LAN
MAIN LINE BETWEEN DLC AND E-SUS CIRCUITLAN-61
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN DLC AND E-SUS CIRCUIT
Diagnosis ProcedureINFOID:0000000006238655
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector M19
- Harness connector B2
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the harness connectors M19 and B2.
2. Check the continuity between the data link connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the data link connector and the harness connector M19.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of air levelizer control module.
2. Check the continuity between the harness connector and the air levelizer control module harness connec-
tor.
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main line between the data link connector and the air levelizer
control module.
NO >> Repair the main line between the harness c onnector B2 and the air levelizer control module.
Data link connector Harness connector
Continuity
Connector No. Terminal No. Connector No. Terminal No.
M4 6
M19 29 Existed
14 30 Existed
Harness connector Air levelizer control module harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
B2 29
B84 16 Existed
30 7 Existed
Revision: 2010 May2011 QX56
Page 3482 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-62
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN E-SUS AND ADP CIRCUIT
MAIN LINE BETWEEN E-SUS AND ADP CIRCUIT
Diagnosis ProcedureINFOID:0000000006238656
1.CHECK HARNESS CONTI
NUITY (OPEN CIRC INFINITI QX56 2011 Factory Service Manual
LAN-62
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN E-SUS AND ADP CIRCUIT
MAIN LINE BETWEEN E-SUS AND ADP CIRCUIT
Diagnosis ProcedureINFOID:0000000006238656
1.CHECK HARNESS CONTI
NUITY (OPEN CIRC](/manual-img/42/57033/w960_57033-3481.png)
LAN-62
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN E-SUS AND ADP CIRCUIT
MAIN LINE BETWEEN E-SUS AND ADP CIRCUIT
Diagnosis ProcedureINFOID:0000000006238656
1.CHECK HARNESS CONTI
NUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect the following harness connectors.
-ECM
- Air levelizer control module
- Harness connectors B24 and B460
4. Check the continuity between the air levelizer control module harness connector and the harness connec-
tor.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main li ne between the air levelizer control module and the driver
seat control unit.
NO >> Repair the main line between the air levelizer control module and the harness connector B24.
Air levelizer control module harness connector Harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
B84 16
B24 13 Existed
7 12 Existed
Revision: 2010 May2011 QX56
Page 3483 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
MAIN LINE BETWEEN ADP AND PWBD CIRCUIT
LAN-63
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN ADP AND PWBD CIRCUIT
Diagnosis ProcedureINFOID:0000000006220540
1.CHE INFINITI QX56 2011 Factory Service Manual
LAN
MAIN LINE BETWEEN ADP AND PWBD CIRCUIT
LAN-63
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN ADP AND PWBD CIRCUIT
Diagnosis ProcedureINFOID:0000000006220540
1.CHE](/manual-img/42/57033/w960_57033-3482.png)
LAN
MAIN LINE BETWEEN ADP AND PWBD CIRCUIT
LAN-63
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN ADP AND PWBD CIRCUIT
Diagnosis ProcedureINFOID:0000000006220540
1.CHECK HARNESS CONTI
NUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Disconnect the following harness connectors.
- CAN gateway
- Harness connectors B460 and B24
- Automatic back door control module
4. Check the continuity between the harness connecto r and the automatic back door control module harness
connector.
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main li ne between the driver seat control unit and the automatic
back door control module.
NO >> Repair the main line between the harness c onnector B24 and the automatic back door control
module.
Harness connector Automatic back door control module
harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
B24 13
B26 7 Existed
12 6 Existed
Revision: 2010 May2011 QX56
Page 3484 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-64
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN RDR-R AND RDR-L CIRCUIT
MAIN LINE BETWEEN RDR-R AND RDR-L CIRCUIT
Diagnosis ProcedureINFOID:0000000006220541
1.CHECK CONNECTOR
1. Turn the igni INFINITI QX56 2011 Factory Service Manual
LAN-64
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN RDR-R AND RDR-L CIRCUIT
MAIN LINE BETWEEN RDR-R AND RDR-L CIRCUIT
Diagnosis ProcedureINFOID:0000000006220541
1.CHECK CONNECTOR
1. Turn the igni](/manual-img/42/57033/w960_57033-3483.png)
LAN-64
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN RDR-R AND RDR-L CIRCUIT
MAIN LINE BETWEEN RDR-R AND RDR-L CIRCUIT
Diagnosis ProcedureINFOID:0000000006220541
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side and harness side).
- Harness connector B239
- Harness connector B63
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- Side radar RH
- Harness connectors B239 and B63
2. Check the continuity between the side r adar RH harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the side radar RH and the harness connector B239.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of side radar LH.
2. Check the continuity between the harness c onnector and the side radar LH harness connector.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main line between the side radar RH and the side radar LH.
NO >> Repair the main line between the harness connector B63 and the side radar LH.
Side radar RH harness connector Harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
B243 4
B239 7 Existed
33Existed
Harness connector Side radar LH harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
B63 7
B74 4 Existed
33Existed
Revision: 2010 May2011 QX56
Page 3485 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
MAIN LINE BETWEEN RDR-L AND LANE CIRCUITLAN-65
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN RD
R-L AND LANE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220542
1 INFINITI QX56 2011 Factory Service Manual
LAN
MAIN LINE BETWEEN RDR-L AND LANE CIRCUITLAN-65
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN RD
R-L AND LANE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220542
1](/manual-img/42/57033/w960_57033-3484.png)
LAN
MAIN LINE BETWEEN RDR-L AND LANE CIRCUITLAN-65
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN RD
R-L AND LANE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220542
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector B2
- Harness connector M19
- Harness connector M23
- Harness connector R1
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- Side radar LH
- Harness connectors B2 and M19
2. Check the continuity between the side radar LH harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the side radar LH and the harness connector B2.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the harness connectors M23 and R1.
2. Check the continuity between the harness connectors.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair the main line between the harness connectors M19 and M23.
4.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of lane camera unit.
2. Check the continuity between the harness c onnector and the lane camera unit harness connector.
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main li ne between the side radar LH and the lane camera unit.
Side radar LH harness connector Harness connector
Continuity
Connector No. Terminal No. Connector No. Terminal No.
B74 4
B2 27 Existed
3 28 Existed
Harness connector Harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M19 27
M23 26 Existed
28 23 Existed
Harness connector Lane camera unit harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
R1 26
R8 4 Existed
23 8 Existed
Revision: 2010 May2011 QX56
Page 3486 of 5598
LAN-66
< DTC/CIRCUIT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN RDR-L AND LANE CIRCUIT
NO >> Repair the main line between the harness connector R1 and the lane camera unit.
Revision: 2010 May2011 QX56
Page 3487 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN
MAIN LINE BETWEEN LANE AND APA CIRCUITLAN-67
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN LA
NE AND APA CIRCUIT
Diagnosis ProcedureINFOID:0000000006220543
1.CHE INFINITI QX56 2011 Factory Service Manual
LAN
MAIN LINE BETWEEN LANE AND APA CIRCUITLAN-67
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN LA
NE AND APA CIRCUIT
Diagnosis ProcedureINFOID:0000000006220543
1.CHE](/manual-img/42/57033/w960_57033-3486.png)
LAN
MAIN LINE BETWEEN LANE AND APA CIRCUITLAN-67
< DTC/CIRCUIT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN LA
NE AND APA CIRCUIT
Diagnosis ProcedureINFOID:0000000006220543
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector R1
- Harness connector M23
- Harness connector M77
- Harness connector E105
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the harness connectors R1 and M23.
2. Check the continuity between the harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the lane camera unit and the harness connector R1.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the harness connectors M77 and E105.
2. Check the continuity between the harness connectors.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair the main line between the harness connectors M23 and M77.
4.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of accelerator pedal actuator.
2. Check the continuity between t he harness connector and the accelerator pedal actuator harness connec-
tor.
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main line between the lane camera unit and the accelerator
pedal actuator.
NO >> Repair the main line between the harness c onnector E105 and the accelerator pedal actuator.
Connector No. Terminal No. Continuity
R1 26 29 Existed
23 28 Existed
Harness connector Harness connector
Continuity
Connector No. Terminal No. Connector No. Terminal No.
M23 29
M77 22 Existed
28 23 Existed
Harness connector Accelerator pedal actuator harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
E105 22
E66 5 Existed
23 4 Existed
Revision: 2010 May2011 QX56
Page 3488 of 5598
![INFINITI QX56 2011 Factory Service Manual
LAN-68
< DTC/CIRCUIT DIAGNOSIS >[CAN]
ECM BRANCH LINE CIRCUIT
ECM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220544
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the b INFINITI QX56 2011 Factory Service Manual
LAN-68
< DTC/CIRCUIT DIAGNOSIS >[CAN]
ECM BRANCH LINE CIRCUIT
ECM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220544
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the b](/manual-img/42/57033/w960_57033-3487.png)
LAN-68
< DTC/CIRCUIT DIAGNOSIS >[CAN]
ECM BRANCH LINE CIRCUIT
ECM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006220544
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the ECM for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ECM.
2. Check the resistance between the ECM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ECM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ECM. Refer to EC-168, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the ECM. Refer to EC-535, "Removal and Installation".
YES (Past error)>>Error was detected in the ECM branch line.
NO >> Repair the power supply and the ground circuit.
ECM harness connector Resistance (Ω)
Connector No. Terminal No.
E80 146 151 Approx. 108 – 132
Revision: 2010 May2011 QX56
