P1817 TRANSFER MOTORDLN-71
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
2. Turn the actuator shaft. Refer to DLN-114, "Inspection".
3. Check “ROTARY POSI SEN” of CONSULT-II I “DATA MONITOR” for “ALL MODE AWD/4WD”.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Transfer assembly is mechanical malfunction. Replace transfer assembly. Refer to DLN-121,
"Removal and Installation".
4.CHECK TERMINALS AND HARNESS CONNECTORS
Check the pin terminals for damage or loose connection with each harness connector.
Is the inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Component InspectionINFOID:0000000006222270
1.CHECK TRANSFER MOTOR
1. Remove transfer control actuator. Refer to DLN-114, "
Exploded View".
2. Apply 12 V to transfer control actuator connector No. 1 terminal and No. 8 terminal.
CAUTION:
Never make the terminals short.
Connect the fuse between the term inals when applying the voltage.
3. Check the operation of transfer control actuator.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace transfer control actuator. Refer to DLN-114, "
Exploded View".
Monitor item Condition Status
ROTARY POSI SEN Turn the actuator shaft. Value is changing
Transfer control actuator Condition Operation
Te r m i n a l
18 Apply the voltage between No. 1 (+)
terminal and No. 8 (
−) terminal. Operate clockwise
Apply the voltage between No. 1 ( −)
terminal and No. 8 (+) terminal. Operate counter-
clockwise
Revision: 2010 May2011 QX56
Page 1874 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-72
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181A TRANSFER MOTOR TEMPERATURE SENSOR
P181A TRANSFER MOTOR TEMPERATURE SENSOR
DTC LogicINFOID:0000000006222271
DTC DETECTION LOGIC
DTC CONFIRMATIO INFINITI QX56 2011 Factory Service Manual
DLN-72
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181A TRANSFER MOTOR TEMPERATURE SENSOR
P181A TRANSFER MOTOR TEMPERATURE SENSOR
DTC LogicINFOID:0000000006222271
DTC DETECTION LOGIC
DTC CONFIRMATIO](/manual-img/42/57033/w960_57033-1873.png)
DLN-72
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181A TRANSFER MOTOR TEMPERATURE SENSOR
P181A TRANSFER MOTOR TEMPERATURE SENSOR
DTC LogicINFOID:0000000006222271
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Start the engine and drive at 40 km/h (25 MPH) or more for approximately 1minute.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P181A” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-72, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222272
1.CHECK TRANSFER MOTOR TEMPERATURE SENSOR POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect transfer control actuator harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer contro l actuator harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK TRANSFER MOTOR TEMPERATURE SENSOR CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer control actuator har-
ness connector.
4. Check the continuity between transfer control actuator harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
P181A MOTOR TEMP SEN When vehicle speed is 40km/h or more
and transfer motor temperature is lower
than normal
Transfer control actuator
Malfunction of transfer motor temper-
ature sensor circuit. (open)
When transfer motor temperature is
higher than normal Transfer control actuator
Malfunction of transfer motor temper-
ature sensor circuit. (short)
+ −
Voltag e
Transfer control actuator
Connector Terminal F52 4 7 Approx. 5 V
Transfer control unit Transfer control actuator Continuity
Connector Terminal Connector Terminal
E59 28
F52 4
Existed
97
Revision: 2010 May2011 QX56
Page 1875 of 5598
![INFINITI QX56 2011 Factory Service Manual
P181A TRANSFER MOTOR TEMPERATURE SENSOR
DLN-73
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace e INFINITI QX56 2011 Factory Service Manual
P181A TRANSFER MOTOR TEMPERATURE SENSOR
DLN-73
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace e](/manual-img/42/57033/w960_57033-1874.png)
P181A TRANSFER MOTOR TEMPERATURE SENSOR
DLN-73
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
3.CHECK TRANSFER MOTOR TEMPERATURE SENSOR
Check the transfer control actuator. Refer to DLN-73, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Transfer motor temperature sensor is malfuncti oning. Replace transfer control actuator. Refer to
DLN-114, "
Exploded View".
4.CHECK TERMINALS AND HARNESS CONNECTORS
Check the pin terminals for damage or loose connection with each harness connector.
Is the inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Component InspectionINFOID:0000000006222273
1.CHECK TRANSFER MOTOR TEMPERATURE SENSOR
1. Turn the ignition switch OFF.
2. Disconnect transfer control actuator harness connector.
3. Check the resistance between transfer cont rol actuator harness connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Transfer motor temperature sensor is malfuncti oning. Replace transfer control actuator. Refer to
DLN-114, "
Exploded View".
Transfer control actuator —Continuity
Connector Terminal
F52 7 Ground Not existed
Transfer control actuator Condition Resistance
Te r m i n a l
47 20
°C (68 °F) Approx. 12.5 k Ω
80 °C (176 °F) Approx. 1.3 k Ω
Revision: 2010 May2011 QX56
Page 1876 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-74
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181B INCOMPLETE SELFSHUT
P181B INCOMPLETE SELFSHUT
DTC LogicINFOID:0000000006222274
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTI INFINITI QX56 2011 Factory Service Manual
DLN-74
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181B INCOMPLETE SELFSHUT
P181B INCOMPLETE SELFSHUT
DTC LogicINFOID:0000000006222274
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTI](/manual-img/42/57033/w960_57033-1875.png)
DLN-74
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181B INCOMPLETE SELFSHUT
P181B INCOMPLETE SELFSHUT
DTC LogicINFOID:0000000006222274
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P181B” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-74, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222275
1.CHECK TRANSFER CONTROL UNIT POWER SUPPLY (1)
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the voltage between transfer control unit harness connector and ground.
4. Turn the ignition switch ON. CAUTION:
Never start the engine.
5. Check the voltage between transfer control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK TRANSFER CONTROL UNIT POWER SUPPLY (2)
1. Turn the ignition switch OFF.
2. Check the 10A fuse (#34).
3. Check the harness for open or short between transfe r control unit harness connector No.20 terminal and
10A (#34).
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit. Refer to PG-11, "Wiring Diagram - BAT-
TERY POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
3.CHECK TRANSFER CONTROL UNIT GROUND
1. Turn the ignition switch OFF.
DTC Display item Malfunction detected condition Possible cause
P181B IMCOMP SELFSHUT When ignition switch is OFF and transfer
control unit power su
pply is lower or
higher than normal Self-shut is incomplete.
Transfer control unit
—Voltage
Connector Terminal
E59 20 Ground Battery voltage
Transfer control unit —Voltage
Connector Terminal
E59 20 Ground Battery voltage
Revision: 2010 May2011 QX56
Page 1877 of 5598
P181B INCOMPLETE SELFSHUTDLN-75
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
2. Check the continuity between transfer control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK TERMINALS AND HARNESS CONNECTORS
Check transfer control unit pin terminals for damage or loose connection with harness connector.
Is inspection result normal?
YES >> After turning the ignition switch OFF, perform DTC confirmation procedure again. When DTC
"P181B" is detected, Replace transfer control unit. Refer to DLN-107, "
Removal and Installation".
NO >> Repair or replace error-detected parts.
Transfer control unit —Continuity
Connector Terminal
E60 44
Ground Existed
46
Revision: 2010 May2011 QX56
Page 1878 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-76
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181C TRANSFER MOTOR POWER SUPPLY
P181C TRANSFER MO
TOR POWER SUPPLY
DescriptionINFOID:0000000006222276
Supplies power to transfer control actuator INFINITI QX56 2011 Factory Service Manual
DLN-76
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181C TRANSFER MOTOR POWER SUPPLY
P181C TRANSFER MO
TOR POWER SUPPLY
DescriptionINFOID:0000000006222276
Supplies power to transfer control actuator](/manual-img/42/57033/w960_57033-1877.png)
DLN-76
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181C TRANSFER MOTOR POWER SUPPLY
P181C TRANSFER MO
TOR POWER SUPPLY
DescriptionINFOID:0000000006222276
Supplies power to transfer control actuator (transfer motor).
DTC LogicINFOID:0000000006222277
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P181C” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-76, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222278
1.CHECK TRANSFER MOTOR POWER SUPPLY (2)
Check the voltage between transfer control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK TRANSFER MOTOR POWER SUPPLY CIRCUIT (2)
1. Turn the ignition switch OFF.
2. Check the 30A fusible link (J).
3. Check the harness for open or short between transfe r control unit harness connector No.41 terminal and
30A fusible link (J).
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit. Refer to PG-11, "Wiring Diagram - BAT-
TERY POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
3.CHECK TERMINALS AND HARNESS CONNECTORS
Check the pin terminals for damage or loose connection with each harness connector.
Is the inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P181C MOTOR POWER SUPPLY When transfer control actuator power
supply is lower or higher than normalMalfunction of transfer control actuator
(transfer motor) powe
r supply circuit
+ −
Voltag e
Transfer control unit
Connector Terminal E60 41 46 Battery voltage
Revision: 2010 May2011 QX56
Page 1879 of 5598
![INFINITI QX56 2011 Factory Service Manual
P181E STEERING ANGLE SENSORDLN-77
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P181E STEERING ANGLE SENSOR
DTC LogicINFOID:0000000006222279
DTC DETECTION LOGIC
DTC CO INFINITI QX56 2011 Factory Service Manual
P181E STEERING ANGLE SENSORDLN-77
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P181E STEERING ANGLE SENSOR
DTC LogicINFOID:0000000006222279
DTC DETECTION LOGIC
DTC CO](/manual-img/42/57033/w960_57033-1878.png)
P181E STEERING ANGLE SENSORDLN-77
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P181E STEERING ANGLE SENSOR
DTC LogicINFOID:0000000006222279
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P181E” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-77, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222280
1.PERFORM ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-III
Perform self-diagnosis for “ABS”.
Is DTC
“C1143” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-97, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK CAN COMMUNICATION LINE
Check communication line. Refer to LAN-69, "
Diagnosis Procedure".
Is inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P181E ST ANGLE SEN SIG Malfunction is detected in steering angle
sensor signal through CAN communica-
tion. Harness or connector (CAN communi-
cation line)
Steering angle sensor
- Steering angle sensor error
- Malfunction of steering angle sensor circuit error
Revision: 2010 May2011 QX56
Page 1880 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-78
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181F INCOMPLETE CALIBRATION
P181F INCOMPLETE CALIBRATION
DTC LogicINFOID:0000000006222281
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPR INFINITI QX56 2011 Factory Service Manual
DLN-78
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181F INCOMPLETE CALIBRATION
P181F INCOMPLETE CALIBRATION
DTC LogicINFOID:0000000006222281
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPR](/manual-img/42/57033/w960_57033-1879.png)
DLN-78
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P181F INCOMPLETE CALIBRATION
P181F INCOMPLETE CALIBRATION
DTC LogicINFOID:0000000006222281
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P181F” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-78, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222282
1.PERFORM INITIAL CALIBRATION
1. Erase self-diagnostic result for “ALL MODE AWD/4WD”.
2. Perform initial calibration. Refer to DLN-41, "
Work Procedure".
3. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is any DTC except
“P181F” detected?
YES >> Check DTC.
NO >> GO TO 2.
2.PERFORM SELF-DIAGNOSIS
With CONSULT-III
1. Erase self-diagnostic result for “ALL MODE AWD/4WD”.
2. Turn the ignition switch OFF, and then wait 10 seconds or more.
3. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P181F” detected?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Check transfer control unit pin terminals fo r damage or loose connection with harness connector.
If any items are damaged, repair or replace the error-detected parts.
DTC Display item Malfunction detected condition Possible cause
P181F INCOMP CALIBRATION When incomplete calibration of transfer
control unit is detected.Initial calibration of transfer is incom-
plete
Revision: 2010 May2011 QX56
