Page 937 of 5598
CHG-24
< SYMPTOM DIAGNOSIS >
CHARGING SYSTEM
SYMPTOM DIAGNOSIS
CHARGING SYSTEM
Symptom TableINFOID:0000000006274876
Symptom Reference
Discharged battery
Refer to CHG-13, "
Work Flow".
The charge warning lamp does not illuminate when the ignition
switch is set to ON.
The charge warning lamp does not turn OFF after the engine
starts.
The charging warning lamp turns ON when increasing the engine
speed.
Revision: 2010 May2011 QX56
Page 938 of 5598
CHG
ALTERNATORCHG-25
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
B A
O P
N
REMOVAL AND INSTALLATION
ALTERNATOR
Exploded ViewINFOID:0000000006274877
REMOVAL
DISASSEMBLY
1. Alternator bracket 2. Alternator bracket mounting bolt 3. “B” terminal harness
4. “B” terminal nut 5. Alternator connector 6. Alternator
7. Alternator stay 8. Alternator mounting bolt (lower) 9. Alternator stay mounting bolt
10. Ground harness 11. Alternator mounting bolt (upper)
Refer to
GI-4, "
Components" for symbols in the figure.
JMMIA0361GB
Revision: 2010 May2011 QX56
Page 939 of 5598
CHG-26
< REMOVAL AND INSTALLATION >
ALTERNATOR
Type: A002TX1491
Removal and InstallationINFOID:0000000006274878
REMOVAL
1. Disconnect the battery cable from the negative terminal. Refer to PG-164, "Removal and Installation".
2. Remove front under cover. Refer to EXT-25, "
Removal and Installation".
3. Remove drive belt. Refer to EM-20, "
Removal and Installation".
4. Disconnect engine oil pressure switch connector (A) and alter- nator connector (B).
5. Remove harness bracket bolt (C).
6. Remove “B” terminal nut (D) and disconnect “B” terminal har- ness.
JMMIA0363GB
1. Rear bearing 2. Rotor assembly 3. Retainer
4. Front bearing 5. Front bracket assembly 6. Pulley
7. Pulley nut 8. Stator assembly 9. IC voltage regulator assembly
10. Diode assembly 11. Rear bracket assembly 12. Terminal set
Refer to GI-4, "
Components" for symbols in the figure.
JMMIA0364ZZ
Revision: 2010 May2011 QX56
Page 940 of 5598

CHG
ALTERNATORCHG-27
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
B A
O P
N
7. Remove ground harness mounting bolt.
8. Remove alternator mounting bolt (lower), and then alternator mounting bolt (upper).
9. Remove A/T fluid cooler tube (1) from fan shroud (2).
10. Move A/T fluid cooler tube (1) and secure work space.
11. Remove alternator assembly
(2) from underneath the vehicle.
INSTALLATION
Note the following items, and then install in the reverse order of removal.
CAUTION:
Be careful to tighten “B” terminal nut carefully.
Install alternator, and check tension of belt. Refer to EM-20, "
Checking".
For this model, the power genera tion voltage variable control system that controls the power gener-
ation voltage of the alternator has been adopted. Therefore, the power generation voltage variable
control system operation inspectio n should be performed after replacing the alternator, and then
make sure that the system operates normally. Refer to CHG-17, "
Inspection Procedure".
When installing alternator br acket, tighten mounting bolts in
numerical order as shown in the figure.
JMMIA0365ZZ
JMMIA0366ZZ
JMMIA0367ZZ
JMMIA0456ZZ
Revision: 2010 May2011 QX56
Page 941 of 5598
CHG-28
< REMOVAL AND INSTALLATION >
ALTERNATOR
Inspection
INFOID:0000000006274885
ALTERNATOR PULLEY INSPECTION
Perform the following.
Make sure that alternator pulley does not rattle.
Make sure that alternator pulley nut is tight. Refer to CHG-25, "
Exploded View".
Revision: 2010 May2011 QX56
Page 942 of 5598
CHG
SERVICE DATA AND SPECIFICATIONS (SDS)
CHG-29
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D E
F
G H
I
J
K L
B A
O P
N
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
AlternatorINFOID:0000000006274881
*: Adjustment range of power generation voltage variable control is 11.4 - 15.6 V. Ty p e
A002TX1491
MITSUBISHI make
Nominal rating [V - A] 12 -150
Ground polarity Negative
Minimum revolution under no-load (When 13.5 V is ap-
plied) [rpm] Less than 1,300
Hot output current (When 13.5 V is applied) [A/rpm] More than 57/1,500
More than 126/2,500
More than 152/5,000
Regulated output voltage [V] 14.1 - 14.7
*
Revision: 2010 May2011 QX56
Page 943 of 5598

CO-1
ENGINE
C
DE
F
G H
I
J
K L
M
SECTION CO
A
CO
N
O P
CONTENTS
ENGINE COOLING SYSTEM
PRECAUTION ................ ...............................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Commercial Service Tools ................................. ......3
SYSTEM DESCRIPTION ..............................4
DESCRIPTION ............................................... .....4
Engine Cooling System ..................................... ......4
Engine Cooling System Schematic .........................5
SYMPTOM DIAGNOSIS ...............................6
OVERHEATING CAUSE ANALYSIS ............. .....6
Troubleshooting Chart ........................................ ......6
PERIODIC MAINTENANCE ..........................8
ENGINE COOLANT ....................................... .....8
Inspection ............................................................ ......8
Draining .....................................................................8
Refilling .....................................................................9
Flushing ...................................................................10
RADIATOR .........................................................11
RESERVOIR TANK CAP ..........................................11
RESERVOIR TANK CAP : Inspection ................. ....11
RADIATOR ............................................................. ....11
RADIATOR : Inspection ...........................................11
REMOVAL AND INSTALLATION ...............13
RADIATOR ....................................... .................13
Exploded View ..................................................... ....13
Removal and Installation .........................................13
Inspection ................................................................15
COOLING FAN ..................................................16
Exploded View .........................................................16
Removal and Installation .........................................16
Inspection ................................................................17
WATER PUMP ..................................................18
Exploded View .........................................................18
Removal and Installation .........................................18
Inspection ................................................................19
WATER INLET AND THERMOSTAT ASSEM-
BLY ....................................................................
20
Exploded View .........................................................20
Removal and Installation .........................................20
Inspection ................................................................21
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .............................................
23
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
23
Periodical Maintenance Specification ................ ....23
Radiator ...................................................................23
Thermostat ..............................................................23
Revision: 2010 May2011 QX56
Page 944 of 5598

CO-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006417198
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISS AN/INFINITI dealer.
Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
