Page 4945 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-152
< DTC/CIRCUIT DIAGNOSIS >
B1182 LAP PRE-TENSIONER LH
B1182 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220100
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1.

Page 4946 of 5598

INFINITI QX56 2011 Factory Service Manual
B1183 LAP PRE-TENSIONER LHSRC-153
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1183 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220102
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNO

B1183 LAP PRE-TENSIONER LHSRC-153
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1183 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220102
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-149, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220103
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-149, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-149, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1183 PRE-TEN2 FRONT LH [VB-SHORT] Lap pre-tensioner LH circuit is shorted
to some power supply circuit Harness or connectors
(Lap pre-tensioner circuit is shorted.)
Malfunction in lap pre-tensioner LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4947 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-154
< DTC/CIRCUIT DIAGNOSIS >
B1184 LAP PRE-TENSIONER LH
B1184 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220104
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1.

SRC-154
< DTC/CIRCUIT DIAGNOSIS >
B1184 LAP PRE-TENSIONER LH
B1184 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220104
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-150, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220105
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-150, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-150, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1184 PRE-TEN2 FRONT LH [GND-SHORT] Lap pre-tensioner LH circuit is shorted to
ground Harness or connectors
(Lap pre-tensioner circuit is shorted.)
Malfunction in lap pre-tensioner LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4948 of 5598

INFINITI QX56 2011 Factory Service Manual
B1185 LAP PRE-TENSIONER LHSRC-155
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1185 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220106
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNO

B1185 LAP PRE-TENSIONER LHSRC-155
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1185 LAP PRE-TENSIONER LH
DTC LogicINFOID:0000000006220106
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSTIC RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-151, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220107
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE LAP PRE-TENSIONER LH
1. Replace lap pre-tensioner LH. Refer to SB-6, "
SEAT BELT RETRACTOR : Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-151, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-151, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1185 PRE-TEN2 FRONT LH [SHORT] Lap pre-tensioner LH circuit are shorted
to each other Harness or connectors
(Lap pre-tensioner circuit is shorted.)
Malfunction in lap pre-tensioner LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4949 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-156
< DTC/CIRCUIT DIAGNOSIS >
B1186, B1187, B1188, B1189, B1190, B1191 DIAGNOSIS SENSOR UNIT
B1186, B1187, B1188, B1189, B1190, B1191 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006220108
DTC D

Page 4950 of 5598

INFINITI QX56 2011 Factory Service Manual
B1193 CURTAIN AIR BAG MODULE RHSRC-157
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1193 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220110
DTC DETECTION LOGIC
DTC CONFIRMATION

B1193 CURTAIN AIR BAG MODULE RHSRC-157
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1193 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220110
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-157, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220111
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-157, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module RH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-157, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1193 CURTAIN MODULE RH
[OPEN] Front curtain air bag module RH circuit is
open Disconnection of wiring harness and open
Malfunction in front curtain air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4951 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-158
< DTC/CIRCUIT DIAGNOSIS >
B1193 CURTAIN AIR BAG MODULE RH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4952 of 5598

INFINITI QX56 2011 Factory Service Manual
B1194 CURTAIN AIR BAG MODULE RHSRC-159
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1194 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220112
DTC DETECTION LOGIC
DTC CONFIRMATION

B1194 CURTAIN AIR BAG MODULE RHSRC-159
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1194 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220112
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-159, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220113
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-159, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module RH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-159, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1194 CURTAIN MODULE RH
[VB-SHORT] Frount curtain air bag module RH circuit
is shorted to power supply circuit Disconnection of wiring harness and short
Malfunction in frount curtain air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Load next 8 pages

Page: < prev 1-10 ... 4913-4920 4921-4928 4929-4936 4937-4944 4945-4952 4953-4960 4961-4968 4969-4976 4977-4984 ... 5600 next >

rear entertainment alternator belt android auto run flat torque power steering
