WW-50
< SYMPTOM DIAGNOSIS >
WIPER AND WASHER SYSTEM SYMPTOMS
Front wiper does not
stopHI only
Combination switch
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
Front wiper request signal
BCM
IPDM E/R IPDM E/R DATA MONITOR
“FR WIP REQ”
IPDM E/R —
LO only Combination switch
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
Front wiper request signal
BCM
IPDM E/R IPDM E/R DATA MONITOR
“FR WIP REQ”
IPDM E/R —
INT (AUTO) only Combination switch
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
Front wiper request signal
BCM
IPDM E/R IPDM E/R DATA MONITOR
“FR WIP REQ”
Front wiper does not
operate normally Sensitivity adjustment
cannot be performed.
Combination switch
Harness between combination switch and BCM
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
BCM —
Auto wiping operation
does not operate Check that the wiper setting is auto wiping operation
Refer to
WW-15, "
WIPER : CONSULT-III Function (BCM - WIPER)".
Intermittent control
linked with vehicle
speed cannot be per-
formed Check that the wiper setting is linked with vehicle speed
Refer to
WW-15, "
WIPER : CONSULT-III Function (BCM - WIPER)".
Wiper is not linked to
the washer operation. Combination switch
Harness between combination switch and BCM
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
BCM —
Does not return to stop
position. [Repeatedly
operates for 10 sec-
onds and then stops
for 20 seconds. (Fail-
safe)] IPDM E/R
Harness between IPDM E/R and front wiper
motor
Front wiper motor Front wiper auto stop signal
circuit
Refer to
WW-38, "
Compo-
nent Function Check"
Rear wiper does not
operate ON only
Combination switch
Harness between combination switch and BCM
BCM Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
INT only Combination switch
Harness between combination switch and BCM
BCM Combination switch
Refer to
BCS-80, "Symptom
Ta b l e"
ON and INT Combination switch
Harness between combination switch and BCM
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
BCM
Harness between rear wiper motor and BCM
Harness between rear wiper motor and ground
Rear wiper motor Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
Symptom Probable malfunction location Inspection item
Revision: 2010 May2011 QX56
Page 5570 of 5598

WIPER AND WASHER SYSTEM SYMPTOMSWW-51
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Rear wiper does not
stop ON only
Combination switch
BCM Rear wiper motor circuit
Refer to
WW-43, "
Compo-
nent Function Check".
INT only Combination switch
BCM Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
Rear wiper does not
operate normally Wiper is not linked to
the washer operation.
Combination switch
Harness between rear wiper motor and BCM
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
BCM —
Rear wiper does not
return to the stop posi-
tion. [Stops after a five-
second operation.
(Fail-safe)] BCM
Harness between rear wiper motor and BCM
Rear wiper motor
Rear wiper auto stop signal
circuit
Refer to
WW-45, "
Compo-
nent Function Check"
Rear wiper does not
operate even when
shift lever is shifted to
the “R”. Check the linked with reverse rear wiper setting.
Refer to
WW-15, "WIPER : CONSULT-III Function (BCM - WIPER)".
NOTE:
Factory setting of the rear wiper operation is operation linked with reverse.
Shift position signal (CAN communication)
BCM
TCM TCM DATA MONITOR
″
SLCT LVR POSI ″
Headlamp washer
does not operate. Headlamp washer
does not operate with
the front washer when
headlamps are turned
ON. Combination switch
Harness between combination switch and BCM
BCM
Combination switch
Refer to
BCS-80, "
Symptom
Ta b l e"
Fusible link
Harness between fusible link and headlamp
washer relay
Headlamp washer relay
Harness between haedlamp washer relay and IPDM E/R
IPDM E/R
Harness between haedlamp washer relay and headlamp washer pump
headlamp washer pump
Harness between haedlamp washer pump and ground Headlamp washer circuit
Refer to
WW-47, "
Compo-
nent Function Check"
BCM —
Symptom Probable malfunction location Inspection item
Revision: 2010 May2011 QX56
Page 5571 of 5598
WW-52
< SYMPTOM DIAGNOSIS >
NORMAL OPERATING CONDITION
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006300483
FRONT WIPER MOTOR PROTECTION FUNCTION
IPDM E/R may stop the front wiper to protect the front wiper motor if any obstruction (operation resistance)
such as a large amount of snow is detected during the front wiper operation.
At that time turn OFF the front wiper and remove t he foreign object. Then wait for approximately 20 seconds
or more and reactivate the front wiper. The wiper will operate normally.
REAR WIPER MOTOR PROTECTION FUNCTION
BCM may stop rear wiper to protect the rear wiper motor when the rear wiper is stopped for 5 seconds or
more due to a snowfall.
Rear wiper operates normally one minute after t he obstacles are removed with rear wiper OFF.
Revision: 2010 May2011 QX56
Page 5572 of 5598

FRONT WIPER DOES NOT OPERATEWW-53
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
FRONT WIPER DO ES NOT OPERATE
DescriptionINFOID:0000000006300484
The front wiper does not operate under any operation conditions.
Diagnosis ProcedureINFOID:0000000006300485
1.CHECK WIPER RELAY OPERATION
CONSULT-III ACTIVE TEST
1. Select “FRONT WIPER” of IPDM E/R active test item.
2. With operating the test item, check front wiper operation.
Is front wiper operation normally?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK FRONT WIPER MOTOR FUSE
Check front wiper motor fuse. Refer to WW-35, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the fuse after repairing the applicable circuit.
3.CHECK FRONT WIPER MOTOR GROUND CIRCUIT
Check front wiper motor ground circuit. Refer to WW-39, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK FRONT WIPER MOTOR INPUT VOLTAGE
CONSULT-III ACTIVE TEST
1. Turn ignition switch OFF.
2. Disconnect front wiper motor connector.
3. Turn ignition switch ON.
4. Select “FRONT WIPER” of IPDM E/R active test item.
5. With operating the test item, check voltage between front wiper motor harness connector and ground.
Is the inspection result normal?
YES >> Replace front wiper motor.
NO >> Replace IPDM E/R.
5.CHECK FRONT WIPER REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select “FR WIP REQ” of IPDM E/R data monitor item.
2. Switch the front wiper switch to HI and LO. Lo : Front wiper LO operation
Hi : Front wiper HI operation
Off : Stop the front wiper.
(+)
(− ) Condition Voltage (Approx.)
Front wiper motor
Connector Terminal
E42 1
Ground FRONT WIPER Lo Battery voltage
Off 0 V
4 Hi Battery voltage
Off 0 V
Revision: 2010 May2011 QX56
Page 5573 of 5598
WW-54
< SYMPTOM DIAGNOSIS >
FRONT WIPER DOES NOT OPERATE
3. With operating the front wiper switch, check the status of “FR WIP REQ”.
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> GO TO 6.
6.CHECK COMBINATION SWITCH
Perform the inspection of the combination switch. Refer to BCS-80, "
Symptom Table".
Is combination switch normal?
YES >> Replace BCM. Refer to BCS-81, "Removal and Installation".
NO >> Repair or replace the applicable parts.
Monitor item Condition Monitor status
FR WIP REQ Front wiper switch HI
On Hi
Off Stop
Front wiper switch LO On Low
Off Stop
Revision: 2010 May2011 QX56
Page 5574 of 5598
HEADLAMP WASHER NOZZLE AND TUBEWW-55
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
REMOVAL AND INSTALLATION
HEADLAMP WASHER NOZZLE AND TUBE
Exploded ViewINFOID:0000000006220393
Hydraulic LayoutINFOID:0000000006220394
1. Headlamp washer nozzle cover 2. Headlamp washer nozzle assembly 3. Headlamp washer nozzle retainer
4. Headlamp washer nozzle bracket 5. Front bumper fascia : Pawl
JMLIA1096ZZ
1. Headlamp washer nozzle assembly LH 2. Headlamp washer tube 3. Headlamp washer tube (tank side)
4. Headlamp washer nozzle assembly RH 5. Front bumper fascia
A. Metal clip
JMLIA1097ZZ
Revision: 2010 May2011 QX56
Page 5575 of 5598

WW-56
< REMOVAL AND INSTALLATION >
HEADLAMP WASHER NOZZLE AND TUBE
Removal and Installation
INFOID:0000000006220395
REMOVAL
1. Pull out headlamp washer nozzle from bumper fascia, disen- gage pawl (A), and then remove headlamp washer nozzle cover
(1).
2. Remove front bumper fascia. Refer to EXT-13, "
Removal and Installation".
3. Disconnect headlamp washer tube joint.
4. Remove headlamp washer nozzle retainer.
5. Remove headlamp washer nozzle bracket.
6. Remove headlamp washer nozzle from the front bumper fascia.
INSTALLATION
Install in the reverse order of removal.
InspectionINFOID:0000000006220396
HEADLAMP WASHER NOZZLE SPRAY POSITION INSPECTION
CAUTION:
Replace headlamp washer nozzle assembly with a new pa rt if headlamp washer jet position is outside
the headlamp illumination area shown in the figure.
Check that headlamp washer injection is certainly on headlamp
illumination area.
Check the headlamp washer injection range as shown in the fig- ure.
JPLIA1030ZZ
JMLIA1098ZZ
a : 67.8 mm (2.31 in)
B : 83.2 mm (3.04 in)
C : 316.2 mm (12.13 in)
JMLIA1099ZZ
Revision: 2010 May2011 QX56
Page 5576 of 5598
HEADLAMP WASHER NOZZLE AND TUBEWW-57
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Check the headlamp washer nozzle spray angle.
