INFINITI QX56 2011 Factory Service Manual WW-58 < REMOVAL AND INSTALLATION > WASHER TANK WASHER TANK Exploded ViewINFOID:0000000006220397 Removal and InstallationINFOID:0000000006220398 REMOVAL 1. Fully open hood. 2. Remove washer tank inle

Page 5578 of 5598

INFINITI QX56 2011 Factory Service Manual WASHER TANKWW-59 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P 11. Pull washer tank (1) out of body panel bracket (2) to remove from the vehicle. INSTALLATION Note the following item,

Page 5579 of 5598

INFINITI QX56 2011 Factory Service Manual WW-60 < REMOVAL AND INSTALLATION > WASHER PUMP WASHER PUMP Exploded ViewINFOID:0000000006220399 Removal and InstallationINFOID:0000000006220400 REMOVAL 1. Remove washer tank. Refer to WW-58, "Removal

Page 5580 of 5598

INFINITI QX56 2011 Factory Service Manual HEADLAMP WASHER PUMPWW-61 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P HEADLAMP WASHER PUMP Exploded ViewINFOID:0000000006220401 Removal and InstallationINFOID:0000000006220402 REMOVA

Page 5581 of 5598

INFINITI QX56 2011 Factory Service Manual WW-62 < REMOVAL AND INSTALLATION > WASHER LEVEL SWITCH WASHER LEVEL SWITCH Removal and InstallationINFOID:0000000006220403 The washer level switch must be replaced together with the washer tank as an

Page 5582 of 5598

INFINITI QX56 2011 Factory Service Manual FRONT WASHER NOZZLE AND TUBEWW-63 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P FRONT WASHER NOZZLE AND TUBE Exploded ViewINFOID:0000000006220404 Hydraulic LayoutINFOID:000000000622040

Page 5583 of 5598

INFINITI QX56 2011 Factory Service Manual WW-64 < REMOVAL AND INSTALLATION > FRONT WASHER NOZZLE AND TUBE Removal and Installation INFOID:0000000006220406 REMOVAL 1. Remove cowl top cover. Refer to EXT-21, "Removal and Installation". 2. Dis

Page 5584 of 5598

INFINITI QX56 2011 Factory Service Manual FRONT WASHER NOZZLE AND TUBEWW-65 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P Unit: mm (in) Insert a needle or similar object (A) into the spray opening (1) and move up/down and left
