Page 4409 of 5598
DESCRIPTIONSCS-49
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
SYSTEM DESCRIPTION
DESCRIPTION
DescriptionINFOID:0000000006256039
Corrects sinkage of vehicle rear that occurs in laden or towing conditions.
Maintains vehicle height at a constant level and improv es riding comfort by charging or discharging air in air
chamber of rear shock absorber, according to signal from vehicle height sensor installed to rear suspension.
Revision: 2010 May2011 QX56
Page 4410 of 5598
SCS-50
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
COMPONENT PARTS
COMPONENT PARTS
Component Parts LocationINFOID:0000000006256040
Component DescriptionINFOID:0000000006256041
1. Combination meter
Refer to MWI-6, "
METER SYSTEM
: Component Parts Location".2. CK SUSP indicator lamp 3. Air levelizer control module
4. Air compressor relay 5. Air chamber 6. Air compressor
7. Vehicle height sensor
A. Inside of luggage side finisher low- er (LH) B. Engine room (RH) C. Rear shock absorber
D. Vehicle rear (LH)
JSEIA0223GB
Component parts Reference
Air levelizer control module SCS-51, "
Air Levelizer Control Module"
Vehicle height sensorSCS-51, "Vehicle Height Sensor"
Air compressor
SCS-51, "Air Compressor"Exhaust solenoid
Revision: 2010 May2011 QX56
Page 4411 of 5598
![INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSSCS-51
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Air Levelizer Control ModuleINFOID:0000000006256042
Operates ON/OFF of air compressor ( INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSSCS-51
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Air Levelizer Control ModuleINFOID:0000000006256042
Operates ON/OFF of air compressor (](/manual-img/42/57033/w960_57033-4410.png)
COMPONENT PARTSSCS-51
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Air Levelizer Control ModuleINFOID:0000000006256042
Operates ON/OFF of air compressor (exhaust solenoid) , according to signal from vehicle height sensor.
Transmits CK SUSP indicator lamp signal to the combination meter via CAN communication, when setting of standard vehicle height is incomplete.
If malfunction is detected, the syste m enters fail-safe mode. Refer to SCS-59, "
Fail-safe".
Vehicle Height SensorINFOID:0000000006256043
Measures vehicle height of vehicle rear and transmits th is information to air levelizer control module according
to electric signal.
Air CompressorINFOID:0000000006256044
Operates according to signal from air levelizer control module via air compressor relay, and charges air in air
chamber of rear shock absorber.
EXHAUST SOLENOID
Operates according to signal from air levelizer control module, and discharges air in air chamber of rear shock
absorber.
Air Compressor RelayINFOID:0000000006256045
Turns ON according to signal from air levelizer control module, and operates air compressor.
CK SUSP Indicator LampINFOID:0000000006256046
Turns ON for 2 seconds when ignition switch is turned ON, for the purpose of bulb check.
Turns ON when setting of standard vehicle height is incomplete.
NOTE:
Does not turn ON when the system is malfunctioning.
Air compressor relay SCS-51, "Air Compressor Relay"
CK SUSP indicator lampSCS-51, "CK SUSP Indicator Lamp"
Component parts Reference
Revision: 2010 May2011 QX56
Page 4412 of 5598
![INFINITI QX56 2011 Factory Service Manual
SCS-52
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
STRUCTURE AND OPERATION
STRUCTURE AND OPERATION
Rear Shock AbsorberINFOID:0000000006256047
Discharges air in air chamber (2) from air val INFINITI QX56 2011 Factory Service Manual
SCS-52
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
STRUCTURE AND OPERATION
STRUCTURE AND OPERATION
Rear Shock AbsorberINFOID:0000000006256047
Discharges air in air chamber (2) from air val](/manual-img/42/57033/w960_57033-4411.png)
SCS-52
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
STRUCTURE AND OPERATION
STRUCTURE AND OPERATION
Rear Shock AbsorberINFOID:0000000006256047
Discharges air in air chamber (2) from air valve (1)
when vehicle height of vehicle rear is higher than stan-
dard vehicle height, has shock absorber stroke in compressed direction, lowers vehicle height, and returns it
to standard vehicle height.
Also charges air in air chamber from air valve when height of vehicle rear is lower than standard vehicle
height, has shock absorber stroke in extending directi on, raises vehicle height, and returns it to standard
vehicle height.
Charged air, because of rubber (3) that is hard and loca ted on side surface, does not expand in lateral direc-
tion, but expands in vertical direction, and enables shock absorber to extend or retract.
Without Hydraulic Body-Motion Control System
With Hydraulic Body-M otion Control System
JSEIA0217ZZ
1. Air valve 2. Air chamber 3. Rubber
A. Stroke
: Vehicle upper
JSEIA0218ZZ
1. Air valve 2. Air chamber 3. Rubber
A. Stroke
: Vehicle upper
Revision: 2010 May2011 QX56
Page 4413 of 5598
STRUCTURE AND OPERATIONSCS-53
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Vehicle Height SensorINFOID:0000000006256048
Vehicle height sensor is installed between rear suspension member
(1) and rear lower link (2).
Since arm (A) portion and rod (B) portion are ball joint type, distance
between rear suspension member and rear lower link shortens when
vehicle height of vehicle rear lowers because of laden or towing con-
ditions, and arm portion changes to the status that is higher in its left
side as shown in the figure.
This angle change in arm portion is transmitted to the air levelizer
control module according to electric signal.
JSEIA0219ZZ
Revision: 2010 May2011 QX56
Page 4414 of 5598
![INFINITI QX56 2011 Factory Service Manual
SCS-54
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
SYSTEM
SYSTEM
System DiagramINFOID:0000000006256049
System DescriptionINFOID:0000000006256050
Based on the signal from the vehicle height INFINITI QX56 2011 Factory Service Manual
SCS-54
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
SYSTEM
SYSTEM
System DiagramINFOID:0000000006256049
System DescriptionINFOID:0000000006256050
Based on the signal from the vehicle height](/manual-img/42/57033/w960_57033-4413.png)
SCS-54
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
SYSTEM
SYSTEM
System DiagramINFOID:0000000006256049
System DescriptionINFOID:0000000006256050
Based on the signal from the vehicle height sensor, t
he air levelizer control module operates the air com-
pressor (exhaust solenoid) and controls vehicle height so that it remains at a constant height. This operation
occurs if vehicle height of vehicle rear is judged to be 15 mm (0.59 in) or more or 15 mm (0.59 in) or less
than standard vehicle height, continuously for 30 seconds, when engine is started.
If malfunction is detected, the system enters fail-safe mode. Refer to SCS-59, "
Fail-safe".
INPUT/OUTPUT SIGNAL
Air levelizer control module transmits and receives following signals between each control unit via CAN com-
munication line.
OPERATING PRINCIPLE
System Time Table
JSEIA0220GB
Component parts Control signal
ECM Transmits the following signal via CAN communication line to air levelizer control module.
Engine speed signal
Combination meter Receives the following signal via CAN communication line from air levelizer control module.
CK SUSP indicato
r lamp signal
ABS actuator and elec tric unit (con-
trol unit) Transmits the following signal via CAN communication line to air levelizer control module.
Vehicle speed signal
Revision: 2010 May2011 QX56
Page 4415 of 5598
![INFINITI QX56 2011 Factory Service Manual
SYSTEMSCS-55
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Vehicle height raises [When starting engi
ne, if vehicle height of vehicle rear continues for 30 s INFINITI QX56 2011 Factory Service Manual
SYSTEMSCS-55
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Vehicle height raises [When starting engi
ne, if vehicle height of vehicle rear continues for 30 s](/manual-img/42/57033/w960_57033-4414.png)
SYSTEMSCS-55
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Vehicle height raises [When starting engi
ne, if vehicle height of vehicle rear continues for 30 seconds or more in a
status that is 15 mm (0.59 in) or less than standard vehicle height]
1. Vehicle height sensor detects vehicle height status, and transmits this information to air levelizer control
module.
2. Air levelizer control module turns air compressor relay ON and operates air compressor.
3. Air compressor charges air in air chamber of shock absorber.
4. Vehicle height raises, and control is complete when status is −1 mm ( −0.04 in) of standard vehicle height
value.
Vehicle height lowers [When starting engine, if vehicle height of vehicle rear continues for 30 seconds or more in a
status that is 15 mm (0.59 in) or more of standard vehicle height]
1. Vehicle height sensor detects vehicle height status, and transmits this information to air levelizer control
module.
2. Air levelizer control module turns exhaust solenoid of air compressor ON.
3. Air compressor discharges air from air chamber of shock absorber.
4. Vehicle height lowers, and control is complete when st atus is +1 mm (+0.04 in) of standard vehicle height.
Fail-safeINFOID:0000000006256051
If malfunction is detected, control stops.
The system may enter fail-safe mode under certain conditions (for example, over-laden conditions) when elec-
tronic circuit is normal.
In this case, always check that the system re turns to normal by starting engine after unloading load.
JSEIA0221GB
Revision: 2010 May2011 QX56
Page 4416 of 5598
![INFINITI QX56 2011 Factory Service Manual
SCS-56
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
DIAGNOSIS SYSTEM (AIR
LEVELIZER CONTROL MODULE)
DIAGNOSIS SYSTEM (AIR LE VELIZER CONTROL MODULE)
CONSULT-III FunctionINFOID:00000000062560 INFINITI QX56 2011 Factory Service Manual
SCS-56
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
DIAGNOSIS SYSTEM (AIR
LEVELIZER CONTROL MODULE)
DIAGNOSIS SYSTEM (AIR LE VELIZER CONTROL MODULE)
CONSULT-III FunctionINFOID:00000000062560](/manual-img/42/57033/w960_57033-4415.png)
SCS-56
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
DIAGNOSIS SYSTEM (AIR
LEVELIZER CONTROL MODULE)
DIAGNOSIS SYSTEM (AIR LE VELIZER CONTROL MODULE)
CONSULT-III FunctionINFOID:0000000006256052
CONSULT-III APPLICATION ITEMS
WORK SUPPORT
CAUTION:
Perform the procedure when the vehicle is stopped.
SELF DIAGNOSTIC RESULTS
Refer to SCS-59, "DTC Index".
When “CRNT” is displayed on self-diagnosis result,
The system is presently malfunctioning.
When “PAST” is displayed on self-diagnosis result, System malfunction in the past is detect ed, but the system is presently normal.
Freeze frame data (FFD)
DATA MONITOR
Diagnostic test mode Function
Work Support This mode enables a technician to adjust some devices faster and more accurately.
Self Diagnostic Results Retrieve DTC from ECU and display diagnostic items.
Data Monitor Monitor the input/output signal of the control unit in real time.
CAN Diagnosis This mode displays a network diagnosis result about CAN by a diagram.
CAN Diagnostic Support
Monitor It monitors the status of CAN communication.
ECU Identification Display the ECU identification number (part number etc.) of the selected system.
Active Test Send the drive signal from CONSULT-III to the actuator. The operation check can be performed.
Item name Description
STANDARD HEIGHT LEVEL Forcibly sets vehicle height to the set standard vehicle height.
ADJUST HEIGHT INI Sets standard vehicle height.
CLEAR HEIGHT INI Erases standard vehicle height.
Item name Description
IGN COUNTER The number of times that ignition switch is turned ON after the DTC is detected is displayed.
When “0” is displayed: It indicates that the system is presently malfunctioning.
When except “0” is displayed: It indicates that system malfunction in the past is detected, but the system
is presently normal.
NOTE:
Each time when ignition switch is turned OFF to ON, numerical number increases in 1 → 2 → 3...38 → 39.
When the operation number of times exceeds 39, the number do not increase and “39” is displayed until
self-diagnosis is erased.
Monitored item (Unit) Remarks
IGN VOLT (V) Displays the power supply voltage of air levelizer control module.
VHCL HT INTLZ STA Displays setting status of standard vehicle height.
VHCL HT INIT SLCT Displays setting status of standard vehicle height.
VHCL HEIGHT SEN (V) Displays the signal voltage of vehicle height sensor.
VHCL HT CNVSN VL (mm) Displays the vehicle height recognized by air levelizer control module.
VHCL HGT FIX TIME (hour) Displays period of time that signal from vehicle height sensor does not change.
Revision: 2010 May2011 QX56
