Page 1857 of 5598
![INFINITI QX56 2011 Factory Service Manual
P180C SENSOR POWER SUPPLY (5V)DLN-55
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4. Check the continuity between transfer lo ck position sensor harness connector and INFINITI QX56 2011 Factory Service Manual
P180C SENSOR POWER SUPPLY (5V)DLN-55
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4. Check the continuity between transfer lo ck position sensor harness connector and](/manual-img/42/57033/w960_57033-1856.png)
P180C SENSOR POWER SUPPLY (5V)DLN-55
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4. Check the continuity between transfer lo ck position sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
3.CHECK TRANSFER LOCK POSITION SENSOR POWER SUPPLY (2)
1. Turn the ignition switch OFF.
2. Connect transfer lock position sensor harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer lock pos ition sensor harness connector terminals.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace transfer lock position sensor. Refer to DLN-119, "
Removal and Installation".
4.CHECK TRANSFER ROTARY POSITION SENSOR POWER SUPPLY (1)
1. Turn the ignition switch OFF.
2. Connect transfer control unit harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer rotary position sensor harness connector terminals.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK TRANSFER ROTARY POSITION SENSOR CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer rotary position sensor
harness connector.
Transfer control unit Transfer lock position sensor Continuity
Connector Terminal Connector Terminal
E59 17
F40 1
Existed
30 2
Transfer lock position sensor —Continuity
Connector Terminal
F40 1 Ground Not existed
+ −
Vo l ta g e
Transfer lock position sensor
Connector Terminal F40 1 2 Approx. 5 V
+ −
Vo l ta g e
Transfer rotary position sensor
Connector Terminal F41 1 2 Approx. 5 V
Revision: 2010 May2011 QX56
Page 1858 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-56
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180C SENSOR POWER SUPPLY (5V)
4. Check the continuity between transfer rotary position sensor harness connector and ground.
Is the inspection resul INFINITI QX56 2011 Factory Service Manual
DLN-56
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180C SENSOR POWER SUPPLY (5V)
4. Check the continuity between transfer rotary position sensor harness connector and ground.
Is the inspection resul](/manual-img/42/57033/w960_57033-1857.png)
DLN-56
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180C SENSOR POWER SUPPLY (5V)
4. Check the continuity between transfer rotary position sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace error-detected parts.
6.CHECK TRANSFER ROTARY POSITION SENSOR POWER SUPPLY (2)
1. Turn the ignition switch OFF.
2. Connect transfer lock position sensor harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer rotary position sensor harness connector terminals.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace transfer rotary position sensor. Refer to DLN-117, "
Removal and Installation".
7.CHECK TERMINALS AND HARNESS CONNECTORS
Check the pin terminals for damage or loose connection with each harness connector.
Is the inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Transfer control unit Transfer rotary position sensor Continuity
Connector Terminal Connector Terminal
E59 18
F41 1
Existed
16 2
Transfer rotary position sensor —Continuity
Connector Terminal
F41 1 Ground Not existed
+ −
Voltag e
Transfer rotary position sensor
Connector Terminal F41 1 2 Approx. 5 V
Revision: 2010 May2011 QX56
Page 1859 of 5598
![INFINITI QX56 2011 Factory Service Manual
P180D TRANSFER ROTARY POSITION SENSORDLN-57
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180D TRANSFER ROTARY POSITION SENSOR
DTC LogicINFOID:0000000006222253
DTC D INFINITI QX56 2011 Factory Service Manual
P180D TRANSFER ROTARY POSITION SENSORDLN-57
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180D TRANSFER ROTARY POSITION SENSOR
DTC LogicINFOID:0000000006222253
DTC D](/manual-img/42/57033/w960_57033-1858.png)
P180D TRANSFER ROTARY POSITION SENSORDLN-57
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180D TRANSFER ROTARY POSITION SENSOR
DTC LogicINFOID:0000000006222253
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Turn the 4WD shift switch AUTO ⇒4H ⇒4LO ⇒4H ⇒AUTO.
3. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P180D” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-57, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222254
1.CHECK TRANSFER ROTARY POSITION SENSOR SIGNAL
1. Turn the ignition switch ON.
2. Check the voltage between transfer control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK TRANSFER ROTARY POSI TION SENSOR POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect transfer rotary pos ition sensor harness connector.
3. Turn the ignition switch ON.
CAUTION:
Never start the engine.
4. Check the voltage between transfer rotary position sensor harness connector terminals.
DTC Display item Malfunction detected condition Possible cause
P180D ROTARY POSITION SEN Malfunction is detected in transfer rotary
position sensor.Transfer rotary position sensor
Transfer rotary po
sition sensor error
Transfer rotary posi tion sensor circuit
error
+
−Vol tag e
Transfer control unit
Connector Terminal
E59 15 Ground
JPDIE0268GB
+ −
Vo l ta g e
Transfer rotary position sensor
Connector Terminal F41 1 2 Approx. 5 V
Revision: 2010 May2011 QX56
Page 1860 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-58
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180D TRANSFER ROTARY POSITION SENSOR
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK TRANSFER ROTARY POSITION SENSOR CIRCUI INFINITI QX56 2011 Factory Service Manual
DLN-58
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180D TRANSFER ROTARY POSITION SENSOR
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK TRANSFER ROTARY POSITION SENSOR CIRCUI](/manual-img/42/57033/w960_57033-1859.png)
DLN-58
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180D TRANSFER ROTARY POSITION SENSOR
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK TRANSFER ROTARY POSITION SENSOR CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer rotary position sensor
harness connector.
4. Check the continuity between transfer rotary position sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
4.CHECK TRANSFER ROTARY POSITION SENSOR SIGNAL CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer rotary position sensor
harness connector.
4. Check the continuity between transfer rotary position sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.REPLACE TRANSFER ROTARY POSITION SENSOR
1. Replace transfer rotary position sensor. Refer to DLN-117, "
Removal and Installation".
2. Perform confirmation procedure again. Refer to DLN-57, "
DTC Logic".
Is DTC
“P180D” detected?
YES >> GO TO 6.
NO >> INSPECTION END
6.CHECK TERMINALS AND HARNESS CONNECTORS
Check the pin terminals for damage or loose connection with each harness connector.
Is the inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Transfer control unit Transfer rotary position sensor Continuity
Connector Terminal Connector Terminal
E59 18
F41 1
Existed
16 2
Transfer rotary position sensor — Continuity
Connector Terminal
F41 1 Ground Not existed
Transfer control unit Transfer rotary position sensor Continuity
Connector Terminal Connector Terminal
E59 15 F41 3 Existed
Transfer rotary position sensor —Continuity
Connector Terminal
F41 3 Ground Not existed
Revision: 2010 May2011 QX56
Page 1861 of 5598
![INFINITI QX56 2011 Factory Service Manual
P180E SENSOR POWER SUPPLY (8V)DLN-59
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180E SENSOR POWER SUPPLY (8V)
DescriptionINFOID:0000000006222255
Supplies power (8V INFINITI QX56 2011 Factory Service Manual
P180E SENSOR POWER SUPPLY (8V)DLN-59
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180E SENSOR POWER SUPPLY (8V)
DescriptionINFOID:0000000006222255
Supplies power (8V](/manual-img/42/57033/w960_57033-1860.png)
P180E SENSOR POWER SUPPLY (8V)DLN-59
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180E SENSOR POWER SUPPLY (8V)
DescriptionINFOID:0000000006222255
Supplies power (8V) to transfer internal speed sensor.
DTC LogicINFOID:0000000006222256
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch ON.
2. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P180E” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-59, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222257
1.CHECK TRANSFER INTERNAL SPEED SENSOR POWER SUPPLY (1)
1. Turn the ignition switch OFF.
2. Disconnect transfer control actuator harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer cont rol actuator harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK TRANSFER INTERNAL SPEED SENSOR CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer control actuator har-
ness connector.
4. Check the continuity between transfer control actuator harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
P180E SEN POWER SUPPLY (8V) When the sensor power supply (8V) volt-
age is lower or higher than normal.Malfunction of transfer internal speed
sensor power supply circuit (open or
short)
+
−
Vo l ta g e
Transfer control actuator
Connector Terminal F52 3 7 Approx. 8 V
Transfer control unit Transfer control actuator Continuity
Connector Terminal Connector Terminal
E59 39
F52 3
Existed
97
Revision: 2010 May2011 QX56
Page 1862 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-60
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180E SENSOR PO
WER SUPPLY (8V)
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK TRANSFER INTE INFINITI QX56 2011 Factory Service Manual
DLN-60
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180E SENSOR PO
WER SUPPLY (8V)
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK TRANSFER INTE](/manual-img/42/57033/w960_57033-1861.png)
DLN-60
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180E SENSOR PO
WER SUPPLY (8V)
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK TRANSFER INTERNAL SPEED SENSOR POWER SUPPLY (2)
1. Turn the ignition switch OFF.
2. Connect transfer control actuator harness connector.
3. Turn the ignition switch ON. CAUTION:
Never start the engine.
4. Check the voltage between transfer contro l actuator harness connector terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Transfer internal speed sensor is malfunctioni ng. Replace transfer control actuator. Refer to DLN-
114, "Removal and Installation".
4.CHECK TERMINALS AND HARNESS CONNECTORS
Check the pin terminals for damage or loose connection with each harness connector.
Is the inspection result normal?
YES >> Replace transfer control unit. Refer to DLN-107, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Transfer control actuator —Continuity
Connector Terminal
F52 7 Ground Not existed
+ −
Voltag e
Transfer control actuator
Connector Terminal F52 3 7 Approx. 8 V
Revision: 2010 May2011 QX56
Page 1863 of 5598
![INFINITI QX56 2011 Factory Service Manual
P180F TRANSFER INTERNAL SPEED SENSORDLN-61
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180F TRANSFER INTE RNAL SPEED SENSOR
DTC LogicINFOID:0000000006222258
DTC DET INFINITI QX56 2011 Factory Service Manual
P180F TRANSFER INTERNAL SPEED SENSORDLN-61
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180F TRANSFER INTE RNAL SPEED SENSOR
DTC LogicINFOID:0000000006222258
DTC DET](/manual-img/42/57033/w960_57033-1862.png)
P180F TRANSFER INTERNAL SPEED SENSORDLN-61
< DTC/CIRCUIT DIAGNOSIS > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P180F TRANSFER INTE RNAL SPEED SENSOR
DTC LogicINFOID:0000000006222258
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
With CONSULT-III
1. Turn the ignition switch OFF to ON.
2. Turn the 4WD shift switch AUTO ⇒4H ⇒4LO ⇒4H ⇒AUTO.
3. Perform self-diagnosis for “ALL MODE AWD/4WD”.
Is DTC
“P180F” detected?
YES >> Proceed to diagnosis procedure. Refer to DLN-61, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222259
1.CHECK TRANSFER INTERNAL SPEED SENSOR SIGNAL
1. Turn the ignition switch ON.
2. Check the voltage between transfer control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK TRANSFER INTERNAL SPEED SENSOR POWER SUPPLY
DTC Display item Malfunction detected condition Possible cause
P180F MOTOR SYSTEM Malfunction is detected in transfer mo-
tor.
Malfunction is detected in transfer in- ternal speed sensor. Transfer control actuator
Transfer motor error
Transfer internal speed sensor circuit
error
Transfer assembly internal malfunc-
tion.
+
— Condition Voltage
Transfer control unit
Connector Terminal
E59 10 Ground
4WD mode: AUTO
A/T shift selector: N
Depress accelerator pedal several time
31 Ground NOTE:
When changing the transfer motor
rotation direction.
JPDIE0267GB
JPDIE0269GB
Revision: 2010 May2011 QX56
Page 1864 of 5598
![INFINITI QX56 2011 Factory Service Manual
DLN-62
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180F TRANSFER INTE
RNAL SPEED SENSOR
1. Turn the ignition switch OFF.
2. Disconnect transfer control actuator harness connector.
3. Turn the igniti INFINITI QX56 2011 Factory Service Manual
DLN-62
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180F TRANSFER INTE
RNAL SPEED SENSOR
1. Turn the ignition switch OFF.
2. Disconnect transfer control actuator harness connector.
3. Turn the igniti](/manual-img/42/57033/w960_57033-1863.png)
DLN-62
< DTC/CIRCUIT DIAGNOSIS >[TRANSFER: ATX90A]
P180F TRANSFER INTE
RNAL SPEED SENSOR
1. Turn the ignition switch OFF.
2. Disconnect transfer control actuator harness connector.
3. Turn the ignition switch ON.
4. Check the voltage between transfer contro l actuator harness connector terminals.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK TRANSFER INTERNAL SPEED SENSOR POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer control actuator har-
ness connector.
4. Check the continuity between transfer control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace error-detected parts.
4.CHECK TRANSFER INTERNAL S PEED SENSOR SIGNAL CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect transfer control unit harness connector.
3. Check the continuity between transfer control uni t harness connector and transfer control actuator har-
ness connector.
4. Check the continuity between transfer control actuator harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
+ −
Voltag e
Transfer control actuator
Connector Terminal F52 3 7 8V
Transfer control unit Transfer control actuator Continuity
Connector Terminal Connector Terminal
E59 39
F52 3
Existed
97
Transfer control actuator —Continuity
Connector Terminal
F52 3 Ground Not existed
Transfer control unit Transfer control actuator Continuity
Connector Terminal Connector Terminal
E59 10
F52 2
Existed
31 6
Transfer control actuator —Continuity
Connector Terminal
F52 2
Ground Not existed
6
Revision: 2010 May2011 QX56
