ECM
EC-89
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
106
(R)
107 (R) 175
(B) Fuel injector No. 7 (HI)
Fuel injector No. 4 (HI)
Output[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
108 (G)
109 (G) 175
(B) Fuel injector No. 1 (LO)
Fuel injector No. 6 (LO)
Output[Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
11 0
(L/B) 175
(B) High pressure fuel pump (LO) Input [Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
OutputJPBIA3345ZZ
JPBIA3347ZZ
JPBIA3355ZZ
JPBIA3356ZZ
JPBIA3342ZZ
JPBIA3343ZZ
Revision: 2010 May2011 QX56
