Page 1177 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-212
< REMOVAL AND INSTALLATION >[DCA]
ICC SENSOR
REMOVAL AND INSTALLATION
ICC SENSOR
Exploded ViewINFOID:0000000006228177
CAUTION:
Always perform the laser beam aiming adjustme
nt and check the o

Page 1178 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
ACCELERATOR PEDAL ASSEMBLYDAS-213
< REMOVAL AND INSTALLATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
ACCELERATOR PEDAL ASSEMBLY
Exploded ViewINFOID:0000000006223668
Refer to ACC-4, "MODELS WITH DI

Page 1179 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-214
< REMOVAL AND INSTALLATION >[DCA]
DYNAMIC DRIVER ASSISTANCE SWITCH
DYNAMIC DRIVER ASSISTANCE SWITCH
Exploded ViewINFOID:0000000006223669
Dynamic driver assistance switch is integr
ated in the

Page 1180 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
PRECAUTIONSDAS-215
< PRECAUTION > [FCW]
C
D
E
F
G H
I
J
K L
M B
N P A
PRECAUTION
PRECAUTIONS
Precaution for FCW System ServiceINFOID:0000000006223670
CAUTION:
Never look straight into th e lase

Page 1181 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-216
< SYSTEM DESCRIPTION >[FCW]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006223671
Component DescriptionINFOID:0000000006223672
1. Information disp

Page 1182 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
COMPONENT PARTSDAS-217
< SYSTEM DESCRIPTION > [FCW]
C
D
E
F
G H
I
J
K L
M B
N P A
Warning systems ON indicator
(In the warning systems switch) Turns warning systems ON indicator ON/OFF according

Page 1183 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-218
< SYSTEM DESCRIPTION >[FCW]
SYSTEM
SYSTEM
System DescriptionINFOID:0000000006223673
SYSTEM DIAGRAM
ADAS CONTROL UNIT INPU
T/OUTPUT SIGNAL ITEM
Input Signal Item
Output Signal Item
DESCRIPTION

Page 1184 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
SYSTEM
DAS-219
< SYSTEM DESCRIPTION >[FCW]
C
D
E
F
G H
I
J
K L
M B
N P A
The FCW system will function when own vehicle is dr iven at speeds of approximately 15 km/h (10 MPH) and
above.
NOTE:
Th

DAS
SYSTEM
DAS-219
< SYSTEM DESCRIPTION >[FCW]
C
D
E
F
G H
I
J
K L
M B
N P A
The FCW system will function when own vehicle is dr iven at speeds of approximately 15 km/h (10 MPH) and
above.
NOTE:
The FCW system shares the di agnosis function with ICC system.
FUNCTION DESCRIPTION
The distance from the vehicle ahead and a relative speed are calculated by using the ICC sensor and an ICC
sensor signal is transmitted to t he ADAS control unit via ITS communi cation. When judging the necessity of
warning according to the received vehicle ahead detection signal, the ADAS control unit transmits a buzzer
output signal and meter display signal to the combination meter via CAN communication.
FCW Operating Condition
Warning systems ON indicator: ON
Vehicle speed: Approximately 15 km/h (10 MPH) and above.
Fail-safe Indication
FCW INITIAL STATE CHANGE
CAUTION:
Never change FCW initial state “ON” ⇒ “OFF” without the con sent of the customer.
FCW initial state can be changed.
FCW initial ON* - FCW function is automatically turned ON, when the ignition switch OFF ⇒ ON.
FCW initial OFF - FCW function is still OFF when the ignition switch OFF ⇒ ON.
*: Factory setting
How to change FCW/LDW/BSW initial state1. Turn ignition switch ON.
2. Warning systems switch is OFF.
3. Push and hold warning systems switch for more than 4 seconds.
4. Buzzer sounds and blinking of the warning systems ON indicator informs that the FCW/LDW/BSW initial
state change is completed.
Fail-safe (ADAS Control Unit)INFOID:0000000006223674
If a malfunction occurs in each s ystem, ADAS control unit cancels eac h control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Vehicle condition Indication on the combination meter
When the FCW system malfunctions
When the sensor window is dirty
When driving into a strong light (i.e. sunlight)
NOTE:
Check that the IBA system is not OFF. The indicator lamp is shared
with IBA system.
JPOIA0179ZZ
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warning lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
toneICC system warning lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
tone
IBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
tone
IBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
toneICC system warning lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56
