REAR A/C CONTROL COMMUNICATION SIGNAL
HAC-127
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR A/C CONTROL COMMUNICATION SIGNAL
Diagnosis ProcedureINFOID:0000000006275975
1.CHECK COMMUNICATION SIGNAL CIRCUIT (A/C AUTO AMP. → REAR A/C CONTROL) FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect rear A/C contro l and A/C auto amp. connector.
3. Check continuity between rear A/C control har ness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK COMMUNICATION SIGNAL CIRCUIT (A/C AUTO AMP. → REAR A/C CONTROL) FOR SHORT
Check continuity between rear A/ C control harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK COMMUNICATION SIGNAL CIRCUIT (REAR A/C CONTROL → A/C AUTO AMP.) CIRCUIT FOR
OPEN
Check continuity between rear A/C control har ness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK COMMUNICATION SIGNAL CIRCUIT (REAR A/C CONTROL → A/C AUTO AMP.) CIRCUIT FOR
SHORT
Check continuity between rear A/ C control harness connector and ground.
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Repair harness or connector.
Rear A/C control A/C auto amp. Continuity
Connector Terminal Connector Terminal
M419M5011 Existed
Rear A/C control —Continuity
Connector Terminal
M41 9 Ground Not existed
Rear A/C control A/C auto amp. Continuity
Connector Terminal Connector Terminal
M4110M5031 Existed
Rear A/C control —Continuity
Connector Terminal
M41 10 Ground Not existed
Revision: 2010 May2011 QX56
Page 3234 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-128
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR A/C SOLENOID VALVE
REAR A/C SOLENOID VALVE
Diagnosis ProcedureINFOID:0000000006275976
1.CHECK FUSE
1. Turn ignition switch OFF.
2. C INFINITI QX56 2011 Factory Service Manual
HAC-128
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR A/C SOLENOID VALVE
REAR A/C SOLENOID VALVE
Diagnosis ProcedureINFOID:0000000006275976
1.CHECK FUSE
1. Turn ignition switch OFF.
2. C](/manual-img/42/57033/w960_57033-3233.png)
HAC-128
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR A/C SOLENOID VALVE
REAR A/C SOLENOID VALVE
Diagnosis ProcedureINFOID:0000000006275976
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 10A fuse [No.4, located in fuse block (J/B)]. NOTE:
Refer to PG-140, "
Fuse, Connector and Terminal Arrangement".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK REAR A/C SOLENOID VALVE POWER SUPPLY
1. Disconnect rear A/C solenoid valve connector.
2. Turn ignition switch ON and front air conditioning system ON.
3. Check voltage between rear A/C solenoid valve harness connector and ground when rear blower motor is operated.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK REAR A/C SOLENOID VALVE GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between rear A/C solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> Replace rear expansion valve assembly. Refer to HA-49, "EXPANSION VALVE : Removal and
Installation".
NO >> Repair harness or connector.
4.CHECK REAR A/C RELAY POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect rear A/C relay connector.
3. Turn ignition switch ON.
4. Check voltage between rear A/C relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
+
−Condition Vo l ta g e
(Approx.)
Rear A/C solenoid valve
Connector Terminal
B207 1 Ground Rear blower motor ON Battery voltage
OFF 0 V
Rear A/C sole noid valve
—Continuity
Connector Terminal
B207 2 Ground Existed
+ −Vol tag e
(Approx.)
Rear A/C relay
Connector Terminal
E87 1
Ground Battery voltage
3
Revision: 2010 May2011 QX56
Page 3235 of 5598
![INFINITI QX56 2011 Factory Service Manual
REAR A/C SOLENOID VALVEHAC-129
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
NO >> Repair harness or connector between rear A/C relay and fuse block (J/B).
INFINITI QX56 2011 Factory Service Manual
REAR A/C SOLENOID VALVEHAC-129
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
NO >> Repair harness or connector between rear A/C relay and fuse block (J/B).](/manual-img/42/57033/w960_57033-3234.png)
REAR A/C SOLENOID VALVEHAC-129
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
NO >> Repair harness or connector between rear A/C relay and fuse block (J/B).
5.CHECK REAR A/C RERAY CONTROL CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect A/C auto amp. connector.
3. Check continuity between rear A/C relay har ness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair harness or connector.
6.CHECK REAR A/C RELAY CONTROL CIRCUIT FOR SHORT
Check continuity between rear A/C relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair harness or connector.
7.CHECK REAR A/C SOLENOID VALVE POWER SUPPLY CIRCUIT
Check continuity between rear A/C relay harness c onnector and rear A/C solenoid valve harness connector.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair harness or connector.
8.CHECK REAR A/C RELAY
Check rear A/C relay. Refer to HAC-129, "
Component Inspection".
Is the inspection result normal?
YES >> Replace A/C auto amp.. Refer to HAC-146, "Removal and Installation".
NO >> Replace rear A/C relay.
Component InspectionINFOID:0000000006275977
1.CHECK REAR A/C RELAY
1. Remove rear A/C relay.
Rear A/C relay A/C auto amp. Continuity
Connector Terminal Connector Terminal
E87 2 M50 38 Existed
Rear A/C relay —Continuity
Connector Terminal
E87 2 Ground Not existed
Rear A/C relay Rear A/C solenoid valve Continuity
Connector Terminal Connector Terminal
E87 5 B207 1 Existed
Revision: 2010 May2011 QX56
Page 3236 of 5598
HAC-130
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR A/C SOLENOID VALVE
2. Check continuity between the r
ear A/C relay terminal 3 and 5
when the voltage is supplied between terminal 1 and 2.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace rear A/C relay.
Blower relay Voltage Continuity
Te r m i n a l
35 ON Existed
OFF Not existed
JSIIA1551ZZ
Revision: 2010 May2011 QX56
Page 3237 of 5598
![INFINITI QX56 2011 Factory Service Manual
REAR BLOWER MOTORHAC-131
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR BLOWER MOTOR
Diagnosis ProcedureINFOID:0000000006275978
1.CHECK FUSE
1. Turn ign INFINITI QX56 2011 Factory Service Manual
REAR BLOWER MOTORHAC-131
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR BLOWER MOTOR
Diagnosis ProcedureINFOID:0000000006275978
1.CHECK FUSE
1. Turn ign](/manual-img/42/57033/w960_57033-3236.png)
REAR BLOWER MOTORHAC-131
< DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR BLOWER MOTOR
Diagnosis ProcedureINFOID:0000000006275978
1.CHECK FUSE
1. Turn ignition switch OFF.
2. Check 20A fuse [No. 16, located in fuse block (J/B)]. NOTE:
Refer to PG-140, "
Fuse, Connector and Terminal Arrangement".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the blown fuse after repairing the affected circuit if a fuse is blown.
2.CHECK REAR BLOWER MOTOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect rear blower motor connector.
3. Turn ignition switch ON.
4. Check voltage between rear blower motor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector between rear blower motor and fuse block (J/B).
3.CHECK REAR BLOWER MOTOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between rear blower motor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK REAR BLOWER MOTOR CONTROL SIGNAL CIRCUIT
1. Disconnect A/C auto amp. connector.
2. Check continuity between rear blower motor harness connector and A/C auto amp. harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair harness or connector.
5.CHECK REAR BLOWER MOTOR CONTROL SIGNAL
1. Reconnect rear blower motor connector and A/C auto amp. connector.
2. Turn ignition switch ON.
3. Operate MODE switch to set air outlet to VENT.
+
−Vol tag e
Rear blower motor
Connector Terminal M302 1 Ground Battery voltage
Rear blower motor —Continuity
Connector Terminal
M302 3 Ground Existed
Rear blower motor A/C auto amp. Continuity
Connector Terminal Connector Terminal
M302 2 M50 34 Existed
Revision: 2010 May2011 QX56
Page 3238 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-132
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR BLOWER MOTOR
4. Change fan speed from Lo to Hi, and check duty rati
os between rear blower motor harness connector and
ground by usi INFINITI QX56 2011 Factory Service Manual
HAC-132
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR BLOWER MOTOR
4. Change fan speed from Lo to Hi, and check duty rati
os between rear blower motor harness connector and
ground by usi](/manual-img/42/57033/w960_57033-3237.png)
HAC-132
< DTC/CIRCUIT DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR BLOWER MOTOR
4. Change fan speed from Lo to Hi, and check duty rati
os between rear blower motor harness connector and
ground by using an oscilloscope.
NOTE:
Calculate drive signal duty ratio as shown in the figure.
T2 = Approx. 1.6 ms
Is the inspection result normal?
YES >> Replace rear blower motor. Refer to VTL-16, "REAR A/C UNIT ASSEMBLY : Removal and Instal-
lation".
NO >> Replace A/C auto amp.. Refer to HAC-146, "
Removal and Installation".
Component InspectionINFOID:0000000006275979
1.CHECK REAR BLOWER MOTOR-I
1. Remove rear blower motor.
2. Check that there is not any mixing foreign object in the rear blower motor.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace rear blower motor. Refer to VTL-16, "
REAR A/C UNIT ASSEMBLY : Removal and Instal-
lation".
2.CHECK REAR BLOWER MOTOR-II
Check that there is not breakage or damage in the rear blower motor.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace rear blower motor. Refer to VTL-16, "
REAR A/C UNIT ASSEMBLY : Removal and Instal-
lation".
3.CHECK REAR BLOWER MOTOR-III
Check that rear blower motor turns smoothly.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace rear blower motor. Refer to VTL-16, "
REAR A/C UNIT ASSEMBLY : Removal and Instal-
lation".
Rear blower motor Condition
Duty ratio
(Approx.)
Connector Terminal Fan speed (manual)
VENT mode
M272 2 1st 25 %
2nd 33 % 3rd 41 %4th 51 %
5th 61 %
6th 69 %
7th 81 %
JPLIA1210GB
Revision: 2010 May2011 QX56
Page 3239 of 5598
![INFINITI QX56 2011 Factory Service Manual
FRONT AUTOMATIC AIR CONDITIONING SYSTEMHAC-133
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
SYMPTOM DIAGNOSIS
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
Diagnosis INFINITI QX56 2011 Factory Service Manual
FRONT AUTOMATIC AIR CONDITIONING SYSTEMHAC-133
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
SYMPTOM DIAGNOSIS
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
Diagnosis](/manual-img/42/57033/w960_57033-3238.png)
FRONT AUTOMATIC AIR CONDITIONING SYSTEMHAC-133
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
SYMPTOM DIAGNOSIS
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
Diagnosis Chart By SymptomINFOID:0000000006275980
NOTE:
Perform the self-diagnoses with CONSULT-III before per forming the symptom diagnosis. If DTC is detected,
perform the corresponding diagnosis.
Symptom Corresponding malfunction part Reference
Front air conditioning system does not activate.
Front air conditioning system cannot be con-
trolled.
Operation status of front air conditioning system is
not indicated on front dis-
play. Fail-safe activates Multi AV system
AV- 1 9 9 , "
Symptom Table"
Fail-safe does not acti-
vate Power supply system of A/C auto
amp.
A/C auto amp. HAC-110, "A/C AUTO AMP. : Diag-
nosis Procedure"
Air outlet does not change (Except upper ventila-
tion).
Front mode door motor does not operate normally. Circuit between front mode door
motor and A/C auto amp.
Front mode door motor control link-
age
Front mode door motor
A/C auto amp. HAC-112, "FRONT MODE DOOR
MOTOR : Diagnosis Procedure"
Upper ventilator door does not change.
Upper ventilator door motor does not operate nor-
mally. Circuit between upper ventilator
door motor and A/C auto amp.
Upper ventilator door motor installa- tion condition
Upper ventilator door motor
A/C auto amp. HAC-116, "UPPER VENTILATOR
DOOR MOTOR : Diagnosis Proce-
dure"
Discharge air temperature of driver side does not
change.
Front air mix door motor (driver side) does not op-
erate normally. Circuit between front air mix door
motor (driver side ) and A/C auto
amp.
Front air mix door motor (driver side)
installation condition
Front air mix door motor (driver side)
A/C auto amp. HAC-110, "FRONT AIR MIX DOOR
MOTOR (DRIVER SIDE) : Diagno-
sis Procedure"
Discharge air temperature of passenger side does
not change.
Front air mix door motor (passenger side) does not
operate normally. Circuit between front air mix door
motor (passenger side) and A/C
auto amp.
Front air mix door motor (passenger side) installation condition
Front air mix door motor (passenger side)
A/C auto amp. HAC-111, "FRONT AIR MIX DOOR
MOTOR (PASSENGER SIDE) : Di-
agnosis Procedure"
Intake door does not change.
Intake door motor does not operate normally.
Circuit between intake door motor
and A/C auto amp.
Intake door motor control linkage
Intake door motor
A/C auto amp. HAC-113, "INTAKE DOOR MOTOR
: Diagnosis Procedure"
All door motors do not operate normally.
Each door motor power supply and
ground circuit
A/C auto amp. HAC-118, "Diagnosis Procedure"
Front blower motor operation is malfunctioning. Power supply system of front blower
motor
Circuit between front blower motor and A/C auto amp..
Front blower motor
A/C auto amp. HAC-121, "Diagnosis Procedure"
Revision: 2010 May2011 QX56
Page 3240 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-134
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
Compressor does not operate. Circuit between magnet clutch and
IPDM E/R
Magnet clutch
IPDM E/R INFINITI QX56 2011 Factory Service Manual
HAC-134
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
Compressor does not operate. Circuit between magnet clutch and
IPDM E/R
Magnet clutch
IPDM E/R](/manual-img/42/57033/w960_57033-3239.png)
HAC-134
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
Compressor does not operate. Circuit between magnet clutch and
IPDM E/R
Magnet clutch
IPDM E/R (A/C relay)
Circuit between ECM and refriger- ant pressure sensor
Refrigerant pressure sensor
CAN communication circuit
A/C auto amp. HAC-142, "Diagnosis Procedure"
Insufficient cooling.
No cool air comes out. (Air flow volume is normal.)
Magnet clutch control system
Drive belt slipping
Refrigerant cycle
Air leakage from each duct
A/C auto amp. connection recogni-
tion signal circuit
Temperature settin g trimmer (front)HAC-138, "FRONT AIR CONDI-
TIONER : Diagnosis Procedure"
Insufficient heating.
No warm air comes out. (Air flow volume is nor-
mal.) Engine cooling system
Heater hose
Heater core
Air leakage from each duct
Temperature settin
g trimmer (front)HAC-140, "FRONT AIR CONDI-
TIONER : Diagnosis Procedure"
Noise is heard when front
air conditioning system op-
erates. During compressor
operation
Refrigerant cycle
HA-27, "
Symptom Table"
During front blower
motor operation Mixing any foreign object in front
blower motor
Front blower motor fan breakage
Front blower motor rotation inferiori- ty HAC-122, "Component Inspection
(Front Blower Motor)"
Memory function does not operate.
Setting temperature is not memorized.
Battery power supply system of A/C
auto amp.
A/C auto amp. HAC-110, "A/C AUTO AMP. : Diag-
nosis Procedure"
Symptom Corresponding malfunction part Reference
Revision: 2010 May2011 QX56
