REAR AUXILIARY INPUT JACKS
Removal and InstallationINFOID:0000000006216394
REMOVAL
1. Remove console rear finisher. Refer to IP-23, "Exploded View".
2. Remove rear auxiliary input jacks mounting scr ews to remove rear auxiliary input jacks.
INSTALLATION
Install in the reverse order of removal.
