EC-74
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
INT/V SOL (B2) Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle 0 - 2%
2,000 rpm Approx. 0 - 50%
AIR COND RLY Engine: After warming up, idle
the engine A/C switch: OFF OFF
A/C switch: ON
(Compressor operates)
ON
VENT CONT/V Ignition switch: ON OFF
THRTL RELAY Ignition switch: ON ON
A/F S1 HTR (B1) Engine: After warming up, idle the engine
(More than 140 seconds after starting engine) 4 - 100%
A/F S1 HTR (B2) Engine: After warming up, idle the engine
(More than 140 seconds after starting engine) 4 - 100%
HO2S2 HTR (B1) Engine speed: Below 3,600 rpm after the following conditions are met.
- Engine: After warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load ON
Engine speed: Above 3,600 rpm OFF
HO2S2 HTR (B2) Engine speed: Below 3,600 rpm after the following conditions are met.
- Engine: After warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load ON
Engine speed: Above 3,600 rpm OFF
ALT DUTY SIG Power generation voltage variable control: Operating ON
Power generation voltage variable control: Not operating OFF
I/P PULLY SPD Vehicle speed: More than 20 km/h (12 MPH) Almost the same speed as
the tachometer indication
VEHICLE SPEED Turn drive wheels and compare CONSULT-III value with the speedometer in-
dication. Almost the same speed as
the speedometer indication
IDL A/V LEARN Engine: Running Idle air volume learning has not been per-
formed yet.
YET
Idle air volume learning has already been
performed successfully. CMPLT
TRVL AFTER MIL Ignition switch: ON Vehicle has traveled after MIL has illumi-
nated.0 - 65,535 km
(0 - 40,7
23 miles)
SNOW MODE SW Ignition switch: ON Snow mode switch: ON ON
Snow mode switch: OFF OFF
ENG OIL TEMP Engine: After warming up More than 70 °C (158 °F)
MAIN SW Ignition switch: ON MAIN switch: Pressed ON
MAIN switch: Released OFF
CANCEL SW Ignition switch: ON CANCEL switch: Pressed ON
CANCEL switch: Released OFF
RESUME/ACC SW Ignition switch: ON RESUME/ACCELERATE switch:
Pressed
ON
RESUME/ACCELERATE switch: Re-
leased OFF
SET SW Ignition switch: ON SET/COAST switch: Pressed ON
SET/COAST switch: Released OFF
BRAKE SW1
(ASCD/ICC brake
switch) Ignition switch: ON
Brake pedal: Fully released ON
Brake pedal: Slightly depressed OFF
Monitor Item Condition Values/Status
Revision: 2010 May2011 QX56
Page 2099 of 5598
![INFINITI QX56 2011 Factory Service Manual
ECM
EC-75
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
BRAKE SW2
(Stop lamp switch)
Ignition switch: ON Brake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
INFINITI QX56 2011 Factory Service Manual
ECM
EC-75
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
BRAKE SW2
(Stop lamp switch)
Ignition switch: ON Brake pedal: Fully released OFF
Brake pedal: Slightly depressed ON](/manual-img/42/57033/w960_57033-2098.png)
ECM
EC-75
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
BRAKE SW2
(Stop lamp switch)
Ignition switch: ON Brake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
DIST SW Ignition switch: ON DISTANCE switch: Pressed ON
DISTANCE switch: Released OFF
CRUISE LAMP Ignition switch: ON MAIN switch: Pressed at the 1st time
→
at the 2nd time ON
→ OFF
AC EVA TEMP Engine: Running Indicates A/C evaporator
temperature sent from“uni-
fied meter and A/C amp.”.
AC EVA TARGET Engine: Running Indicates target A/C evapo-
rator temperature sentfrom
“unified meter and A/C
amp.”.
FAN DUTY Engine: Running 0 - 100%
ALT DUTY Engine: Idle 0 - 80%
BAT CUR SEN Engine speed: Idle
Battery: Fully charged*
2
Selector lever: P or N position
A/C switch: OFF
No load Approx. 2,600 - 3,500 mV
A/F ADJ-B1 Engine: Running −0.330 - 0.330
A/F ADJ-B2 Engine: Running −0.330 - 0.330
P/N POSI SW Ignition switch: ON Selector lever: P or N ON
Selector lever: Except above position OFF
INT/A TEMP SE Ignition switch: ON Indicates intake air temper-
ature
AC PRESS SEN Engine: Idle
Both A/C switch and blower fan switch: ON (Compressor operates) 1.0 - 4.0 V
FUEL PRES SEN Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 2.74 Mpa
2,000 rpm Approx. 3.0 Mpa
FUEL INJ B1 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 1.4 msec
2,000 rpm Approx. 1.0 msec
FUEL INJ B2 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 1.4 msec
2,000 rpm Approx. 1.0 msec
INT/V TIM (B1) Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle
−5 - 5 °CA
2,000 rpm Approx. 0 - 30 °CA
INT/V TIM (B2) Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle
−5 - 5 °CA
2,000 rpm Approx. 0 - 30 °CA
MAP SENSOR Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 1.0 V
2,000 rpm Approx. 1.35 V
EVAP LEAK DIAG Ignition switch: ON Indicates the condition of
EVAP leak diagnosis.
Monitor Item Condition Values/Status
Revision: 2010 May2011 QX56
Page 2100 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-76
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
EVAP DIAG READY Ignition switch: ON Indicates the ready condi-
tion of EVAP leak diagnosis.
VVEL LEARN Ignition switch: OFF
→ ON
(After warming INFINITI QX56 2011 Factory Service Manual
EC-76
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
EVAP DIAG READY Ignition switch: ON Indicates the ready condi-
tion of EVAP leak diagnosis.
VVEL LEARN Ignition switch: OFF
→ ON
(After warming](/manual-img/42/57033/w960_57033-2099.png)
EC-76
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
EVAP DIAG READY Ignition switch: ON Indicates the ready condi-
tion of EVAP leak diagnosis.
VVEL LEARN Ignition switch: OFF
→ ON
(After warming up) VVEL learning has no
t been performed
yet. YET
VVEL learning has already been per-
formed successfully. DONE
VVEL SEN LEARN-B1 VVEL learning has already been performed successfully Approx. 0.30 - 0.80 V
VVEL SEN LEARN-B2 VVEL learning has already been performed successfully Approx. 0.30 - 0.80 V
VVEL POSITION SEN-
B1 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 0.25 - 1.50 V
When revving engine up to 2,000 rpm
quickly
Approx. 0.25 - 4.75 V
VVEL POSITION SEN-
B2 Engine: After warming up
Selector lever: P or N position
Air conditioner switch: OFF
No load Idle Approx. 0.25 - 1.50 V
When revving engine up to 2,000 rpm
quickly
Approx. 0.25 - 4.75 V
VVEL TIM-B1 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 0 - 23 deg
When revving engine up to 2,000 rpm
quickly
Approx. 0 - 90 deg
VVEL TIM-B2 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 0 - 23 deg
When revving engine up to 2,000 rpm
quickly
Approx. 0 - 90 deg
FPCM Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Engine: Cranking HI
Revving engine from idle to 4,000 rpm
quickly MID
Engine: Idle
Engine coolant temperature: More than 10 °C (50 °F) LOW
BAT TEMP SEN Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle
Indicates the temperature
around the battery.
COOLING FAN SPD Engine speed: Idle
Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Water temp: Less than 98
°C Approx. 100 – 200 rpm
Water temp: More than 98 °C Approx. 600 – 700 rpm
THRTL STK CNT B1 NOTE:
The item is indicated, but not used. —
HO2 S2 DIAG2(B1) NOTE:
The item is indicated, but not used.
—
HO2 S2 DIAG2(B2) NOTE:
The item is indicated, but not used. —
FUEL INJ TIMG Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 16 deg
2,000 rpm Approx.
−170 deg
H/P FUEL PUMP DEG Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 211.0 deg
2,000 rpm Approx. 206.0 deg
Monitor Item Condition Values/Status
Revision: 2010 May2011 QX56
Page 2101 of 5598
![INFINITI QX56 2011 Factory Service Manual
ECM
EC-77
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. INFINITI QX56 2011 Factory Service Manual
ECM
EC-77
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally.](/manual-img/42/57033/w960_57033-2100.png)
ECM
EC-77
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. Thus, the
y differ
from ECM terminals voltage signal.
*2: Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to PG-159, "
How to Handle Battery".
TERMINAL LAYOUT
PHYSICAL VALUES
NOTE:
Specification data are reference values and are measured between each terminals.
Pulse signal is measured by CONSULT-III.
FUEL PRES SEN V Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 1150 mV
2,000 rpm Approx. 1200 mV
L/FUEL PRES SEN Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 0.45 MPa
2,000 rpm Approx. 0.45 MPa
L/FUEL PRES SEN V Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle Approx. 3250 mV
3,000 rpm Approx. 3100 mV
ECM TEMP 1 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle
Indicates the temperature of
ECM internal circuit 1.
ECM TEMP 2 Engine: After warming up
Selector lever: P or N position
A/C switch: OFF
No load Idle
Indicates the temperature of
ECM internal circuit 2.
FUEL PUMP DUTY Engine: After warming up
Shift lever: P or N
Air conditioner switch: OFF
No load Engine speed: Idle 30 - 40%
Monitor Item Condition Values/Status
JPBIA3371ZZ
Revision: 2010 May2011 QX56
Page 2102 of 5598
EC-78
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
1
(R)
2
(R) 175
(B) Fuel injector No. 8 (HI)
Fuel injector No. 5 (HI)
Output[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
3
(G)
4
(G) 175
(B) Fuel injector No. 3 (LO)
Fuel injector No. 2 (LO)
Input[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
5
(B/R) — ECM ground — — —
JPBIA3345ZZ
JPBIA3347ZZ
JPBIA3355ZZ
JPBIA3356ZZ
Revision: 2010 May2011 QX56
Page 2103 of 5598
![INFINITI QX56 2011 Factory Service Manual
ECM
EC-79
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
6
(R) 7
(R) 175
(B) Fuel injector No. 3 (HI)
Fuel injector No. 2 (HI)
Output[Engine is running]
Warm-up condition
INFINITI QX56 2011 Factory Service Manual
ECM
EC-79
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
6
(R) 7
(R) 175
(B) Fuel injector No. 3 (HI)
Fuel injector No. 2 (HI)
Output[Engine is running]
Warm-up condition
](/manual-img/42/57033/w960_57033-2102.png)
ECM
EC-79
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
6
(R) 7
(R) 175
(B) Fuel injector No. 3 (HI)
Fuel injector No. 2 (HI)
Output[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
8
(G) 9
(G) 175
(B) Fuel injector No. 8 (LO)
Fuel injector No. 5 (LO)
Input[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
10
(B) — ECM ground — — —
11
(BR) 175
(B) PNP switch Input [Ignition switch: ON]
Selector lever: P or N position
BATTERY VOLTAGE
(11 - 14 V)
[Ignition switch: ON]
Selector lever: Except above posi- tion 0 V
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
OutputJPBIA3345ZZ
JPBIA3347ZZ
JPBIA3355ZZ
JPBIA3356ZZ
Revision: 2010 May2011 QX56
Page 2104 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-80
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
12
(Y)
13
(L/B) 14
(BR/ Y)
15
(LG/ R) 175
(B) Ignition signal No. 1
Ignition signal No. 2
Ignition signal No. 3
Ignition signal No. 4
Input[Engine is r INFINITI QX56 2011 Factory Service Manual
EC-80
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
12
(Y)
13
(L/B) 14
(BR/ Y)
15
(LG/ R) 175
(B) Ignition signal No. 1
Ignition signal No. 2
Ignition signal No. 3
Ignition signal No. 4
Input[Engine is r](/manual-img/42/57033/w960_57033-2103.png)
EC-80
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
12
(Y)
13
(L/B) 14
(BR/ Y)
15
(LG/ R) 175
(B) Ignition signal No. 1
Ignition signal No. 2
Ignition signal No. 3
Ignition signal No. 4
Input[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle 0 - 0.2 V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm 0.1 - 0.4 V
17
(P/L) 18
(Y/R) 19
(G/Y)
20
(O) 175
(B) Ignition signal No. 5
Ignition signal No. 6
Ignition signal No. 7
Ignition signal No. 8
Input[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle 0 - 0.2 V
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm 0.1 - 0.4 V
21
(G/O) 25
(LG) Intake air temperature sensor Input [Engine is running] 0 - 4.8 V
Output voltage varies with intake
air temperature.
22
(BR/ W) 25
(LG) Mass air flow sensor Input [Engine is running]
Warm-up condition
Idle speed
0.9 - 1.1 V
[Engine is running]
Warm-up condition
Engine speed: 2,500 rpm 1.4 - 1.9 V
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
JPBIA3355ZZ
JPBIA3356ZZ
JPBIA3355ZZ
JPBIA3356ZZ
Revision: 2010 May2011 QX56
