Page 4841 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-48
< DTC/CIRCUIT DIAGNOSIS >
B1022 OCCUPANT SENS C/U
B1022 OCCUPANT SENS C/U
DescriptionINFOID:0000000006219975
Suppresses the deployment of front passenger air bag when the condition of passenge

SRC-48
< DTC/CIRCUIT DIAGNOSIS >
B1022 OCCUPANT SENS C/U
B1022 OCCUPANT SENS C/U
DescriptionINFOID:0000000006219975
Suppresses the deployment of front passenger air bag when the condition of passenger seat is empty or occu-
pied with a child and child-seat. Also illuminates front passenger air bag OFF indicator lamp when the condi-
tion of passenger seat is occupied with a child-seat and ch ild. In case of malfunction the blinking of the air bag
warning lamp reports the malfunction to driver, and by the on board self-diagnosis system or CONSULT-III can
detect the cause.
OPERATION
This unit classifies occupant in passenger seat and detec ts electrical malfunction in Occupant Detection Sys-
tem and transmits malfunction information to air bag control unit.
STRUCTURE
It is integrated into the seat sensor mat and detects the occupants and Occupant Detection System control
unit that classifies the occupants.
INSTALLATION
Occupant Detection System control unit is installed in the passenger seat cushion.
DTC LogicINFOID:0000000006219976
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-48, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219977
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
DIAGNOSTIC PROCEDURE
1.CHECK HARNESS CONNECTOR
Check the connection of harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1022 OCCUPANT SENS C/U [COMM FAIL] Malfunction occurs in Occupant Detec-
tion System control unit, circuit of Occu-
pant Detection System control unit-Air
bag diagnosis sensor unit or Air bag di-
agnosis sensor unit Disconnection of wiring harness
Malfunction in Occupant Detection
System control unit
Malfunction in air bag diagnosis sen-
sor unit
Revision: 2010 May2011 QX56

Page 4842 of 5598

INFINITI QX56 2011 Factory Service Manual
B1022 OCCUPANT SENS C/USRC-49
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO

Page 4843 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-50
< DTC/CIRCUIT DIAGNOSIS >
B1023 PASS A/B INDCTR CKT
B1023 PASS A/B INDCTR CKT
DescriptionINFOID:0000000006219978
Suppresses the deployment of front passenger air bag when the condition of pass

SRC-50
< DTC/CIRCUIT DIAGNOSIS >
B1023 PASS A/B INDCTR CKT
B1023 PASS A/B INDCTR CKT
DescriptionINFOID:0000000006219978
Suppresses the deployment of front passenger air bag when the condition of passenger seat is empty or occu-
pied with a child and child-seat. Also illuminates front passenger air bag OFF indicator lamp when the condi-
tion of passenger seat is occupied with a child-seat and ch ild. In case of malfunction the blinking of the air bag
warning lamp reports the malfunction to driver, and by the on board self-diagnosis system or CONSULT-III can
detect the cause.
OPERATION
Illuminates front passenger air bag OFF indicator when t he passenger seat is empty or occupied by a child or
a child-seat.
STRUCTURE
Front passenger air bag OFF indicator with LED illumination.
INSTALLATION
Front passenger air bag OFF indicator is inst alled at the instrument panel center.
DTC LogicINFOID:0000000006219979
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-50, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219980
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
DIAGNOSTIC PROCEDURE
1.CHECK HARNESS CONNECTOR
Check the connection of harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1023 PASS A/B INDCTR CKT [UNIT FAIL] Passenger air bag OFF indicator circuit
is open or shorted to ground or the cir-
cuits are shorted each other Disconnection of wiring harness
Malfunction in front passenger air
bag OFF indicator
Malfunction in air bag diagnosis sen- sor unit
Revision: 2010 May2011 QX56

Page 4844 of 5598

INFINITI QX56 2011 Factory Service Manual
B1023 PASS A/B INDCTR CKTSRC-51
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.

Page 4845 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-52
< DTC/CIRCUIT DIAGNOSIS >
B1025, B1032, B1048 OCS SENSOR
B1025, B1032, B1048 OCS SENSOR
DescriptionINFOID:0000000006219981
Suppresses the deployment of front passenger air bag when the condit

SRC-52
< DTC/CIRCUIT DIAGNOSIS >
B1025, B1032, B1048 OCS SENSOR
B1025, B1032, B1048 OCS SENSOR
DescriptionINFOID:0000000006219981
Suppresses the deployment of front passenger air bag when the condition of passenger seat is empty or occu-
pied with a child and child-seat. Also illuminates front passenger air bag OFF indicator lamp when the condi-
tion of passenger seat is occupied with a child-seat and ch ild. In case of malfunction the blinking of the air bag
warning lamp reports the malfunction to driver, and by the on board self-diagnosis system or CONSULT-III can
detect the cause.
OPERATION
This unit classifies occupant in passenger seat and detec ts electrical malfunction in Occupant Detection Sys-
tem and transmits malfunction information to air bag control unit.
STRUCTURE
It is integrated into the seat sensor mat and detects the occupants and Occupant Detection System control
unit that classifies the occupants.
INSTALLATION
Occupant Detection System control unit is installed in the passenger seat cushion.
DTC LogicINFOID:0000000006219982
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-52, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219983
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
DIAGNOSTIC PROCEDURE
1.CHECK HARNESS CONNECTOR
Check the connection of harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1025
B1032
B1048 OCS SENSOR Malfunction occu
rs in Occupant Detec-
tion System control unit, circuit of Occu-
pant Detection System control unit-Air
bag diagnosis sensor unit or Air bag di-
agnosis sensor unit Disconnection of wiring harness
Internal breakdown in Occupant De-
tection System control unit
Malfunction in air bag diagnosis sen-
sor unit
Revision: 2010 May2011 QX56

Page 4846 of 5598

INFINITI QX56 2011 Factory Service Manual
B1025, B1032, B1048 OCS SENSORSRC-53
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO T

Page 4847 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-54
< DTC/CIRCUIT DIAGNOSIS >
B1026, B1027, B1028, B1029, B1030, B1031 DIAGNOSIS SENSOR UNIT
B1026, B1027, B1028, B1029, B1030, B1031 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006219984
DTC DE

Page 4848 of 5598

INFINITI QX56 2011 Factory Service Manual
B1033, B1034 CRASH ZONE SENSOR
SRC-55
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1033, B1034 CRASH ZONE SENSOR
DTC LogicINFOID:0000000006219986
DTC DETECTION LOGIC
DTC CONFIRMATION
