PCS-64
< DTC/CIRCUIT DIAGNOSIS >[POWER DISTRIBUTION SYSTEM]
B261A PUSH-BUTTON IGNITION SWITCH
B261A PUSH-BUTTON IGNITION SWITCH
DTC LogicINFOID:0000000006220214
DTC DETECTION LOGIC
NOTE:
If DTC B261A is displayed with DTC U1000, first
perform the trouble diagnosis for DTC U1000. Refer to
BCS-70, "
DTC Logic".
If DTC B261A is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
BCS-71, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press the push-button ignition switch under the fo llowing conditions, and wait for 1 second or more.
- Selector lever is in the P or N position
- Do not depress brake pedal
2. Check “Self-diagnosis result” of BCM with CONSULT-III.
Is DTC detected?
YES >> Go to PCS-64, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006220215
1.CHECK IGNITION SWITCH OUTPUT SIGNAL (PUSH-BUTTON IGNITION SWITCH)
1. Disconnect push-button ignition swit ch connector and IPDM E/R connector.
2. Check voltage between push-button ignition switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK PUSH-BUTTON IGNITION SWITCH CIRCUIT (BCM)
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and push-button ignition switch harness connector.
3. Check continuity between push-button ignition switch harness connector and ground.
DTC No.Trouble diagnosis
name DTC detecting condition Possible cause
B261A PUSH-BTN IGN SW BCM detects a difference of signal for 1 second or
more between the following items.
Push-button ignition switch signal
Push-button ignition switch status signal (CAN) Harness or connectors
(Push-button ignition switch circuit
is open or shorted.)
BCM
IPDM E/R
(+)
(–)Voltage (V)
(Approx.)
Push-button ignition switch
Connector Terminal M101 4 Ground 12
BCM Push-button ignition switch Continuity
Connector Terminal Connector Terminal
M71 100 M101 4 Existed
Push-button ignition switch GroundContinuity
Connector Terminal
M101 4 Not existed
Revision: 2010 May2011 QX56
