REAR WIPER ARM
REAR WIPER ARM
Exploded ViewINFOID:0000000006220420
Removal and InstallationINFOID:0000000006220421
REMOVAL
1. Operate rear wiper to the auto stop position.
2. Remove rear wiper arm cover.
3. Remove rear wiper arm mounting nut.
4. Remove wiper arm from the vehicle.
INSTALLATION
1. Clean wiper arm mount as shown in the figure to prevent nutfrom being loosened.
2. Operate the rear wiper motor to the auto stop position.
3. Adjust the rear wiper blade position. Refer to WW-74, "
Adjust-
ment".
4. Install the rear wiper arm by tightening the mounting nut.
5. Inject the washer fluid.
6. Operate the rear wiper to the auto stop position.
7. Check that the rear wiper blades stop at the specified position.
8. Install the rear wiper arm cover.
AdjustmentINFOID:0000000006220422
REAR WIPER BLADE POSITION ADJUSTMENT
Set the wiper blade top on the defrosting wire (A) (c learance between the end of back door glass and the top
of wiper blade center).
1. Rear wiper motor 2. Pivot seal 3. Rear wiper arm
4. Rear wiper arm cover 5. Rear wiper blade
Refer to GI-4, "
Components" for symbols in the figure.
JMLIA0942GB
SKIA0082J
Revision: 2010 May2011 QX56
Page 5594 of 5598
REAR WIPER ARMWW-75
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Standard clearance
L : 88.5 ±7.5 mm (3.484 ± 0.295 in)
JMLIA1112ZZ
Revision: 2010 May2011 QX56
Page 5595 of 5598
WW-76
< REMOVAL AND INSTALLATION >
REAR WIPER MOTOR
REAR WIPER MOTOR
Exploded ViewINFOID:0000000006220423
Removal and InstallationINFOID:0000000006220424
REMOVAL
1. Remove rear wiper arm. Refer to WW-74, "Removal and Installation".
2. Remove back door finisher inner. Refer to INT-39, "
Removal and Installation".
3. Disconnect rear wiper motor connector.
4. Remove rear wiper motor mounting bolts.
5. Remove rear wiper motor from the vehicle.
6. Remove the pivot seal.
INSTALLATION
Install in the reverse order of removal.
1. Rear wiper motor 2. Pivot seal 3. Rear wiper arm
4. Rear wiper arm cover 5. Rear wiper blade
Refer to GI-4, "
Components" for symbols in the figure.
JMLIA0942GB
Revision: 2010 May2011 QX56
Page 5596 of 5598
REAR WASHER NOZZLE AND TUBEWW-77
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
REAR WASHER NOZZLE AND TUBE
Hydraulic LayoutINFOID:0000000006220425
Removal and InstallationINFOID:0000000006220426
REMOVAL
1. Remove rear spoiler. Refer to EXT-41, "Removal and Installation".
2. Remove high-mounted stop lamp. Refer to EXL-140, "
Removal and Installation".
1. Rear washer nozzle 2. Rear washer tube 3. Washer tank
