 of 5598

INFINITI QX56 2011 Factory Service Manual
REAR RH SIDE POWER WINDOW ALONE DOES NOT OPERATE
PWC-65
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REAR RH SIDE POWER WINDOW ALONE DOES NOT OPERATE
WHEN POWER WINDOW MAIN SWITCH IS OPER

Page 4151 of 5598

INFINITI QX56 2011 Factory Service Manual
PWC-66
< SYMPTOM DIAGNOSIS >
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATE NORMAL-LY
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATE NOR-
MALLY
DRIVER SIDE
DRIVER SIDE : Diagnosis ProcedureIN

Page 4152 of 5598

INFINITI QX56 2011 Factory Service Manual
AUTO OPERATION DOES NOT OPERATE BUT MANUAL OPERATE NORMAL-
LY
PWC-67
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
Refer to PWC-33, "Work Procedure"
Is the inspection result normal?
YES >>
