2011 INFINITI QX56 Factory Service Manual

airbag window center console headlight bulb fuse box hood open

Load previous 8 pages

Page 169 of 5598

INFINITI QX56 2011 Factory Service Manual
AV
SYSTEMAV-21
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
Around view monitor screen transition
FRONT VIEW The front view image is from the front camera.
When the selector lever is in any

Page 170 of 5598

INFINITI QX56 2011 Factory Service Manual
AV-22
< SYSTEM DESCRIPTION >
SYSTEM
Front view guiding lines
REAR VIEW The rear view image is from the rear camera.
When the selector lever is in the reverse position, the rear view is displayed.

Page 171 of 5598

INFINITI QX56 2011 Factory Service Manual
AV
SYSTEMAV-23
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
Front-side view area and guiding line
BIRDS-EYE VIEW The image from the 4 cameras is cut out and convert ed into the overhead view,

Page 172 of 5598

INFINITI QX56 2011 Factory Service Manual
AV-24
< SYSTEM DESCRIPTION >
SYSTEM
Birds-Eye view display area
Camera Image Operation Principle
If the information writing to around view monitor control unit and the information from the camera a

AV-24
< SYSTEM DESCRIPTION >
SYSTEM
Birds-Eye view display area
Camera Image Operation Principle
If the information writing to around view monitor control unit and the information from the camera are not
matched, the applicable camera position is indicated as an error on the Birds-Eye view display. (Calibration
operation is necessary when replacing each camera or when replacing around view monitor control unit.)
Around view monitor control unit receives the camera switch signal from AV control unit via AV communica-
tion by pressing the “CAMERA” switch of multifunction switch.
Around view monitor control unit that receives the ca mera switch signal supplies the power to each camera
and inputs the camera image from each camera.
When the selector lever is in the reverse position, around view monitor control unit receives the reverse sig- nal, supplies the power to each camera, and inputs the camera image from each camera.
Around view monitor control unit that receives the camera image signal from each camera cuts out the
required screen for each view, superimposes the camera image, vehicle icon, guiding lines, sonar indicator,
and outputs them to the front display unit.
CAMERA ASSISTANCE SONAR FUNCTION
Install the corner sensor on the front bumper and r ear bumper. It detects the obstacles around the vehicle
when the around view monitor is displayed. It warn s of the approach to the obstacles with the buzzer and
indicator in the display linked with the around view monitor system.
It displays the distance between the bumper and obstacle with the color of sonar indicator in the display and the blinking cycle of indicator in 3 stages.
The buzzer warns of the distance to the obstacles with the cycle in 3 stages.
System Operation Description
Around view monitor control unit transmits the sonar operation signal via AV communication to sonar control
unit to control the operation of sonar indicator and sonar buzzer.
Sonar control unit that receives the sonar operation signal from around view monitor control unit transmits
the detection signal and detection distance signal according to the signal from corner sensor via AV commu-
nication to around view monitor control unit. Around vi ew monitor control unit operates the applicable sonar
indicator.
When receiving a sonar operation signal from the around view monitor control unit, the sonar control unit
converts a signal transmitted from the corner sensor into a detection distance signal and transmits it to the
AV control unit via AV communication. When receivi ng the detection signal, the AV control unit activates
each speaker via BOSE amp.
JSNIA0775GB
Revision: 2010 May2011 QX56

Page 173 of 5598

INFINITI QX56 2011 Factory Service Manual
AV
SYSTEMAV-25
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
Sonar control unit has the diagnosis function. It can det ect the corner sensor malfunction or sensor harness
open circuit. It tra

Page 174 of 5598

INFINITI QX56 2011 Factory Service Manual
AV-26
< SYSTEM DESCRIPTION >
SYSTEM
Color and blinking cycle of sonar indicator
Sonar Buzzer Operation
Each sonar sensor transmits a sensor signal to the sonar control unit when detecting an obstac

Page 175 of 5598

INFINITI QX56 2011 Factory Service Manual
AV
SYSTEMAV-27
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
When the light switch is in the 1st or 2nd position, the dimming of the display is judged according to a dimming
signal transmitted

AV
SYSTEMAV-27
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
When the light switch is in the 1st or 2nd position, the dimming of the display is judged according to a dimming
signal transmitted from BCM to the AV control unit. Dis play illuminance is independent of vehicle exterior illu-
minance detected by the auto light detecting sensor ev en when the light switch is in 1st or 2nd position.
MULTI AV SYSTEM : Fail-SafeINFOID:0000000006216217
When the ambiance temperature becomes extremely low or extremely high, AV control unit displays the mes-
sage and limits the AV control unit function.
FAIL-SAFE CONDITIONS
When the ambiance temperature is −20 °C ( −4 °F) or lower, or when it is 70 °C (158 °F) or higher
Display
The messages displayed on fail-safe conditions are as shown below:
DESCRIPTION OF CONTROLS
Ability Operation Mode
There is an ability operation mode for Fail-safes due to low or high ambiance temperature.
If HDD data can be read, fail-safe is shown, then normal displays are displayed only for functions which can be
operated.
RELEASE CONDITIONS OF FAIL-SAFE
Fail-safe is released on following conditions and normal mode is restored.
When The Temperature of HDD Is Low or High
If the ambient temperature becomes out of fa il-safe condition range, normal mode is restored.
Fail-safe mode Display (display of the fail-safe condition)
When HDD temperature is low HDD system is experienci
ng problems due to extreme low temperature.
Normal operation will resume when temperature rises.
When HDD temperature is high HDD system is experienci
ng problems due to extreme high temperature.
Normal operation will resume when temperature drops.
Function When Fail-safe Function is activated
Air conditioner Operation Only multifunction switch (preset switch) can be operated.
Display
LED of multifunction switch (preset switch) illuminates.
Aimed temperature, blow angle, and flow rate are displayed in simplified mode.
Audio Operation Only ON/OFF and volume control operations by multifunction switch (preset switch) are possible.
Display No display (“Fail-safe mode” is displayed)
Camera Operation Image tone cannot be controlled.
Display Cannot be superimposed. (warning display, tone control display)
Hands-free phone Operation Cannot be operated.
Navigation Operation Cannot be operated.
Self diagnosis The display in simplified mode of fail-safe condition
CONSULT-III diagnosis Cannot be operated.
Revision: 2010 May2011 QX56

Page 176 of 5598

INFINITI QX56 2011 Factory Service Manual
AV-28
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DescriptionINFOID:0000000006216218
The AV control unit diagnosis function starts up with multifun

AV-28
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DescriptionINFOID:0000000006216218
The AV control unit diagnosis function starts up with multifunction switch operation and the AV control unit
performs a diagnosis for each unit in the system during the on board diagnosis.
Perform a CONSULT-III diagnosis if the on board diagnosis does not start, e.g., the screen does not display
anything, the multifunction switch does not function, etc.
On Board Diagn osis FunctionINFOID:0000000006216219
MULTIFUNCTION SWITCH AND PRESET SWITCH SELF-DIAGNOSIS FUNCTION
The ON/OFF operation (continuity) of each switch in the multifunction switch and preset switch can be
checked.
Self-diagnosis Mode
Press the “BACK” switch and the “UP” switch of the 8-direction switches within 10 seconds after turning the ignition switch from
OFF to ACC and hold them for 3 seconds or more. Then the
buzzer sounds, all indicators of the preset switch illuminate, and
the self-diagnosis mode starts.
The continuity of each switch at the ON position can be checked
by pressing the switch. The buzzer sounds if the switch is normal.
NOTE:
The hazard switch and disk eject switch cannot be checked.
Finishing Self-diagnosis Mode
Self-diagnosis mode is canceled when turning the ignition switch OFF.
ON BOARD DIAGNOSIS
Description
The trouble diagnosis function has a self-diagnosis mode for conducting trouble diagnosis automatically and
a confirmation/adjustment mode for operating manually.
The self-diagnosis mode performs diagnoses on the AV control unit, connections between system compo-
nents as well as connections between AV contro l unit and GPS antenna. Then it displays the diagnosis
results on the display.
The confirmation/adjustment mode allows the technician to check, modify or adjust the vehicle signals and
set values, as well as to monitor the system erro r records and system communication status. The checking,
modifying or adjusting generally require human inte rvention and judgment (the system cannot make judg-
ment automatically).
On Board Diagnosis Item
JSNIA2987ZZ
Mode Description
Self Diagnosis AV control unit diagnosis.
Diagnoses the connections across system components, between AV
control unit and GPS antenna.
Revision: 2010 May2011 QX56
