Page 1953 of 5598

INFINITI QX56 2011 Factory Service Manual PREPARATIONDLN-151 < PREPARATION > [FRONT FINAL DRIVE: R180A] C EF G H I J K L M A B DLN N O P Commercial Service ToolINFOID:0000000006222375 ST30901000 (J-26010-01) Drift a: 79 mm (3.11 in) dia. b:

Page 1954 of 5598

INFINITI QX56 2011 Factory Service Manual DLN-152 < PREPARATION >[FRONT FINAL DRIVE: R180A] PREPARATION Puller Removing companion flange Drift a: 63 mm (2.48 in) dia. or less b: 49 mm (1.93 in) dia. or more Removing and Installing bushing Sl

Page 1955 of 5598

INFINITI QX56 2011 Factory Service Manual STRUCTURE AND OPERATIONDLN-153 < SYSTEM DESCRIPTION > [FRONT FINAL DRIVE: R180A] C EF G H I J K L M A B DLN N O P SYSTEM DESCRIPTION STRUCTURE AND OPERATION Sectional ViewINFOID:0000000006222376 1. S

Page 1956 of 5598

INFINITI QX56 2011 Factory Service Manual DLN-154 < SYMPTOM DIAGNOSIS >[FRONT FINAL DRIVE: R180A] NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING SYMPTOM DIAGNOSIS NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING NVH Troubleshootin

Page 1957 of 5598

INFINITI QX56 2011 Factory Service Manual FRONT DIFFERENTIAL GEAR OILDLN-155 < PERIODIC MAINTENANCE > [FRONT FINAL DRIVE: R180A] C EF G H I J K L M A B DLN N O P PERIODIC MAINTENANCE FRONT DIFFERENTIAL GEAR OIL InspectionINFOID:0000000006222

Page 1958 of 5598

INFINITI QX56 2011 Factory Service Manual DLN-156 < REMOVAL AND INSTALLATION >[FRONT FINAL DRIVE: R180A] FRONT OIL SEAL REMOVAL AND INSTALLATION FRONT OIL SEAL Exploded ViewINFOID:0000000006222381 Removal and InstallationINFOID:0000000006222

Page 1959 of 5598

INFINITI QX56 2011 Factory Service Manual FRONT OIL SEALDLN-157 < REMOVAL AND INSTALLATION > [FRONT FINAL DRIVE: R180A] C EF G H I J K L M A B DLN N O P CAUTION: Make a stamping after replacing front oil seal.  After replacing front oil sea

Page 1960 of 5598

INFINITI QX56 2011 Factory Service Manual DLN-158 < REMOVAL AND INSTALLATION >[FRONT FINAL DRIVE: R180A] FRONT OIL SEAL 8. Remove the companion flange using puller (commercial service tool). 9. Remove front oil seal using the puller [SST: KV
