Page 3241 of 5598

INFINITI QX56 2011 Factory Service Manual
REAR AUTOMATIC AIR CONDITIONING SYSTEMHAC-135
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR AUTOMATIC AIR CONDITIONING SYSTEM
Diagnosis Chart By SymptomINF

REAR AUTOMATIC AIR CONDITIONING SYSTEMHAC-135
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR AUTOMATIC AIR CONDITIONING SYSTEM
Diagnosis Chart By SymptomINFOID:0000000006275981
NOTE:
Perform the self-diagnoses with CONSULT-III before performing the symptom diagnosis. If DTC is detected,
perform the corresponding diagnosis.
The following table is based on the condition that fr ont automatic air conditioning system operates normally.
Symptom Corresponding malfunction part Reference
Rear air conditioning system cannot be controlled. (Front A/C control)
Operation status of rear air conditioning system is not indicated on front display. Multi AV system
AV- 1 9 9 , "
Symptom Table"
Rear air conditioning sys-
tem cannot be controlled.
(Rear A/C control)Operation status of
rear air conditioning
system is not indicated
on rear A/C control
display
Power supply system of rear A/C
control
Rear A/C control HAC-115, "
REAR A/C CONTROL :
Diagnosis Procedure"
Operation status of
rear air conditioning
system is indicated on
rear A/C control dis-
play Communication circuit between rear
A/C control and A/C auto amp.
A/C auto amp. HAC-127, "
Diagnosis Procedure"
Air outlet does not change.
Rear mode door motor does not operate normally. Circuit between rear mode door mo-
tor and A/C auto amp.
Rear mode door motor control link- age
Front mode door motor
A/C auto amp. HAC-116, "REAR MODE DOOR
MOTOR : Diagnosis Procedure"
Discharge air temperature does not change.
Rear air mix door motor does not operate normally. Circuit between rear air mix door
motor and A/C auto amp.
Rear air mix door motor installation condition
Rear air mix door motor
A/C auto amp. HAC-114, "REAR AIR MIX DOOR
MOTOR : Diagnosis Procedure"
Rear blower motor operation is malfunctioning.
Power supply system of rear blower
motor
Circuit between rear blower motor
and A/C auto amp..
Rear blower motor
A/C auto amp. HAC-131, "Diagnosis Procedure"
Insufficient cooling.
No cool air comes out. (Air flow volume is normal.) Power supply system of rear A/C re-
lay
Circuit between rear A/C relay and A/C auto amp..
Circuit between rear A/C relay and rear A/C solenoid valve.
Circuit between rear A/C solenoid
valve and ground.
Rear A/C relay
Rear A/C solenoid valve
A/C auto amp.
Refrigerant cycle
Air leakage from each duct
Temperature setti ng trimmer (rear) HAC-139, "REAR AIR CONDI-
TIONER : Diagnosis Procedure"
Revision: 2010 May2011 QX56

Page 3242 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-136
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
REAR AUTOMATIC AIR CONDITIONING SYSTEM
Insufficient heating.
No warm air comes out. (Air flow volume is nor-
mal.) Engine cooling syste

Page 3243 of 5598

INFINITI QX56 2011 Factory Service Manual
ACCS (ADVANCE CLIMATE CONTROL SYSTEM)HAC-137
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
ACCS (ADVANCE CLIMATE CONTROL SYSTEM)
Symptom TableINFOID:00000000062

Page 3244 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-138
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
FRONT AIR CONDITIONER
FRONT AIR CONDITIONER : DescriptionINFOID:0000000006275984
Symptom Insuffici

HAC-138
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
FRONT AIR CONDITIONER
FRONT AIR CONDITIONER : DescriptionINFOID:0000000006275984
Symptom Insufficient cooling
No cool air comes out. (Air flow volume is normal.)
FRONT AIR CONDITIONER
: Diagnosis ProcedureINFOID:0000000006275985
NOTE:
Perform self-diagnoses with CONSULT-III before perform ing symptom diagnosis. If any DTC is detected, per-
form the corresponding diagnosis.
1.CHECK MAGNET CLUTCH OPERATION
1. Turn ignition switch ON.
2. Operate fan switch.
3. Press A/C switch.
4. Check that A/C indicator turns ON. Check visually and by sound that compressor operates.
5. Press A/C switch again.
6. Check that A/C indicator turns OFF. Check that compressor stops.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform diagnosis of “COMPRESSOR DOSE NOT OPERATE” in “SYMPTOM DIAGNOSIS”.
Refer to HAC-142, "
Diagnosis Procedure".
2.CHECK DRIVE BELT
Check tension of drive belt. Refer to EM-20, "
Checking".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Adjust or replace drive belt depending on the inspection results.
3.CHECK REFRIGERANT CYCLE
Connect recovery/recycling recharging equipment to the vehicle and perform pressure inspection with gauge.
Refer to HA-27, "
Symptom Table".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace parts depending on the inspection results.
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of the fr ont air conditioning system for leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK AMBIENT TEMPERATURE DISPLAY
Check that there is not much diference between act ual ambient temperature and indicated temperature on
information display in combination meter.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Perform diagnosis for the A/C auto amp. connection recognition signal circuit. Refer to MWI-74,
"DiagnosisProcedure".
6.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (FRONT)
1. Check setting value of temperature setting trimmer (front). Refer to HAC-68, "
FRONT AUTOMATIC AIR
CONDITIONING SYSTEM : Temperature Setting Trimmer (Front)".
2. Check that temperature setting trimme r (front) is set to “+ direction”.
Revision: 2010 May2011 QX56

Page 3245 of 5598

INFINITI QX56 2011 Factory Service Manual
INSUFFICIENT COOLINGHAC-139
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
NOTE:
The control temperature can be set with the setti ng of the temperature setting

INSUFFICIENT COOLINGHAC-139
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
NOTE:
The control temperature can be set with the setti ng of the temperature setting trimmer (front).
3. Set difference between set temperature and control temperature to “0”.
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace A/C auto amp.. Refer to HAC-146, "
Removal and Installation".
REAR AIR CONDITIONER
REAR AIR CONDITIONER : DescriptionINFOID:0000000006275986
Symptom Insufficient cooling
No cool air comes out. (Air flow volume is normal.)
REAR AIR CONDITIONER : Diagnosis ProcedureINFOID:0000000006275987
NOTE:
Perform self-diagnoses with CONSULT-III before performi ng symptom diagnosis. If any DTC is detected, per-
form the corresponding diagnosis.
1.CHECK REAR A/C SOLENOID VALVE
Check rear A/C solenoid valve. Refer to HAC-128, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning parts.
2.CHECK REFRIGERANT CYCLE
Connect recovery/recycling recharging equipment to t he vehicle and perform pressure inspection with gauge.
Refer to HA-27, "
Symptom Table".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace parts depending on the inspection results.
3.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of the rear air conditioning system for leakage.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace parts depending on the inspection results.
4.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (REAR)
1. Check setting value of temperature setting trimmer (rear). Refer to HAC-69, "
REAR AUTOMATIC AIR
CONDITIONING SYSTEM : Temperature Setting Trimmer (Rear)".
2. Check that temperature setting trimmer (rear) is set to “+ direction”. NOTE:
The control temperature can be set with the sett ing of the temperature setting trimmer (rear).
3. Set difference between set temperature and control temperature to “0”.
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace A/C auto amp.. Refer to HAC-146, "
Removal and Installation".
Revision: 2010 May2011 QX56

Page 3246 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-140
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
INSUFFICIENT HEATING
INSUFFICIENT HEATING
FRONT AIR CONDITIONER
FRONT AIR CONDITIONER : DescriptionINFOID:0000000006275990
Symptom Insuffici

HAC-140
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
INSUFFICIENT HEATING
INSUFFICIENT HEATING
FRONT AIR CONDITIONER
FRONT AIR CONDITIONER : DescriptionINFOID:0000000006275990
Symptom Insufficient heating
No warm air comes out. (Air flow volume is normal.)
FRONT AIR CONDITIONER
: Diagnosis ProcedureINFOID:0000000006275991
NOTE:
Perform self-diagnoses with on board diagnosis and CO NSULT-III before performing symptom diagnosis. If
DTC is detected, perform the corresponding diagnosis.
1.CHECK COOLING SYSTEM
1. Check engine coolant level and check leakage. Refer to CO-8, "
Inspection".
2. Check reservoir tank cap. Refer to CO-11, "
RESERVOIR TANK CAP : Inspection".
3. Check water flow sounds of the engine coolant. Refer to CO-9, "
Refilling".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refill engine coolant and repair or repl ace parts depending on the inspection results.
2.CHECK HEATER HOSE
Check installation of heater hose by visually or touching.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace parts depending on the inspection results.
3.CHECK FRONT HEATER CORE
1. Check temperature of inlet hose and outlet hose of front heater core.
2. Check that inlet side of front heater core is hot and t he outlet side is slightly lower than/almost equal to the
inlet side.
CAUTION:
Always perform the temperature in spection in a short period of time because the engine coolant
temperature is very hot.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front heater core. Refer to HA-44, "
HEATER CORE : Removal and Installation".
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of front air conditioning system for air leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (FRONT)
1. Check setting value of temperature setting trimmer (front). Refer to HAC-68, "
FRONT AUTOMATIC AIR
CONDITIONING SYSTEM : Temperature Setting Trimmer (Front)".
2. Check that temperature setting trimmer (front) is set to “ − direction”.
NOTE:
The control temperature can be set by t he temperature setting trimmer (front).
3. Set difference between the set temperature and control temperature to “0”.
Are the symptoms solved?
YES >> INSPECTION END
NO >> Replace A/C auto amp.. Refer to HAC-146, "
Removal and Installation".
REAR AIR CONDITIONER
Revision: 2010 May2011 QX56

Page 3247 of 5598

INFINITI QX56 2011 Factory Service Manual
INSUFFICIENT HEATINGHAC-141
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR AIR CONDITIONER : DescriptionINFOID:0000000006275992
Symptom
Insufficient heati

INSUFFICIENT HEATINGHAC-141
< SYMPTOM DIAGNOSIS > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR AIR CONDITIONER : DescriptionINFOID:0000000006275992
Symptom
Insufficient heating
No warm air comes out. (Air flow volume is normal.)
REAR AIR CONDITIONER : Diagnosis ProcedureINFOID:0000000006275993
CAUTION:
Perform the self-diagnoses with on board diagnosi s and CONSULT-III before performing symptom
diagnosis. If any malfunction result or DTC is detected, perform the corresponding diagnosis.
1.CHECK COOLING SYSTEM
1. Check engine coolant level and check leakage. Refer to CO-8, "
Inspection".
2. Check reservoir tank cap. Refer to CO-11, "
RESERVOIR TANK CAP : Inspection".
3. Check water flow sounds of the engine coolant. Refer to CO-9, "
Refilling".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refill the engine coolant and repair or replace the parts depending on the inspection results.
2.CHECK HEATER HOSE
Check installation of heater hose by visually or touching.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace parts depending on the inspection results.
3.CHECK REAR HEATER CORE
1. Check temperature of inlet hose and outlet hose of rear heater core.
2. Check that the inlet side of rear heater core is hot and the outlet side is slightly lower than/almost equal to
the inlet side.
CAUTION:
Always perform the temperature inspection in a sh ort period of time because the engine coolant
temperature is very hot.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear heater core. Refer to HA-48, "
HEATER CORE : Removal and Installation".
4.CHECK AIR LEAKAGE FROM EACH DUCT
Check duct and nozzle, etc. of the rear air conditioning system for air leakage.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace parts depending on the inspection results.
5.CHECK SETTING OF TEMPERATURE SETTING TRIMMER (REAR)
1. Check setting value of temperature setting trimmer (rear). Refer to HAC-69, "
REAR AUTOMATIC AIR
CONDITIONING SYSTEM : Temperature Setting Trimmer (Rear)".
2. Check that the temperature setting trimmer is set to “ − direction”.
NOTE:
The control temperature can be set by the temperature setting trimmer (rear).
3. Set the difference between the set temperature (rear) and control temperature to “0”.
Are the symptoms solved?
YES >> INSPECTION END
NO >> Replace A/C auto amp.. Refer to HAC-146, "
Removal and Installation".
Revision: 2010 May2011 QX56

Page 3248 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-142
< SYMPTOM DIAGNOSIS >[AUTOMATIC AIR CONDITIONING]
COMPRESSOR DOSE DOT OPERATE
COMPRESSOR DOSE DOT OPERATE
DescriptionINFOID:0000000006275994
Symptom: Compressor dose not operate.
Diagnosis Pr

Load next 8 pages

Page: < prev 1-10 ... 3209-3216 3217-3224 3225-3232 3233-3240 3241-3248 3249-3256 3257-3264 3265-3272 3273-3280 ... 5600 next >

engine oil carplay seat memory radio controls apple carplay wheel size
