Page 4977 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-184
< DTC/CIRCUIT DIAGNOSIS >
B1304 SATELLITE SEN RH
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4978 of 5598

INFINITI QX56 2011 Factory Service Manual
B1306, B1308, B1309, B1310 SATELLITE SEN RH
SRC-185
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1306, B1308, B1309, B1310 SATELLITE SEN RH
DTC LogicINFOID:0000000006220147
DTC DETECT

B1306, B1308, B1309, B1310 SATELLITE SEN RH
SRC-185
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
B1306, B1308, B1309, B1310 SATELLITE SEN RH
DTC LogicINFOID:0000000006220147
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-185, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220148
WARNING:
Before servicing, turn ignition s witch OFF, disconnect battery negati ve terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE REAR SATELLITE SENSOR
1. Replace rear satellite sensor RH. Refer to SR-24, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-185, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-185, "
DTC Logic".
Is DTC detected?
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1306
B1308
B1309
B1310 SATELLITE SENS RH
[COMM FAIL]
Rear satellite sensor RH is malfunctioning
or out of the specified specification Disconnection of wiring harness
Malfunction in rear satellite sensor RH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4979 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-186
< DTC/CIRCUIT DIAGNOSIS >
B1306, B1308, B1309, B1310 SATELLITE SEN RH
YES >> GO TO 1.
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4980 of 5598

INFINITI QX56 2011 Factory Service Manual
B1307 SATELLITE SEN RHSRC-187
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1307 SATELLITE SEN RH
DTC LogicINFOID:0000000006220149
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK

Page 4981 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-188
< DTC/CIRCUIT DIAGNOSIS >
B1311 SATELLITE SEN LH
B1311 SATELLITE SEN LH
DTC LogicINFOID:0000000006220151
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-

Page 4982 of 5598

INFINITI QX56 2011 Factory Service Manual
B1311 SATELLITE SEN LHSRC-189
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
NO >> INSPECTION END
Revision: 2010 May2011 QX56

Page 4983 of 5598

INFINITI QX56 2011 Factory Service Manual
SRC-190
< DTC/CIRCUIT DIAGNOSIS >
B1313, B1315, B1316, B1317 SATELLITE SEN LH
B1313, B1315, B1316, B1317 SATELLITE SEN LH
DTC LogicINFOID:0000000006220153
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDU

SRC-190
< DTC/CIRCUIT DIAGNOSIS >
B1313, B1315, B1316, B1317 SATELLITE SEN LH
B1313, B1315, B1316, B1317 SATELLITE SEN LH
DTC LogicINFOID:0000000006220153
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-190, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220154
WARNING:
Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait at least 3
minutes or more. (To discharge backup capacitor.)
Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connector.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE REAR SATELLITE SENSOR
1. Replace rear satellite sensor LH. Refer to SR-24, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-190, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-190, "
DTC Logic".
Is DTC detected?
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1313
B1315
B1316
B1317 SATELLITE SENS LH
[COMM FAIL]
Rear satellite sensor LH is malfunctioning
or out of the specified specification Disconnection of wiring harness
Malfunction in rear satellite sensor LH
Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

Page 4984 of 5598

INFINITI QX56 2011 Factory Service Manual
B1313, B1315, B1316, B1317 SATELLITE SEN LH
SRC-191
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
YES >> GO TO 1.
NO >> INSPECTION END
Revision: 2010 May2011 QX56
