P2127, P2128 APP SENSOREC-473
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
7.DETECT MALFUNCTIONING PART
Check the following.
Loose or poor connection for each connector and harness
Harness for open or short between ECM and APP sensor
>> Repair open circuit, short to ground or short to power in harness or connectors.
8.CHECK APP SENSOR 2 INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between APP sens or harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and APP sensor
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
10.CHECK APP SENSOR
Refer to EC-474, "
Component Inspection (Accelerator Pedal Position Sensor)".
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 11.
11 .REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly. Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASSIST
SYSTEM : Removal and Installation" (Without distance control assist system) or ACC-4, "MODELS WITH
DISTANCE CONTROL ASSIST SYSTEM : Removal and Installation" (With distance control assist system).
>> INSPECTION END
12.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E110
(Without ICC) 5
E80 129 Existed
E67
(With ICC) 8
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E110
(Without ICC) 6
E80 126 Existed
E67
(With ICC) 7
Revision: 2010 May2011 QX56
Page 2498 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-474
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2127, P2128 APP SENSOR
>> INSPECTION END
Component Inspection (Accele
rator Pedal Position Sensor)INFOID:0000000006217977
1.CHECK ACCELERATOR PEDAL POSITION INFINITI QX56 2011 Factory Service Manual
EC-474
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2127, P2128 APP SENSOR
>> INSPECTION END
Component Inspection (Accele
rator Pedal Position Sensor)INFOID:0000000006217977
1.CHECK ACCELERATOR PEDAL POSITION](/manual-img/42/57033/w960_57033-2497.png)
EC-474
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2127, P2128 APP SENSOR
>> INSPECTION END
Component Inspection (Accele
rator Pedal Position Sensor)INFOID:0000000006217977
1.CHECK ACCELERATOR PEDAL POSITION SENSOR
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Turn ignition switch ON.
4. Check the voltage ECM harness connector terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly. Refer to ACC-3, "
MODELS WITHOUT DISTANCE CONTROL ASSIST
SYSTEM : Removal and Installation" (Without distance control assist system) or ACC-4, "MODELS WITH
DISTANCE CONTROL ASSIST SYSTEM : Removal and Installation" (With distance control assist system).
>> INSPECTION END
ECM Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
E80 136 (APP sensor 1) 140
Accelerator pedalFully released 0.65 - 0.87
Fully depressed 4.3 - 4.8
126 (APP sensor 2) 129 Fully released 0.28 - 0.48
Fully depressed 2.0 - 2.5
Revision: 2010 May2011 QX56
Page 2499 of 5598
![INFINITI QX56 2011 Factory Service Manual
P2135 TP SENSOREC-475
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2135 TP SENSOR
DTC LogicINFOID:0000000006217978
DTC DETECTION LOGIC
NOTE:
If DTC P2135 is displayed with DTC INFINITI QX56 2011 Factory Service Manual
P2135 TP SENSOREC-475
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2135 TP SENSOR
DTC LogicINFOID:0000000006217978
DTC DETECTION LOGIC
NOTE:
If DTC P2135 is displayed with DTC](/manual-img/42/57033/w960_57033-2498.png)
P2135 TP SENSOREC-475
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2135 TP SENSOR
DTC LogicINFOID:0000000006217978
DTC DETECTION LOGIC
NOTE:
If DTC P2135 is displayed with DTC P0643, perfo
rm the trouble diagnosis for DTC P0643. Refer to EC-
381, "DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 8 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-475, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217979
1.CHECK THROTTLE POSITION SEN SOR POWER SUPPLY CIRCUIT-I
1. Disconnect electric throttle c ontrol actuator harness connector.
2. Turn ignition switch ON.
3. Check the voltage between electric throttle control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK THROTTLE POSITI ON SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2135 TP SENSOR-B1
(Throttle position sensor circuit
range/performance) Rationally incorrect voltage is sent to
ECM compared with the signals from
TP sensor 1 and TP sensor 2. Harness or connector
(TP sensor 1 or 2 circuit is open or shorted.)
Electric throttle control actuator
(TP sensor 1 or 2)
Electric throttle control actuator Ground Voltage (V)
Connector Terminal
F66 2 Ground Approx. 5
Revision: 2010 May2011 QX56
Page 2500 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-476
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2135 TP SENSOR
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, shor INFINITI QX56 2011 Factory Service Manual
EC-476
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2135 TP SENSOR
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, shor](/manual-img/42/57033/w960_57033-2499.png)
EC-476
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2135 TP SENSOR
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK THROTTLE POSITION
SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between electric throttle control actuator harness connector and ECM harness con-
nector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK THROTTLE POSITION SENSOR
Refer to EC-476, "
Component Inspection (Throttle Position Sensor)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
Replace electric throttle control actuator. Refer to EM-30, "
Removal and Installation".
>> INSPECTION END
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (Throttle Position Sensor)INFOID:0000000006217980
1.CHECK THROTTLE POSITION SENSOR
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Perform EC-147, "
Work Procedure".
4. Turn ignition switch ON.
5. Set selector lever position to D.
6. Check the voltage between ECM harness connector terminals under the following conditions.
Electric throttle control actuator ECM Continuity
Connector Terminal Connector Terminal
F66 4 F110 97 Existed
Electric throttle control actuator ECM Continuity
Connector Terminal Connector Terminal
F66 1
F110 91
Existed
379
Revision: 2010 May2011 QX56
Page 2501 of 5598
P2135 TP SENSOREC-477
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ELECTRIC THROTTLE CONTROL ACTUATOR
Replace electric throttle control actuator. Refer to EM-30, "
Removal and Installation".
>> INSPECTION END
ECM Condition Voltage (V)
Connector +–
Terminal Terminal
F110 91
(TP sensor 1 signal) 97
(Sensor ground) Accelerator pedal Fully released More than 0.36
Fully depressed Less than 4.75
79
(TP sensor 2 signal) Fully released Less than 4.75
Fully depressed More than 0.36
Revision: 2010 May2011 QX56
Page 2502 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-478
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
P2138 APP SENSOR
DTC LogicINFOID:0000000006217981
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with DTC P0643, first pe
rform the trou INFINITI QX56 2011 Factory Service Manual
EC-478
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
P2138 APP SENSOR
DTC LogicINFOID:0000000006217981
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with DTC P0643, first pe
rform the trou](/manual-img/42/57033/w960_57033-2501.png)
EC-478
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
P2138 APP SENSOR
DTC LogicINFOID:0000000006217981
DTC DETECTION LOGIC
NOTE:
If DTC P2138 is displayed with DTC P0643, first pe
rform the trouble diagnosis for DTC P0643. Refer to
EC-381, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 8 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-478, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217982
1.CHECK ACCELERATOR PEDAL POSITION SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2138 APP SENSOR
(Accelerator pedal position
sensor circuit range/perfor-
mance) Rationally incorrect voltage is
sent to ECM compared with
the signals from APP sensor 1
and APP sensor 2. Harness or connectors
(APP sensor 1 or 2 circuit is open or shorted.)
[CKP sensor circuit is shorted.]
[CMP sensor (bank 1) circuit is shorted.]
(Battery current sensor circuit is shorted.)
(Refrigerant pressure sensor circuit is shorted.)
(EVAP control system pressure sensor circuit is short-
ed.)
Accelerator pedal position sensor (APP sensor 1 or 2)
Crankshaft position sensor
Camshaft position sensor (bank 1)
Refrigerant pressure sensor
Battery current sensor
EVAP control system pressure sensor
APP sensor Ground Voltage (V)
Connector Terminal
E110
(Without ICC) 2
Ground Approx. 5
E67
(With ICC) 12
Revision: 2010 May2011 QX56
Page 2503 of 5598
![INFINITI QX56 2011 Factory Service Manual
P2138 APP SENSOREC-479
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Loose or poor connection f INFINITI QX56 2011 Factory Service Manual
P2138 APP SENSOREC-479
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Loose or poor connection f](/manual-img/42/57033/w960_57033-2502.png)
P2138 APP SENSOREC-479
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Loose or poor connection for each connector and harness
Harness for open or short between ECM and APP sensor
>> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1. Turn ignition switch ON.
2. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 4.
4.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sens or harness connector and ECM harness connector.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and accelerator pedal position sensor
Loose or poor connection for each connector and harness
>> Repair open circuit.
6.CHECK SENSOR POWER SUPPLY CIRCUIT
Check harness for short to power and short to ground, between the following terminals.
APP sensor
Ground Voltage (V)
Connector Terminal
E110
(Without ICC) 1
Ground Approx. 5
E67
(With ICC) 9
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E110
(Without ICC) 1
E80 131 Existed
E67
(With ICC) 9
ECM Sensor
Connector Terminal Name Connector Terminal
F110 76 Crankshaft position sensor F74 1
77 Camshaft position sensor (bank 1) F84 1
Revision: 2010 May2011 QX56
Page 2504 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-480
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair short to ground or short to power in harness or connectors.
7.CHECK COMPONENTS
INFINITI QX56 2011 Factory Service Manual
EC-480
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair short to ground or short to power in harness or connectors.
7.CHECK COMPONENTS](/manual-img/42/57033/w960_57033-2503.png)
EC-480
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair short to ground or short to power in harness or connectors.
7.CHECK COMPONENTS
Check the following.
Crankshaft position sensor (Refer to EC-301, "
Component Inspection (Crankshaft Position Sensor)".)
Camshaft position sensor (bank 1) (Refer to EC-306, "
Component Inspection (Camshaft Position Sensor)".)
Refrigerant pressure sensor (Refer to EC-520, "
Component Function Check".)
EVAP control system pressure sensor (Refer to EC-335, "
Component Inspection (EVAP Control System
Pressure Sensor)".)
Is the inspection result normal?
YES >> GO TO 14.
NO >> Replace malfunctioning component.
8.CHECK APP SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sens or harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and accelerator pedal position sensor
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
10.CHECK APP SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between APP sens or harness connector and ECM harness connector.
E80133Battery current sensor E63 2
Refrigerant pressure sensor E77 1
EVAP control system pressure sen-
sor
C17 3
131 APP sensor (Without ICC) E110 1
APP sensor (with ICC) E67 9
ECM Sensor
Connector Terminal Name Connector Terminal
APP sensor ECM Continuity
Connector Terminal Connector Terminal
E110
(Without ICC) 4
E80 140
Existed
5129
E67
(With ICC) 11
E80 140
Existed
8129
Revision: 2010 May2011 QX56
