P2A00, P2A03 A/F SENSOR 1EC-489
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
8.CHECK A/F SENSOR 1 HEATER
Refer to EC-182, "
Component Inspection (A/F Sensor 1 Heater)".
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 10.
9.CHECK INTERMITTENT INCIDENT
Perform GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace malfunctioning part.
10.REPLACE AIR FUEL RATIO (A/F) SENSOR 1
Replace air fuel ratio (A/F) sensor 1. Refer to EX-5, "
Exploded View".
CAUTION:
Discard any A/F sensor which has been dropped from a height of more than 0.5 m (19.7 in) onto a
hard surface such as a concrete floor; use a new one.
Before installing new A/F senso r, clean exhaust system threads using Oxygen Sensor Thread
Cleaner [commercial service tool (J-43897-18 or J-43897-12)] and approved anti-seize lubricant
(commercial service tool).
Will CONSULT-III be used?
YES >> GO TO 11.
NO >> GO TO 12.
11 .CONFIRM A/F ADJUSTMENT DATA
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” and “A/F ADJ-B2” in “DATA MONITOR” mode with CONSULT-III.
3. Check that “0.000” is di splayed on CONSULT-III screen.
Is
“0.000” displayed?
YES >> INSPECTION END
NO >> GO TO 12.
12.CLEAR THE MIXTURE RATIO SELF-LEARNING VALUE
Clear the mixture ratio self-learning value. Refer to EC-152, "
Work Procedure".
Will CONSULT-III be used?
YES >> GO TO 13.
NO >> INSPECTION END
13.CONFIRM A/F ADJUSTMENT DATA
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “A/F ADJ-B1” and “A/F ADJ-B2” in “DATA MONITOR” mode with CONSULT-III.
3. Check that “0.000” is di splayed on CONSULT-III screen.
>> INSPECTION END
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P2A00 1 F67 6 F11094
Existed
P2A03 2 F68 6 74
Revision: 2010 May2011 QX56
Page 2514 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-490
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD BRAKE SWITCH
ASCD BRAKE SWITCH
Component Function CheckINFOID:0000000006217989
1.CHECK ASCD BRAKE SWITCH FUNCTION
WITH CONSULT-III
1. Turn ignition swit INFINITI QX56 2011 Factory Service Manual
EC-490
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD BRAKE SWITCH
ASCD BRAKE SWITCH
Component Function CheckINFOID:0000000006217989
1.CHECK ASCD BRAKE SWITCH FUNCTION
WITH CONSULT-III
1. Turn ignition swit](/manual-img/42/57033/w960_57033-2513.png)
EC-490
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD BRAKE SWITCH
ASCD BRAKE SWITCH
Component Function CheckINFOID:0000000006217989
1.CHECK ASCD BRAKE SWITCH FUNCTION
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DAT A MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
WITHOUT CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-490, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217990
1.CHECK ASCD BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ASCD brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
10 A fuse (No. 3)
Harness for open or short between ASCD brake switch and fuse
Loose or poor connection for each connector and harness
>> Repair open circuit or short to ground in harness or connectors.
3.CHECK ASCD BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ASCD brake s witch harness connector and ECM harness connector.
Monitor item Condition Indication
BRAKE SW1
(ASCD brake switch) Brake pedalSlightly depressed OFF
Fully released ON
ECM Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
E80 147
(ASCD brake switch signal) 175 Brake pedalSlightly depressed Approx. 0
Fully released Battery voltage
ASCD brake switch
Ground Voltage
Connector Terminal
E109 1 Ground Battery voltage
Revision: 2010 May2011 QX56
Page 2515 of 5598
![INFINITI QX56 2011 Factory Service Manual
ASCD BRAKE SWITCHEC-491
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO INFINITI QX56 2011 Factory Service Manual
ASCD BRAKE SWITCHEC-491
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO](/manual-img/42/57033/w960_57033-2514.png)
ASCD BRAKE SWITCHEC-491
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and ASCD brake switch
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK ASCD BRAKE SWITCH
Refer to EC-491, "
Component Inspection (ASCD Brake Switch)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace ASCD brake switch. Refer to BR-20, "
Removal and Installation".
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (ASCD Brake Switch)INFOID:0000000006217991
1.CHECK ASCD BRAKE SWITCH-I
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Check the continuity between ASCD brake swit ch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK ASCD BRAKE SWITCH-II
1. Adjust ASCD brake switch installation. Refer to BR-21, "
Inspection and Adjustment".
2. Check the continuity between ASCD brake swit ch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ASCD brake switch. Refer to BR-20, "
Removal and Installation".
ASCD brake switch ECM
Continuity
Connector Terminal Connector Terminal
E109 2 E80 147 Existed
Terminals Condition Continuity
1 and 2 Brake pedal Fully released Existed
Slightly depressed Not existed
Terminals Condition Continuity
1 and 2 Brake pedal Fully released Existed
Slightly depressed Not existed
Revision: 2010 May2011 QX56
Page 2516 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-492
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD INDICATOR
ASCD INDICATOR
Component Function CheckINFOID:0000000006217992
1.CHECK ASCD INDICATOR FUNCTION
Check ASCD indicator under the following conditi INFINITI QX56 2011 Factory Service Manual
EC-492
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD INDICATOR
ASCD INDICATOR
Component Function CheckINFOID:0000000006217992
1.CHECK ASCD INDICATOR FUNCTION
Check ASCD indicator under the following conditi](/manual-img/42/57033/w960_57033-2515.png)
EC-492
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ASCD INDICATOR
ASCD INDICATOR
Component Function CheckINFOID:0000000006217992
1.CHECK ASCD INDICATOR FUNCTION
Check ASCD indicator under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-492, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217993
1.CHECK DTC
Check that DTC UXXXX is not displayed.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis for DTC UXXXX.
2.CHECK DTC WITH COMBINATION METER
Refer to MWI-30, "
CONSULT-III Function".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning part.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-85, "Removal and Installation".
NO >> Repair or replace malfunctioning part.
ASCD INDICATOR CONDITION SPECIFICATION
CRUISE LAMP Ignition switch: ON MAIN switch: Pressed at the
1st time →
at the 2nd time ON
→ OFF
Revision: 2010 May2011 QX56
Page 2517 of 5598
![INFINITI QX56 2011 Factory Service Manual
ELECTRICAL LOAD SIGNALEC-493
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000006217994
The electrical load signal (Rear window defog INFINITI QX56 2011 Factory Service Manual
ELECTRICAL LOAD SIGNALEC-493
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000006217994
The electrical load signal (Rear window defog](/manual-img/42/57033/w960_57033-2516.png)
ELECTRICAL LOAD SIGNALEC-493
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000006217994
The electrical load signal (Rear window defogger switch
signal, headlamp switch signal, heater fan switch sig-
nal, etc.) is transferred via the CAN communication line.
Component Function CheckINFOID:0000000006217995
1.CHECK REAR WINDOW DEF OGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode with CONSULT-III.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to EC-493, "
Diagnosis Procedure".
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-493, "
Diagnosis Procedure".
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-493, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217996
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-493, "
Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2.
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Refer to DEF-24, "
Work Flow".
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switch ON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switch ON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switch ON ON
OFF OFF
Revision: 2010 May2011 QX56
Page 2518 of 5598
EC-494
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Refer to EXL-59, "
Work Flow".
>> INSPECTION END
4.CHECK HEATER FAN CONTROL SYSTEM
Refer to HAC-60, "
Work Flow".
>> INSPECTION END
Revision: 2010 May2011 QX56
Page 2519 of 5598
![INFINITI QX56 2011 Factory Service Manual
ELECTRICALLY-CONTROLLED COOLING FAN COUPLINGEC-495
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
Component Function CheckINFOID:00000 INFINITI QX56 2011 Factory Service Manual
ELECTRICALLY-CONTROLLED COOLING FAN COUPLINGEC-495
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
Component Function CheckINFOID:00000](/manual-img/42/57033/w960_57033-2518.png)
ELECTRICALLY-CONTROLLED COOLING FAN COUPLINGEC-495
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
Component Function CheckINFOID:0000000006217997
1.CHECK COOLING FAN FUNCTION
WITH CONSULT-III
1. Start the engine.
2. Perform “FAN DUTY CONTROL” in “ACTIVE TEST” mode with CONSULT-III.
3. Check that cooling fan speed varies according to the percentage.
NOTE:
Speed changes gradually as the percentage changes.
WITHOUT CONSULT-III
1. Start the engine and warm up the engine until engine coolant temperature reaches at least 98°C (209 °F).
2. Check that cooling fan speed increase.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-495, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217998
1.CHECK DRIVE BELT
1. Turn ignition switch OFF.
2. Check that the drive belt is not broken.
Is inspection result normal?
YES >> GO TO 2.
NO >> Replace drive belt.
2.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING POWER SUPPLY
1. Disconnect electrically-controlled c ooling fan coupling harness connector.
2. Turn ignition switch ON.
3. Check the voltage between electrically-controll ed cooling fan coupling harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Perform trouble diagnosis for power supply circuit.
3.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check the continuity between electrically-cont rolled cooling fan coupling harness connector and ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK ELECTRICALLY-CONTROLLED COOLING FAN COUPLING CONTROL SIGNAL
WITH CONSULT-III
+ −Vo l ta g e
(Approx.)
Electrically-controlled cooling fan coupling
Connector TerminalF39 1 Ground Battery voltage
+ −Continuity
Electrically-controlled cooling fan coupling
Connector TerminalF39 6 Ground Existed
Revision: 2010 May2011 QX56
Page 2520 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-496
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
1. Start the engine.
2. Perform “FAN DUTY CONTROL” in “ACTIV
E TEST” mode of “ECM” with CONSULT-III.
INFINITI QX56 2011 Factory Service Manual
EC-496
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
1. Start the engine.
2. Perform “FAN DUTY CONTROL” in “ACTIV
E TEST” mode of “ECM” with CONSULT-III.](/manual-img/42/57033/w960_57033-2519.png)
EC-496
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ELECTRICALLY-CONTROLLED COOLING FAN COUPLING
1. Start the engine.
2. Perform “FAN DUTY CONTROL” in “ACTIV
E TEST” mode of “ECM” with CONSULT-III.
3. Set the Duty value to 100%.
4. Check the voltage between electrically-controll ed cooling fan coupling harness connector and ground.
CAUTION:
Wait for 1 minute or more to measure.
WITHOUT CONSULT-III
1. Start the engine and warm up the engine until engine coolant temperature reaches at least 98 °C (209 °F).
2. Check the voltage between electrically-controll ed cooling fan coupling harness connector and ground.
CAUTION:
Wait for 1 minute or more to measure.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 5.
5.CHECK ELECTRICALLY-CONTROLLED COOL ING FAN COUPLING CONTROL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between electrically-contro lled cooling fan coupling harness connector and IPDM E/
R harness connector.
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 6.
+ −Vo l ta g e
(Approx.)
Electrically-controlled cooling fan coupling
Connector Terminal
F39 3 Ground 2. 5 V
+ −Vo l ta g e
(Approx.)
Electrically-controlled cooling fan coupling
Connector Terminal
F39 3 Ground 2. 5 V
JMMIA0404GB
JMMIA0404GB
+−
Continuity
Electrically-controlled cooling fan
coupling IPDM E/R
Connector Terminal Connector Terminal F39 3 E17 72 Existed
Revision: 2010 May2011 QX56
