Page 3841 of 5598

INFINITI QX56 2011 Factory Service Manual
PB-10
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Parking Drum BrakeINFOID:0000000006222

Page 3842 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS
PCS-1
ELECTRICAL & POWER CONTROL
C
DE
F
G H
I
J
K L
B
SECTION PCS
A
O P
N
CONTENTS
POWER CONTROL SYSTEM
IPDM E/R
PRECAUTION ................ ...............................
3
PRECAUTIONS ........

PCS
PCS-1
ELECTRICAL & POWER CONTROL
C
DE
F
G H
I
J
K L
B
SECTION PCS
A
O P
N
CONTENTS
POWER CONTROL SYSTEM
IPDM E/R
PRECAUTION ................ ...............................
3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
SYSTEM DESCRIPTION ..............................4
COMPONENT PARTS ................................... .....4
Component Parts Location .................................. ......4
SYSTEM ..............................................................5
RELAY CONTROL SYSTEM ................................ ......5
RELAY CONTROL SYSTEM : System Diagram ......5
RELAY CONTROL SYSTEM : System Descrip-
tion ...................................................................... ......
5
RELAY CONTROL SYSTEM : Fail-Safe ...................6
POWER CONTROL SYSTEM .....................................7
POWER CONTROL SYSTEM : System Diagram ......8
POWER CONTROL SYSTEM : System Descrip-
tion ...................................................................... ......
8
SIGNAL BUFFER SYSTEM ........................ ................8
SIGNAL BUFFER SYSTEM : System Diagram .. ......8
SIGNAL BUFFER SYSTEM : System Description ......8
POWER CONSUMPTION CONTROL SYSTEM ... ......8
POWER CONSUMPTION CONTROL SYSTEM :
System Diagram ........................................................
9
POWER CONSUMPTION CONTROL SYSTEM :
System Description ...................................................
9
DIAGNOSIS SYSTEM (IPDM E/R) .....................10
Diagnosis Description ......................................... ....10
CONSULT-III Function (IPDM E/R) .........................12
ECU DIAGNOSIS INFORMATION ..............15
IPDM E/R ...........................................................15
Reference Value .................................................. ....15
Fail-Safe ..................................................................21
DTC Index ...............................................................22
WIRING DIAGRAM ......................................24
IPDM E/R ...........................................................24
Wiring Diagram .................................................... ....24
DTC/CIRCUIT DIAGNOSIS .........................28
U1000 CAN COMM CIRCUIT ...........................28
Description ........................................................... ....28
DTC Logic ................................................................28
Diagnosis Procedure ...............................................28
B2098 IGNITION RELAY ON STUCK ..............29
Description ...............................................................29
DTC Logic ................................................................29
Diagnosis Procedure ...............................................29
B2099 IGNITION RELAY OFF STUCK ............30
Description ...............................................................30
DTC Logic ................................................................30
Diagnosis Procedure ...............................................30
POWER SUPPLY AND GROUND CIRCUIT ....31
Diagnosis Procedure ...............................................31
REMOVAL AND INSTALLATION ...............32
IPDM E/R ...........................................................32
Removal and Installation ..................................... ....32
POWER DISTRIBUTION SYSTEM
PRECAUTION ............... ...............................
33
PRECAUTIONS .................................................33
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ....
33
Revision: 2010 May2011 QX56

Page 3843 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS-2
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect ..................................
33
SYSTEM DESCRIPTION ............................35
COMPONENT PARTS ..........

PCS-2
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect ..................................
33
SYSTEM DESCRIPTION ............................35
COMPONENT PARTS .................................... ...35
Component Parts Location .................................. ...35
Component Description .........................................35
BCM ........................................................................35
Ignition Relay ..........................................................35
Accessory Relay .....................................................36
Blower Relay ..........................................................36
Push-Button Ignition Switch ....................................36
SYSTEM .......................................................... ...37
POWER DISTRIBUTION SYST EM ........................ ...37
POWER DISTRIBUTION SYSTEM : System Dia-
gram .................................................................... ...
37
POWER DISTRIBUTION SYSTEM : System De-
scription ..................................................................
37
DIAGNOSIS SYSTEM (BCM) ............................39
COMMON ITEM ..................................................... ...39
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) ................................................. ...
39
INTELLIGENT KEY ................................................ ...40
INTELLIGENT KEY : CONSULT-III Function
(BCM - INTELLIGENT KEY) ...................................
40
ECU DIAGNOSIS INFO RMATION ..............45
BCM ................................................................ ...45
List of ECU Reference ......................................... ...45
WIRING DIAGRAM .....................................46
POWER DISTRIBUTION SYSTEM ................ ...46
Wiring Diagram .................................................... ...46
BASIC INSPECTION ...................................53
DIAGNOSIS AND REPAIR WORK FLOW ..... ...53
Work Flow ............................................................ ...53
DTC/CIRCUIT DIAGNOSIS ...................... ...56
B2614 ACC RELAY CIRCUIT ........................ ...56
DTC Logic ............................................................ ...56
Diagnosis Procedure ..............................................56
Component Inspection ............................................57
B2615 BLOWER RELAY CIRCUIT ...................59
DTC Logic ............................................................ ...59
Diagnosis Procedure ..............................................59
Component Inspection ......................................... ...60
B2616 IGNITION RELAY CIRCUIT ...................61
DTC Logic ............................................................ ...61
Diagnosis Procedure ...............................................61
Component Inspection ............................................62
B2618 BCM .......................................................63
DTC Logic ............................................................ ...63
Diagnosis Procedure ...............................................63
B261A PUSH-BUTTON IGNITION SWITCH .....64
DTC Logic ............................................................ ...64
Diagnosis Procedure ...............................................64
B26F1 IGNITION RELAY ..................................66
DTC Logic ............................................................ ...66
Diagnosis Procedure ...............................................66
B26F2 IGNITION RELAY ..................................68
DTC Logic ............................................................ ...68
Diagnosis Procedure ...............................................68
B26F6 BCM .......................................................70
DTC Logic ............................................................ ...70
Diagnosis Procedure ...............................................70
PUSH-BUTTON IGNITION SWITCH .................71
Component Function Check ............................... ...71
Diagnosis Procedure ...............................................71
Component Inspection ............................................72
PUSH-BUTTON IGNITION SWITCH POSI-
TION INDICATOR ..............................................
74
Description ........................................................... ...74
Component Function Check ..................................74
Diagnosis Procedure ...............................................74
SYMPTOM DIAGNOSIS ............................76
PUSH-BUTTON IGNITION SWITCH DOES
NOT OPERATE .............................................. ...
76
Description ........................................................... ...76
Diagnosis Procedure ...............................................76
PUSH-BUTTON IGNITION SWITCH POSI-
TION INDICATOR DOES NOT ILLUMINATE ...
77
Description ..............................................................77
Diagnosis Procedure ...............................................77
REMOVAL AND INSTALLATION ..............78
PUSH-BUTTON IGNITION SWITCH .............. ...78
Exploded View ..................................................... ...78
Removal and Installation .........................................78
Revision: 2010 May2011 QX56

Page 3844 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS
PRECAUTIONSPCS-3
< PRECAUTION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID

PCS
PRECAUTIONSPCS-3
< PRECAUTION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006220159
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Revision: 2010 May2011 QX56

Page 3845 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS-4
< SYSTEM DESCRIPTION >[IPDM E/R]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006220160
1. IPDM E/R
A. Engine room (RH)
JMMIA0330ZZ
Revision: 2010 Ma

Page 3846 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS
SYSTEMPCS-5
< SYSTEM DESCRIPTION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYSTEM
RELAY CONTROL SYSTEM
RELAY CONTROL SYSTEM
: System DiagramINFOID:0000000006220161
RELAY CONTROL SYSTEM : Syste

Page 3847 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS-6
< SYSTEM DESCRIPTION >[IPDM E/R]
SYSTEM
NOTE:
BCM controls the starter relay.
RELAY CONTROL SYSTEM : Fail-SafeINFOID:0000000006220163
CAN COMMUNICATION CONTROL
When CAN communication with ECM a

PCS-6
< SYSTEM DESCRIPTION >[IPDM E/R]
SYSTEM
NOTE:
BCM controls the starter relay.
RELAY CONTROL SYSTEM : Fail-SafeINFOID:0000000006220163
CAN COMMUNICATION CONTROL
When CAN communication with ECM and BCM is impossible,
IPDM E/R performs fail-safe control. After CAN
communication recovers normally, it also returns to normal control.
If No CAN Communication Is Available With ECM
If No CAN Communication Is Available With BCM
Control relay Input/output Transmi t unit Control part Reference page
Headlamp low relay
Headlamp high relay Low beam request signal
High beam request signal
BCM (CAN)
Headlamp (LO)
Headlamp (HI) EXL-10
Front fog lamp relay Front fog light request signal BCM (CAN) Front fog lamp
EXL-20
Tail lamp relay Position light request signal BCM (CAN) Parking lamp
License plate
lamp
Tail lamp
Side marker lamp EXL-18
Illuminations
INL-6
Front wiper relay
Front wiper high relayFront wiper request signal BCM (CAN)
Front wiper motorWW-7Front wiper stop position sig-
nal Front wiper motor
Rear window defogger
relay Rear window defogger control
signal
BCM (CAN)
Rear window defog-
ger
DEF-6
Horn relay
Theft warning horn
relay Theft warning horn request
signal
Horn reminder signal BCM (CAN)
Horn (high)
Horn (low) SEC-17
Starter relayNOTE
Starter control relayStarter control rela
y signal BCM (CAN)
Starter motorSEC-10
,
SEC-10Steering lock unit condition
signal Steering lock unit
Starter relay control signal TCM
Steering lock relay Steering lock relay signal BCM (CAN)
Steering lock unitSEC-10
Steering lock unit condition
signal Steering lock unit
A/T shift selector (detention
switch) signal A/T shift selector
(detention switch)
A/C relay A/C compressor request sig-
nal ECM (CAN)
A/C compressor
(Magnet clutch) HAC-17
Headlamp washer relay
Headlamp washer request
signal BCM (CAN)Headlamp washer
pump WW-13
Ignition relay
Ignition relay-2
Ignition relay-3Ignition switch ON signal BCM (CAN)
Each control unit,
sensor, actuator and
relay (ignition power
supply)PCS-29Vehicle speed signal
Combination meter
(CAN)
Push-button ignition switch
signal Push-button ignition
switch
Control part Fail-safe operation
Cooling fan Transmits the pulse duty signal (PWM signal) 100% when the ignition switch is turned ON.
Transmits the pulse duty signal (PWM signal) 0% when the ignition switch is turned OFF.
A/C compressor A/C relay OFF
Alternator Transmits the power generation command signal (PWM signal) 0%
Revision: 2010 May2011 QX56

Page 3848 of 5598

INFINITI QX56 2011 Factory Service Manual
PCS
SYSTEMPCS-7
< SYSTEM DESCRIPTION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
IGNITION RELAY MALFUNCTION DETECTION FUNCTION
IPDM E/R monitors the voltage at the contact circuit and
excitation co

PCS
SYSTEMPCS-7
< SYSTEM DESCRIPTION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
IGNITION RELAY MALFUNCTION DETECTION FUNCTION
IPDM E/R monitors the voltage at the contact circuit and
excitation coil circuit of the ignition relay inside it.
IPDM E/R judges the ignition relay error if the volt age differs between the contact circuit and the excitation
coil circuit.
If the ignition relay cannot turn OFF due to contact seizure, it activates the tail lamp relay for 10 minutes to alert the user to the ignition relay malfunc tion when the ignition switch is turned OFF.
FRONT WIPER PROTECTION FUNCTION
IPDM E/R detects front wiper stop position by a front wiper stop position signal.
When a front wiper stop position signal is in the conditi ons listed below, IPDM E/R stops power supply to wiper
after repeating a front wiper 10 seconds activation and 20 seconds stop.
NOTE:
This operation status can be confirmed on the IPDM E/ R “Data Monitor” that displays “BLOCK” for the item
“WIP PROT” while the wiper is stopped.
STARTER MOTOR PROTECTION FUNCTION
IPDM E/R turns OFF the starter control relay to protect the starter motor when the starter control relay remains
active for 90 seconds.
POWER CONTROL SYSTEM
Control part Fail-safe operation
Headlamp Turns ON the headlamp low relay when the ignition switch is turned ON
Turns OFF the headlamp low relay when the ignition switch is turned OFF
Headlamp high relay OFF
Parking lamp
License plate lamp
Illumination
Tail lamp Turns ON the tail lamp relay when the ignition switch is turned ON
Turns OFF the tail lamp relay when the ignition switch is turned OFF
Front wiper motor The status just before activation of fail-safe control is maintained until the ignition switch is
turned OFF while the front wiper is operating at LO or HI speed.
The wiper is operated at LO speed until the ignition switch is turned OFF if the fail-safe con- trol is activated while the front wiper is set in the INT mode and the front wiper motor is op-
erating.
Return automatically wiper to stop position when ignition switch is turned ON if fail-safe con- trol is activated while front wiper motor is operated and wiper stops in the other position than
stop position.
Front fog lamp Front fog lamp relay OFF
Horn Horn OFF
Ignition relay The status just before activation of fail-safe is maintained.
Starter motor Starter control relay OFF
Steering lock unit Steering lock relay OFF
Voltage judgment IPDM E/R judgment Operation
Ignition relay contact side Ignition relay excitation coil
side
ON ON Ignition relay ON normal —
OFF OFF Ignition relay OFF normal —
ON OFF Ignition relay ON stuck Detects DTC “B2098: IGN RELAY ON”
Turns ON the tail lamp relay for 10 min-
utes
OFF ON Ignition relay OFF stuck Detects DTC “B2099: IGN RELAY OFF”
Ignition switch Front wiper switch Front wiper stop position signal
ON OFF
The front wiper stop position signal (stop position) cannot be input for
10 seconds.
ON The front wiper stop position signal does not change for 10 seconds.
Revision: 2010 May2011 QX56
