INFINITI QX56 2011 Factory Service Manual
PRECAUTIONSEC-9
< PRECAUTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000

PRECAUTIONSEC-9
< PRECAUTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000006219727
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision that would result in air ba g inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIR BAG”.
Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the
ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s)
with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly
causing serious injury.
When using air or electric power tools or hammers , always switch the ignition OFF, disconnect the
battery, and wait at least 3 minutes before performing any service.
Precaution for Procedur e without Cowl Top CoverINFOID:0000000006217650
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Precautions For Xenon Headlamp ServiceINFOID:0000000006217651
WARNING:
Comply with the follow ing warnings to prevent any serious accident.
Disconnect the battery cable (neg ative terminal) or the power supply fuse before installing, remov-
ing, or touching the xenon headlamp (bulb included). The xenon headlamp contains high-voltage
generated parts.
Never work with wet hands.
Check the xenon headlamp ON-OFF status after assem bling it to the vehicle. Never turn the xenon
headlamp ON in other conditions. Connect th e power supply to the vehicle-side connector.
(Turning it ON outside the lamp case m ay cause fire or visual impairments.)
Never touch the bulb glass immediately afte r turning it OFF. It is extremely hot.
PIIB3706J
Revision: 2010 May2011 QX56

Page 2034 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-10
< PRECAUTION >[VK56VD]
PRECAUTIONS
CAUTION:
Comply with the following cautions to
prevent any error and malfunction.
Install the xenon bulb securely. (Ins ufficient bulb socket installation

EC-10
< PRECAUTION >[VK56VD]
PRECAUTIONS
CAUTION:
Comply with the following cautions to
prevent any error and malfunction.
Install the xenon bulb securely. (Ins ufficient bulb socket installation may melt the bulb, the connec-
tor, the housing, etc. by high-v oltage leakage or corona discharge.)
Never perform HID circuit in spection with a tester.
Never touch the xenon bulb glass with ha nds. Never put oil and grease on it.
Dispose of the used xenon bulb after packing it in thick vinyl without breaking it.
Never wipe out dirt and cont amination with organic solven t (thinner, gasoline, etc.).
On Board Diagnostic (OBD) System of Engine and A/TINFOID:0000000006217652
The ECM has an on board diagnostic system. It will illuminate the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:
Always turn the ignition switch OFF and disconnect the negative battery cable before any repair or
inspection work. The open/short circuit of related sw itches, sensors, solenoid valves, etc. will cause
the MIL to illuminate.
Always connect and lock the conn ectors securely after work. A loose (unlocked) connector will
cause the MIL to illuminate due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
Certain systems and components, especially those related to OBD, may use a new style slide-lock-
ing type harness connector. For descripti on and how to disconnect, refer to EC-51, "
Diagnosis
Description".
Always route and secure the harnesses properly afte r work. The interference of the harness with a
bracket, etc. may cause the MIL to illu minate due to the short circuit.
Always connect rubber tubes properly after work. A misconnected or disconnected rubber tube may
cause the MIL to illuminate due to the malfunction of the EVAP system or fuel injection system, etc.
Always erase the unnecessary malfunction information (repairs completed) from the ECM and TCM
(Transmission control module) before re turning the vehicle to the customer.
General PrecautionsINFOID:0000000006217653
Always use a 12 volt battery as power source.
Never attempt to disconnect battery cables while engine is
running.
Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect negative bat-
tery cable. Failure to do so may damage the ECM because
battery voltage is applied to ECM even if ignition switch is
turned OFF.
Before removing parts, turn ig nition switch OFF and then dis-
connect battery ground cable.
Never disassemble ECM.
If a battery cable is disconnected, the memory will return to
the ECM value.
The ECM will now start to self-control at its initial value. Thus,
engine operation can vary slight ly in this case. However, this
is not an indication of a ma lfunction. Never replace parts
because of a slight variation.
If the battery is disconnected, the following emission-related
diagnostic information will be lost within 24 hours.
- Diagnostic trouble codes
- 1st trip diagnostic trouble codes
- Freeze frame data
- 1st trip freeze frame data
- System readiness test (SRT) codes
- Test values
SEF289H
JMBIA0057ZZ
Revision: 2010 May2011 QX56

Page 2035 of 5598

INFINITI QX56 2011 Factory Service Manual
PRECAUTIONSEC-11
< PRECAUTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O

When connecting ECM harness connector (A), fasten (B) it
securely with a lever as far as it will go as shown in the figure.

Page 2036 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-12
< PRECAUTION >[VK56VD]
PRECAUTIONS

When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes will cause a short circuit an

Page 2037 of 5598

INFINITI QX56 2011 Factory Service Manual
PRECAUTIONSEC-13
< PRECAUTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O

When installing C.B. ham radio or a mobile phone, be sure to
observe the following as it may adversely affect electronic
con

Page 2038 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-14
< PREPARATION >[VK56VD]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000006217654
Commercial Service ToolsINFOID:0000000006217655
Tool number
(Kent-Moore No.)
Tool nameDe

Page 2039 of 5598

INFINITI QX56 2011 Factory Service Manual
PREPARATIONEC-15
< PREPARATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12)
Reconditions the exhaust system threads before
installing a ne

Page 2040 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-16
< SYSTEM DESCRIPTION >[VK56VD]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006217656
ENGINE ROOM COMPARTMENT
ENGINE COMPARTMENT
1. IPDM E/R 2. ECM 3
