BACK DOOR TRIMINT-41
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
K L
M A
B
INT
N
O P
2. Remove back door finisher inner lower.
6. Disengage back door finisher side (1) fixing metal clips using a remover tool (A), and then remove back door finisher side.
7. Disengage back door finisher upper (1) fixing metal clips using a remover tool (A), and then remove back door finisher upper.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
Visually check the clips, pawls and metal clips for deformation and damage during installation.
Replace with new ones if necessary.
When installing back door trims, check that clips, pawls, and metal clips are securely fitted in body
panel holes, and press them in.
: Metal clip
JMJIA4052ZZ
: Metal clip
JMJIA4051ZZ
Revision: 2010 May2011 QX56
GLASS LIDRF-33
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
RF
N
O P
Removal and InstallationINFOID:0000000006141246
CAUTION:
Always work with a helper.
Fully close the glass lid, before removal, th en never operate sunroof motor after removal.
REMOVAL
1. Remove the side trims (LH, RH).
2. Remove the TORX bolts (A) and remove glass lid.
INSTALLATION
CAUTION:
After installing the glass lid, perform the leak test and check the there is no malfunction.
NOTE:
After installation carry out fitting adjustment. Refer to RF-33, "
Adjustment".
Install in the reverse order of removal.
AdjustmentINFOID:0000000006141247
Glass lid Adjustment and Surface Mismatch Adjustment
1. Remove side trims.
2. After loosening glass lid from TORX bolts (left and right).
3. Adjust glass lid from outside of vehicle so it resembles “A – A”,“B – B”“C – C”.
JMKIA0029ZZ
JMKIA5137ZZ
1. Roof panel 2. Glass lid
Portion a (Clearance) b (S urface height difference)
A – A 0.6 – 2.2 mm (0.024 – 0.087 in) −
1.5) – (+1.5) mm
[( −0.059) – (+0.059) in]
