Page 1401 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-436
< ECU DIAGNOSIS INFORMATION >[BSW]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP O

DAS-436
< ECU DIAGNOSIS INFORMATION >[BSW]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON indicator lamp OFF Off
LANE DPRT W/L Drive the vehicle and activate
the LDW system or LDP sys-
tem Lane departure warning lamp ON On
Lane departure warning lamp OFF Off
LDW BUZER OUT-
PUT Drive the vehicle and activate
the LDW/LDP system or BSW
system When the buzzer of the following system operates
LDW/LDP system
BSW system
On
When the buzzer of the following system does not oper-
ate
LDW/LDP system
BSW system Off
LDP SYSTEM ON Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
READY signal Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
Camera lost Drive the vehicle and activate
the LDW system, LDP system Both side lane markers are detected Detect
Deviate side lane marker is lost Deviate
Both side lane markers are lost Both
Shift position Engine running
While driving Displays the
shift position
Turn signal Turn signal lamps OFF
Off
Turn signal lamp LH blinking LH
Turn signal lamp RH blinking RH
Turn signal lamp LH and RH blinking LH&RH
SIDE G While driving Vehicle turning right Negative value
Vehicle turning left Positive value
WARN REQ Drive the vehicle and activate
the LDP system Lane departure warning is operating On
Lane departure warning is not operating Off
STATUS signal Drive the vehicle and activate
the LDP system When the LDP system is ON Stnby
When the LDP system is operating Warn
When the LDP system is canceled Cancl
When the LDP system is OFF Off
Lane unclear While driving Lane marker is unclear On
Lane marker is clear Off
FUNC ITEM Ignition switch ON FUNC1
FUNC ITEM (NV-ICC) Ignition switch ON Off
FUNC ITEM (NV-
DCA) Ignition switch ON
Off
DCA SELECT Ignition switch ON “Distance Control Assist” set with the navigation system
is ON
On
“Distance Control Assist” set with the navigation system
is OFF Off
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

Page 1402 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-437
< ECU DIAGNOSIS INFORMATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
TERMINAL LAYOUT
PHYSICAL VALUES
LDP SELECT Ignition switch ON “Lane Departure Prevention” set with t

Page 1403 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-438
< ECU DIAGNOSIS INFORMATION >[BSW]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223862
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turn

Page 1404 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-439
< ECU DIAGNOSIS INFORMATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
DTC Inspection Priority ChartINFOID:0000000006223863
If multiple DTCs are detected simultaneously, che c

Page 1405 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-440
< ECU DIAGNOSIS INFORMATION >[BSW]
ADAS CONTROL UNIT
DTC Index
INFOID:0000000006223864
NOTE:
The details of time display are as per the following.
4 C1A01: POWER SUPPLY CIR
C1A02: POWER

Page 1406 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-441
< ECU DIAGNOSIS INFORMATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
- CRNT: A malfunction is detected now
- PAST: A malfunction was detected in the past
IGN counter is di

DAS
ADAS CONTROL UNITDAS-441
< ECU DIAGNOSIS INFORMATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
- CRNT: A malfunction is detected now
- PAST: A malfunction was detected in the past
IGN counter is displayed on FFD (Freeze Frame Data).
- 0: The malfunctions that are detected now CAN communication system (U1000, U1010)
- 1 - 39: It increases like 0 → 1 → 2 ··· 38 → 39 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunc tion is detected again in the process.
- If it is over 39, it is fixed to 39 unt il the self-diagnosis results are erased.
Other than CAN communication s ystem (Other than U1000, U1010)
- 1 - 49: It increases like 0 → 1 → 2 ··· 38 → 49 after returning to the normal condition whenever the ignition
switch OFF → ON. It returns to 0 when a malfunc tion is detected again in the process.
- If it is over 49, it is fixed to 49 unt il the self-diagnosis results are erased.
Systems for fail-safe
A: Vehicle-to-vehicle distance control mode
B: Conventional (fixed speed) cruise control mode
C: Intelligent Brake Assist (IBA)
D: Forward Collision Warning (FCW)
E: Distance Control Assist (DCA)
F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
G: Blind Spot Warning (BSW)
DTC
CONSULT-III display Warning lamp Fail-safe
Reference
CONSULT-III On board
display
ICC system warning lamp
IBA OFF indicator lamp
Lane departure warning lamp BSW warning lamp
System
C1A00 0 CONTROL UNIT ON ON ON ON A, B, C, D, E, F, G DAS-470
C1A01 1 POWER SUPPLY CIR ON ON ON ON A, B, C, D, E, F, GDAS-471
C1A02 2 POWER SUPPLY CIR 2 ON ON ON ON A, B, C, D, E, F, GDAS-471
C1A03 3 VHCL SPEED SE CIRC ON ON ON ON A, B, C, D, E, F, G CCS-87
C1A04 4 ABS/TCS/VDC CIRC ON ON ON A, B, C, D, E, FCCS-89
C1A05 5 BRAKE SW/STOP L SW ON ON ON A, B, C, D, E, FCCS-90
C1A06 6 OPERATION SW CIRC ON ON A, B, E, FCCS-94
C1A12 12LASER BEAM OFFCN-
TR ON ON A, C, D, E
CCS-96
C1A13 13 STOP LAMP RLY FIX ON ON A, B, C, D, E CCS-97
C1A14 14 ECM CIRCUIT ON ON A, B, E, FCCS-103
C1A15 15 GEAR POSITION ON ON ON ON A, B, C, D, E, F, G DAS-473
C1A16 16 RADAR STAIN ON ON A, C, D, ECCS-106
C1A17 17 ICC SENSOR MALF ON ON A, B, C, D, ECCS-108
C1A18 18 LASER AIMING INCMP ON ON A, C, D, ECCS-109
C1A21 21ICC SENSOR HIGH
TEMP ON ON A, B, C, D, E
CCS-111
C1A24 24 NP RANGE ON ON ON ON A, B, C, D, E, F, G DAS-475
C1A26 26 ECD MODE MALF ON ON A, B, C, D, E CCS-115
C1A27 27 ECD PWR SUPLY CIR ON ON A, B, C, D, ECCS-116
C1A33 33CAN TRANSMISSION
ERR ON A, B, E
CCS-118
Revision: 2010 May2011 QX56

Page 1407 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS-442
< ECU DIAGNOSIS INFORMATION >[BSW]
ADAS CONTROL UNIT
C1A34 34 COMMAND ERROR ON A, B, E
CCS-119
C1A35 35 APA CIR ON A, ECCS-120
C1A36 36 APA CAN COMM CIR ON A, ECCS-121
C1A37 133 APA CAN CIR

Page 1408 of 5598

INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-443
< ECU DIAGNOSIS INFORMATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
NOTE:
With the detection of “U1000” some syst ems do not perform the fail-safe operation.
A system c

DAS
ADAS CONTROL UNITDAS-443
< ECU DIAGNOSIS INFORMATION > [BSW]
C
D
E
F
G H
I
J
K L
M B
N P A
NOTE:
With the detection of “U1000” some syst ems do not perform the fail-safe operation.
A system controlling based on a signal received from the control unit performs fail-safe operation when the
communication with the ADAS control unit becomes inoperable.
U1500 145 CAM CAN CIR 2 ON F DAS-381
U1501 146 CAM CAN CIR 1 ON FDAS-382
U1502 147ICC SEN CAN COMM
CIR ON ON A, B, C, D, E
CCS-152
U1503 150 SIDE RDR L CAN CIR 2 ON G DAS-502
U1504 151 SIDE RDR L CAN CIR 1 ON GDAS-503
U1505 152 SIDE RDR R CAN CIR 2 ON GDAS-504
U1506 153 SIDE RDR R CAN CIR 1 ON GDAS-505
U1507 154LOST COMM (SIDE
RDR R) ON G
DAS-506
U1508 155LOST COMM (SIDE
RDR L) ON G
DAS-507
U150B 157 ECM CAN CIRC 3 ON ON ON A, B, E, F, G DAS-498
U150C 158 VDC CAN CIRC 3 ON ON ON ON A, B, C, D, E, F, G DAS-499
U150D 159 TCM CAN CIRC 3 ON ON ON ON A, B, C, D, E, F, GDAS-500
U150E 160 BCM CAN CIRC 3 ON ON ON A, B, E, F, GDAS-501
U150F 161 AV CAN CIRC 3 DAS-61
U1512 162 HVAC CAN CIRC3 ON FDAS-383
U1513 163 METER CAN CIRC 3 ON ON ON ON A, B, C, D, E, F, GDAS-508
U1514 164 STRG SEN CAN CIRC 3 ON ON ON A, B, C, D, E, GDAS-509
U1515 165 ICC SENSOR CAN
CIRC 3 ON ON A, B, C, D, E
CCS-155
U1516 166 CAM CAN CIRC 3 ON F DAS-385
U1517 167 APA CAN CIRC 3 ON A, B, ECCS-156
U1518 168 SIDE RDR L CAN CIRC 3 ON G DAS-510
U1519 169SIDE RDR R CAN CIRC
3 ON G
DAS-511
U1520 176 4WD CAN CIRC 3 ON ON ON A, B, C, D, E, F CCS-157
Systems for fail-safe
A: Vehicle-to-vehicle distance control mode
B: Conventional (fixed speed) cruise control mode
C: Intelligent Brake Assist (IBA)
D: Forward Collision Warning (FCW)
E: Distance Control Assist (DCA)
F: Lane Departure Warning (LDW)/Lane Departure Prevention (LDP)
G: Blind Spot Warning (BSW)
DTC
CONSULT-III display Warning lamp Fail-safe
Reference
CONSULT-III On board
display
ICC system warning lamp
IBA OFF indicator lamp
Lane departure warning lamp BSW warning lamp
System
Revision: 2010 May2011 QX56
