2011 INFINITI QX56 Factory Service Manual

jump start terminals jacking handbrake gas tank size coolant tailgate

Page 4433 of 5598

INFINITI QX56 2011 Factory Service Manual
C1802 AIR SUS COMPRS RELAYSCS-73
< DTC/CIRCUIT DIAGNOSIS > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
3. Check continuity between air levelizer control module harness connector

Page 4434 of 5598

INFINITI QX56 2011 Factory Service Manual
SCS-74
< DTC/CIRCUIT DIAGNOSIS >[AIR LEVELIZER CONTROL SYSTEM]
C1803 AIR SUSPENSION EXH SOL
C1803 AIR SUSPENSION EXH SOL
DTC LogicINFOID:0000000006256067
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDUR

SCS-74
< DTC/CIRCUIT DIAGNOSIS >[AIR LEVELIZER CONTROL SYSTEM]
C1803 AIR SUSPENSION EXH SOL
C1803 AIR SUSPENSION EXH SOL
DTC LogicINFOID:0000000006256067
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previous ly conducted, always turn ignition switch OFF
andwait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON and wait 10 seconds or more.
2. Select “EXHAUST SOLENOID” in “Active Test” in “E-SUS”.
3. Touch “ON” and wait 5 seconds or more.
4. Select “Self Diagnostic Result” in “E-SUS”.
Is
“C1803” detected ?
YES >> Go to SCS-74, "DiagnosisProcedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006256068
1.CHECK EXHAUST SOLENOID ON SIGNAL FROM AIR LEVELIZER CONTROL MODULE
CONSULT-III
1. Disconnect air compressor harness connector.
2. Turn ignition switch ON. CAUTION:
Never start the engine.
3. Select “EXHAUST SOLENOID” in “Active Test” in “E-SUS”.
4. Touch “ON”.
5. While operating test item, check voltage bet ween air compressor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN AIR LEVELIZE R CONTROL MODULE AND AIR COMPRESSOR
1. Turn ignition switch OFF.
2. Disconnect air levelizer control module harness connector.
DTC Display item Malfunction detected condition Possible cause
C1803 AIR SUS EXH SOL Output voltage of the exhaust solenoid remains 9 V
or less continuously for 5 seconds during exhaust
solenoid ON signal output by the air levelizer con-
trol module.
Output voltage of the exhaust solenoid remains 2 V
or more continuously for 10 seconds during ex-
haust solenoid ON signal output by the air levelizer
control module. Harness or connector
Exhaust solenoid
Air levelizer control module
Air compressor
—Voltage
Connector Terminal
C12 4 Ground 9 – 16 V
Revision: 2010 May2011 QX56

Page 4435 of 5598

INFINITI QX56 2011 Factory Service Manual
C1803 AIR SUSPENSION EXH SOLSCS-75
< DTC/CIRCUIT DIAGNOSIS > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
3. Check continuity between air levelizer contro l module harness connect

Page 4436 of 5598

INFINITI QX56 2011 Factory Service Manual
SCS-76
< DTC/CIRCUIT DIAGNOSIS >[AIR LEVELIZER CONTROL SYSTEM]
C1803 AIR SUSPENSION EXH SOL
2. Insert resin stick (A) 4.7 mm (0
.185 in) in diameter into either
one of the air compressor air tube hol

Page 4437 of 5598

INFINITI QX56 2011 Factory Service Manual
C1804 VHCL HEIGHT ADJ UPSCS-77
< DTC/CIRCUIT DIAGNOSIS > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
C1804 VHCL HEIGHT ADJ UP
DTC LogicINFOID:0000000006256070
DTC DETECTION LOGIC

C1804 VHCL HEIGHT ADJ UPSCS-77
< DTC/CIRCUIT DIAGNOSIS > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
C1804 VHCL HEIGHT ADJ UP
DTC LogicINFOID:0000000006256070
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previous ly conducted, always turn ignition switch OFF
andwait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Set vehicle in the unloaded vehicle status.
2. Start the engine and wait 150 seconds or more.
3. Perform “Self Diagnostic Result” in “E-SUS”.
Is
“C1804” detected ?
YES >> Go to SCS-77, "DiagnosisProcedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006256071
1.CHECK APPEARANCE
Visually check for malfunction of suspension component s, damage of air chamber of rear shock absorber,
installation malfunction, or defo rmation of vehicle height sensor.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repaire or replace damaged parts.
2.CHECK AIR LEAK
Apply soapy water to air tube, connecting portions between air tube and each component, and air chamber of
rear shock absorber. Check for air leakage.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repaire or replace damaged parts.
3.CHECK AIR COMPRESSOR RELAY POWER SUPPLY
1. Turn ignition switch OFF.
2. Check 30A fuse (#I).
3. Disconnect air compressor relay connector.
4. Check voltage between air compressor relay harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1804 VHCL HEIGHT ADJ UP The vehicle height is 15 mm (0.59 in) or more lower
than the reference height despite the output of air
compressor ON signal continuously for 120 seconds
by the air levelizer control module. Harness or connector
Air compressor
Air compressor relay
Air levelizer control module
Rear shock absorber (air cham-
ber)
Vehicle height sensor
Air tube
Rear suspension component parts
Overloaded
Revision: 2010 May2011 QX56

Page 4438 of 5598

INFINITI QX56 2011 Factory Service Manual
SCS-78
< DTC/CIRCUIT DIAGNOSIS >[AIR LEVELIZER CONTROL SYSTEM]
C1804 VHCL HEIGHT ADJ UP
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged part.
4.CHECK AIR COMPRESSOR

Page 4439 of 5598

INFINITI QX56 2011 Factory Service Manual
C1804 VHCL HEIGHT ADJ UPSCS-79
< DTC/CIRCUIT DIAGNOSIS > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
NO >> Repair or replace damaged part.
Component Inspection (A ir Compressor R

Page 4440 of 5598

INFINITI QX56 2011 Factory Service Manual
SCS-80
< DTC/CIRCUIT DIAGNOSIS >[AIR LEVELIZER CONTROL SYSTEM]
C1805 VHCL HE
IGHT ADJ DOWN
C1805 VHCL HEIGHT ADJ DOWN
DTC LogicINFOID:0000000006256074
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1

Load next 8 pages
