BRC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
C1116 STOP LAMP SWITCH
17.CHECK STOP LAMP RELAY CIRCUIT (2)
1. Turn the ignition switch OFF.
2. Check 10A fuse (#57).
3. Disconnect IPDM E/R harness connect

BRC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
C1116 STOP LAMP SWITCH
17.CHECK STOP LAMP RELAY CIRCUIT (2)
1. Turn the ignition switch OFF.
2. Check 10A fuse (#57).
3. Disconnect IPDM E/R harness connector.
4. Check IPDM E/R pin terminals for dam age or loose connection with harness connector.
5. Check continuity between stop lamp relay harness connector and IPDM E/R harness connector.
Is the inspection result normal?
YES >> Perform trouble diagnosis for ignition power supply. Refer to PG-89, "Wiring Diagram - IGNITION
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
18.CHECK STOP LAMP RELAY POWER SUPPLY (3)
1. Turn the ignition switch OFF.
2. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
3. Turn the ignition switch ON. CAUTION:
Never start engine.
4. Check voltage between stop lamp relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 22.
NO >> GO TO 19.
19.CHECK STOP LAMP RELAY CIRCUIT (3)
1. Turn the ignition switch OFF.
2. Disconnect stop lamp relay harness connector.
3. Check continuity between ABS actuator and electr ic unit (control unit) harness connector and stop lamp
relay harness connector.
4. Check continuity between ABS actuator and elec tric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 20.
Stop lamp relay IPDM E/R Continuity
Connector Terminal Connector Terminal
E581E1559Existed
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 37 Ground Approx. 0 V
ABS actuator and electric unit (control unit) — Condition Voltage
Connector Terminal
E36 37 Ground Brake pedal depressed Battery voltage
Brake pedal not depressed Approx. 0 V
ABS actuator and electric unit (c ontrol unit) Stop lamp relay
Continuity
Connector Terminal Connector Terminal
E3637E58 5Existed
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E36 37 Ground Not existed
Revision: 2010 May2011 QX56
