INFINITI QX56 2011 Factory Service Manual
SRC-160
< DTC/CIRCUIT DIAGNOSIS >
B1194 CURTAIN AIR BAG MODULE RH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4954 of 5598

INFINITI QX56 2011 Factory Service Manual
B1195 CURTAIN AIR BAG MODULE RHSRC-161
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1195 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220114
DTC DETECTION LOGIC
DTC CONFIRMATION

B1195 CURTAIN AIR BAG MODULE RHSRC-161
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1195 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220114
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-161, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220115
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-161, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module RH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-161, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1195 CURTAIN MODULE
RH
[GND-SHORT] Front curtain air bag module RH circuit is
shorted to ground Disconnection of wiring harness and short
Malfunction in front curtain air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4955 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-162
< DTC/CIRCUIT DIAGNOSIS >
B1195 CURTAIN AIR BAG MODULE RH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4956 of 5598

INFINITI QX56 2011 Factory Service Manual
B1196 CURTAIN AIR BAG MODULE RHSRC-163
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1196 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220116
DTC DETECTION LOGIC
DTC CONFIRMATION

B1196 CURTAIN AIR BAG MODULE RHSRC-163
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1196 CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000006220116
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-163, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220117
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-163, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module RH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-163, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1196 CURTAIN MODULE RH
[SHORT] Front curtain air bag module RH circuits are
shorted to each other Disconnection of wiring harness and short
Malfunction in front curtain air bag module RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4957 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-164
< DTC/CIRCUIT DIAGNOSIS >
B1196 CURTAIN AIR BAG MODULE RH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4958 of 5598

INFINITI QX56 2011 Factory Service Manual
B1198 CURTAIN AIR BAG MODULE LHSRC-165
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1198 CURTAIN AIR BAG MODULE LH
DTC LogicINFOID:0000000006220118
DTC DETECTION LOGIC
DTC CONFIRMATION

B1198 CURTAIN AIR BAG MODULE LHSRC-165
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1198 CURTAIN AIR BAG MODULE LH
DTC LogicINFOID:0000000006220118
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-165, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220119
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-165, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module LH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-165, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1198 CURTAIN MODULE LH
[OPEN] Front curtain air bag module LH circuit is
open Disconnection of wiring harness and open
Malfunction in front curtain air bag module LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4959 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-166
< DTC/CIRCUIT DIAGNOSIS >
B1198 CURTAIN AIR BAG MODULE LH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4960 of 5598

INFINITI QX56 2011 Factory Service Manual
B1199 CURTAIN AIR BAG MODULE LHSRC-167
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1199 CURTAIN AIR BAG MODULE LH
DTC LogicINFOID:0000000006220120
DTC DETECTION LOGIC
DTC CONFIRMATION

B1199 CURTAIN AIR BAG MODULE LHSRC-167
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1199 CURTAIN AIR BAG MODULE LH
DTC LogicINFOID:0000000006220120
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-167, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220121
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-167, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE FRONT CURTAIN AIR BAG MODULE
1. Replace front curtain air bag module LH. Refer to SR-19, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-167, "DTC Logic".
Is DTC detected?
YES >> GO TO 1.
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1199 CURTAIN MODULE LH
[VB-SHORT] Front curtain air bag module LH circuit is
shorted to power supply circuit Disconnection of wiring harness and short
Malfunction in front curtain air bag module LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56
