COMPONENT PARTSHAC-7
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
FRONT AUTOMATIC AIR CONDITIONING SYSTEM : Component Description
INFOID:0000000006275849
13. Aspirator 14. Front air mix door motor (Driver side) 15. Intake sensor
16. Front mode door motor 17. Front air mix door motor (Passenger
side)18. Intake door motor
19. Front blower motor 20. A/C auto amp. 21. Front in-vehicle sensor
A. Left side of heater & cooling unit as- sembly B. Right side of heater & cooling unit as-
sembly C. Back side of blower unit assembly
D. Cluster lid C is removed E. Ins trument lower panel LH is re-
moved
Component Description
Ambient sensor Ambient sensor measures ambient air temperature. The sensor uses a
thermistor which is sensitive to the change in temperature. The electrical
resistance of the thermistor decreases as temperature increases.
AV c o n t r o l u n i t AV control unit transmits front A/C control operation signal to A/C auto amp.
via CAN communication line.
A/C auto amp. A/C auto amp. controls front automatic air conditioning system by inputting
and calculating signals from each sensor and each switch. A/C auto amp.
has self-diagnosis function. Diagnosis of front automatic air conditioning
system can be performed quickly.
Blower unit Front blower motor Refer to
HAC-12
.
Intake door motor The LCU (Local Control Unit) is installed to intake door motor so as to per-
form the multiplex commu
nication control (LIN).
Refer to HAC-18, "
FRONT AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
Combination meter Combination meter transmits vehicle speed signal to A/C auto amp. via
CAN communication line.
ECM ECM controls compressor according to status of engine and refrigerant.
ECM transmits engine coolant temperature signal to A/C auto amp. via
CAN communication line.
Engine coolant temperature sensor Engine coolant temperature sensor measures engine coolant temperature.
The sensor uses a thermistor which is sensitive to the change in tempera-
ture. The electrical resistance of the thermistor decreases as temperature
increases.
Front display Front display indicates operation status of front automatic air conditioning
system.
Front in-vehicle sensor Front in-vehicle sensor measures temperature of intake air that flows
through aspirator to passenger room. The sensor uses a thermistor which
is sensitive to the change in temperature. The electrical resistance of the
thermistor decreases as temperature increases.
Revision: 2010 May2011 QX56
Page 3114 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-8
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
REAR AUTOMATIC AIR CONDITIONING SYSTEM
Heater & cooling unit
assemblyAspirator Refer to
HAC-12
.
Front air mix door motor (D INFINITI QX56 2011 Factory Service Manual
HAC-8
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
REAR AUTOMATIC AIR CONDITIONING SYSTEM
Heater & cooling unit
assemblyAspirator Refer to
HAC-12
.
Front air mix door motor (D](/manual-img/42/57033/w960_57033-3113.png)
HAC-8
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
REAR AUTOMATIC AIR CONDITIONING SYSTEM
Heater & cooling unit
assemblyAspirator Refer to
HAC-12
.
Front air mix door motor (Driver
side) The LCU (Local Control Unit) is installe
d to front air mix door motor (driver
side) so as to perform the multiplex communication control (LIN).
Refer to HAC-18, "
FRONT AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
Front air mix door motor (Pas-
senger side) The LCU (Local Control Unit) is installed to front air mix door motor (pas-
senger side) so as to perform the multiplex communication control (LIN).
Refer to
HAC-18, "
FRONT AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
Front mode door motor The LCU (Local Control Unit) is installed to front mode door motor so as to
perform the multiplex communication control (LIN).
Refer to
HAC-18, "
FRONT AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
Intake sensor Intake sensor measures temperature of front evaporator fin temperature.
The sensor uses a thermistor which is sensitive to the change in tempera-
ture. The electrical resistance of the thermistor decreases as temperature
increases.
Upper ventilator door motor The LCU (Local Control Unit) is installed to upper ventilator door motor so
as to perform the multiplex communication control (LIN).
Refer to
HAC-18, "
FRONT AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
IPDM E/R A/C relay is integrated in
IPDM E/R. IPDM E/R op erates A/C relay when A/
C compressor request signal is received from ECM via CAN communica-
tion line.
Magnet clutch The magnet clutch is the device that drives the compressor with the signal
from IPDM E/R. Compressor is driven by the magnet clutch which is mag-
netized by electric power supply. IPDM controls magnet clutch by turning
the built in A/C relay to ON
⇔ OFF according to ECM request.
Preset switch Preset switch is integrated with front A/C control and AV operation switch.
Front A/C control operation signal is transmitted from preset switch to AV
control unit via communication line.
Refrigerant pressure sensor Refer to HAC-13
.
Sunload sensor Sunload sensor measures sunload amount. This sensor is a dual system
so that sunload for driver side and passenger side are measured separate-
ly. This sensor converts sunload amount to voltage signal by photodiode
and transmits to A/C auto amp..
Component Description
Revision: 2010 May2011 QX56
Page 3115 of 5598
COMPONENT PARTSHAC-9
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
REAR AUTOMATIC AIR CONDITIONING SY STEM : Component Parts Location
INFOID:0000000006275850
1. Rear A/C control 2. Preset switch 3. Engine coolant temperature sensor
Refer to EC-16, "
Component Parts
Location".
4. ECM Refer to EC-16, "
Component Parts
Location". 5. Ambient sensor 6. AV control unit
Refer to AV- 9 , "
Component Parts Lo-
cation".
7. Combination meter Refer to MWI-6, "
METER SYSTEM :
Component Parts Location". 8. Sunload sensor 9. Front display
10. Rear mode door motor 11. Rear air mix door motor 12. Rear in-vehicle sensor
13. Rear blower motor 14. Rear A/C solenoid valve 15. Rear A/C relay
16. Intake sensor 17. A/C auto amp.
A. Right side of rear A/C unit assembly B. Left side of rear A/C unit assembly C. Back side of engine room (RH)
D. Left side of heater & cooling unit as- sembly E. Cluster lid C is removed
JMIIA0813ZZ
Revision: 2010 May2011 QX56
Page 3116 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-10
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
REAR AUTOMATIC AIR CONDITIONING SYSTEM : Component Description
INFOID:0000000006275851
ACCS (ADVANCED CLIMATE CONTROL SYSTEM INFINITI QX56 2011 Factory Service Manual
HAC-10
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
REAR AUTOMATIC AIR CONDITIONING SYSTEM : Component Description
INFOID:0000000006275851
ACCS (ADVANCED CLIMATE CONTROL SYSTEM](/manual-img/42/57033/w960_57033-3115.png)
HAC-10
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
REAR AUTOMATIC AIR CONDITIONING SYSTEM : Component Description
INFOID:0000000006275851
ACCS (ADVANCED CLIMATE CONTROL SYSTEM)
Component Description
Ambient sensor Ambient sensor measures ambient air temperature. The sensor uses a
thermistor which is sensitive to the change in temperature. The electrical
resistance of the thermistor decreases as temperature increases.
AV c o n t r o l u n i t AV control unit transmits front A/C control operation signal to A/C auto amp.
via CAN communication line.
A/C auto amp. A/C auto amp. controls rear automatic air conditioning system by inputting
and calculating signals from each sensor and each switch. A/C auto amp.
has self-diagnosis function. Diagnosis of rear automatic air conditioning
system can be performed quickly.
Combination meter Combination meter transmits vehicle speed signal to A/C auto amp. via
CAN communication line.
ECM ECM transmits engine coolant temperature signal to A/C auto amp. via
CAN communication line.
Engine coolant temperature sensor Engine coolant temperature sensor measures engine coolant temperature.
The sensor uses a thermistor which is sensitive to the change in tempera-
ture. The electrical resistance of the thermistor decreases as temperature
increases.
Front display Front display indicates operation status of rear automatic air conditioning
system.
Heater & cooling unit
assembly Intake sensor Intake sensor measures temperature of front evaporator fin temperature.
The sensor uses a thermistor which is sensitive to the change in tempera-
ture. The electrical resistance of the thermistor decreases as temperature
increases.
Preset switch Preset switch is integrated with front A/C control and AV operation switch.
Front A/C control operation signal is transmitted from preset switch to AV
control unit via communication line.
Rear A/C control The operation of the rear A/C control is communicated with the A/C auto
amp. via communication line.
Rear A/C relay Power is supplied to the rear A/C solenoid valve through rear A/C relay with
A/C auto amp. control.
Rear A/C unit assem-
bly Rear air mix door motor
The LCU (Local Contro
l Unit) is installed to rear air mix door motor so as to
perform the multiplex communication control (LIN).
Refer to HAC-26, "
REAR AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
Rear A/C solenoid valve Rear A/C solenoid valve operates by power supply from rear A/C relay and
opens refrigerant line to rear evaporator.
Rear blower motor Refer to HAC-13
.
Rear in-vehicle sensor Rear in-vehicle sensor measures temperature of intake air that flows
through rear blower motor to passenger room. The sensor uses a ther-
mistor which is sensitive to the change in temperature. The electrical resis-
tance of the thermistor decreases as temperature increases.
Rear mode door motor The LCU (Local Control Unit) is installed to rear mode door motor so as to
perform the multiplex communication control (LIN).
Refer to
HAC-26, "
REAR AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
Sunload sensor Sunload sensor measures sunload amount. This sensor is a dual system
so that sunload for driver side and passenger side are measured separate-
ly. This sensor converts sunload amount to voltage signal by photodiode
and transmits to A/C auto amp..
Revision: 2010 May2011 QX56
Page 3117 of 5598
![INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSHAC-11
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
ACCS (ADVANCED CLIMATE CONTROL SYSTEM) : Component Parts Location
INFOID:0000000006275852
INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSHAC-11
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
ACCS (ADVANCED CLIMATE CONTROL SYSTEM) : Component Parts Location
INFOID:0000000006275852](/manual-img/42/57033/w960_57033-3116.png)
COMPONENT PARTSHAC-11
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
ACCS (ADVANCED CLIMATE CONTROL SYSTEM) : Component Parts Location
INFOID:0000000006275852
ACCS (ADVANCED CLIMATE CONTRO L SYSTEM) : Component Description
INFOID:0000000006275853
1. Preset switch 2. Exhaust gas / outside odor detecting
sensor3. AV control unit
Refer to AV- 9 , "
Component Parts Lo-
cation".
4. Front display 5. Ionizer 6. Intake door motor
7. A/C auto amp.
A. Left side of heater & cooling unit as- sembly B. Back side of blower unit assembly C. Cluster lid C is removed
JMIIA0814ZZ
Component Description
Blower unit Intake door motor The LCU (Local Control Unit) is installed to intake door motor so as to per-
form the multiplex communication control (LIN).
Refer to
HAC-18, "
FRONT AUTOMATIC AIR CONDITIONING SYSTEM :
Door Control".
AV c o n t r o l u n i t AV control unit transmits A/C switch operation signal to A/C auto amp. via
CAN communication line.
A/C auto amp. A/C auto amp. controls ACCS (advanced climate control system) by input-
ting and calculating signals from each sensor and each switch. A/C auto
amp. has self-diagnosis function. Diagnosis of ACCS (advanced climate
control system) can be performed quickly.
Exhaust gas / outside odor detecting sensor Exhaust gas / outside odor detecting sensor measures unpleasant odor out-
side of passenger room. In addition to previous exhaust gas detection func-
tion, unpleasant odor in ambient atmosphere is measured.
Revision: 2010 May2011 QX56
Page 3118 of 5598
![INFINITI QX56 2011 Factory Service Manual
HAC-12
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
Aspirator
INFOID:0000000006275856
The aspirator generates the vacuum by the air blown from the heater
& cooling unit and draw INFINITI QX56 2011 Factory Service Manual
HAC-12
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
Aspirator
INFOID:0000000006275856
The aspirator generates the vacuum by the air blown from the heater
& cooling unit and draw](/manual-img/42/57033/w960_57033-3117.png)
HAC-12
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
COMPONENT PARTS
Aspirator
INFOID:0000000006275856
The aspirator generates the vacuum by the air blown from the heater
& cooling unit and draws the air of the passenger room to the front
in-vehicle sensor area via the aspirator duct.
Front Blower MotorINFOID:0000000006275857
The front blower motor utilizes a brush-less motor with a rotating
magnet. Quietness is improved comparing to a conventional motor
(brush motor) that rotates coil while brush functions as contact
points.
Front display Front display indicates operation status of ACCS (advanced climate control
system).
Heater & cooling unit as-
sembly Ionizer Ionizer generates an approximately equal proportional amount of positive
and negative ions in the air.
Preset switch Preset switch is integrated with front A/C control and AV operation switch.
Front A/C control operation signal is transmitted from preset switch to AV
control unit via communication line.
Component Description
RJIA1804E
RJIA2467J
ZHA152H
Revision: 2010 May2011 QX56
Page 3119 of 5598
![INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSHAC-13
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Rear Blower MotorINFOID:0000000006275858
The rear blower motor utilizes a brush-less motor INFINITI QX56 2011 Factory Service Manual
COMPONENT PARTSHAC-13
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Rear Blower MotorINFOID:0000000006275858
The rear blower motor utilizes a brush-less motor](/manual-img/42/57033/w960_57033-3118.png)
COMPONENT PARTSHAC-13
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Rear Blower MotorINFOID:0000000006275858
The rear blower motor utilizes a brush-less motor with a rotating
magnet. Quietness is improved comp aring to a conventional motor
(brush motor) that rotates coil while brush functions as contact
points.
Refrigerant Pressure SensorINFOID:0000000006275859
Description
Refrigerant pressure sensor is installed to upper porti on of liquid tank. The refrigerant pressure sensor con-
verts high-pressure side refrigerant pressure into vo ltage and outputs it to ECM. ECM operates cooling system
protection and idle speed control according to voltage value that is input.
Structure and operation
The refrigerant pressure sensor is a capacitance type sensor. It consists of a pressure detection area and a
signal processing area. The pressure detection area, wh ich is a variable capacity condenser, changes internal
static capacitance according to pressure force. The signal processing area detects the static capacitance of
the pressure detection area, converts the static capacitance into a voltage value, and transmits the voltage
value to ECM.
RJIA2467J
ZHA152H
PBIB2657E
Revision: 2010 May2011 QX56
Page 3120 of 5598
HAC-14
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
SYSTEM
SYSTEM
FRONT AUTOMATIC AIR CONDITIONING SYSTEM
FRONT AUTOMATIC AIR CONDITION
ING SYSTEM : System DiagramINFOID:0000000006275860
FRONT AUTOMATIC AIR CONDITIONIN G SYSTEM : System DescriptionINFOID:0000000006275861
Front automatic air conditioning system is controlled by each function of A/C auto amp., ECM and IPDM E/
R.
Control by A/C auto amp.- HAC-15, "FRONT AUTOMATIC AIR CONDITIONING SYSTEM : Air Flow Control"
-HAC-16, "FRONT AUTOMATIC AIR CONDITIONING SYSTEM : Air Inlet Control"
JMIIA0816GB
Revision: 2010 May2011 QX56
