Page 1057 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS-92
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ACCELERATOR PEDAL ACTUATOR)
ACTIVE TEST
CAUTION:
Never perform ACTIVE TEST while driving the vehicle.
NOTE:
The active test cannot be performed wh INFINITI QX56 2011 Factory Service Manual
DAS-92
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ACCELERATOR PEDAL ACTUATOR)
ACTIVE TEST
CAUTION:
Never perform ACTIVE TEST while driving the vehicle.
NOTE:
The active test cannot be performed wh](/manual-img/42/57033/w960_57033-1056.png)
DAS-92
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ACCELERATOR PEDAL ACTUATOR)
ACTIVE TEST
CAUTION:
Never perform ACTIVE TEST while driving the vehicle.
NOTE:
The active test cannot be performed when the
ICC system warning lamp is illuminated.
Item list
ACCELERATOR PEDAL ACTUATOR TEST 1
NOTE:
Check the accelerator pedal by depressing when performing the test.
ACCELERATOR PEDAL ACTUATOR TEST 2
NOTE:
Check the accelerator pedal by depressing when performing the test.
ECU IDENTIFICATION
Displays accelerator pedal assembly parts number.
Monitor item [Unit] FUNCTION DESCRIPTION
TGT FBK FRC
[N] It displays the target accelerator pedal actuation force that the accelerator pedal actuator read out
from the accelerator pedal feedback force control signal received via ITS communication
(The ADAS control unit transmits the accelerator pedal feedback force control signal via ITS commu-
nication)
TGT MOT POSI
[%] It displays the target motor position that the acce
lerator pedal actuator read out from the accelerator
pedal feedback force control signal received via ITS communication
(The ADAS control unit transmits the accelerator pedal feedback force control signal via ITS commu-
nication)
ACT MOT POSI
[%] It displays the integrated motor position that the accelerator pedal actuator read out
AP OPEN
[%] It displays the accelerator pedal position signal that the accelerator pedal actuator read out via ITS
communication
(The ADAS control unit transmits with ITS communication the accelerator pedal position signal that
is received from ECM via CAN communication)
APA TEMP
[ ° C] It displays the accelerator pedal actuator integrated motor temperature
APA CURRENT
[A] It displays the accelerator pedal actuator integrated motor consumption current
APA PWR
[V] It displays the power supply voltage that the accelerator pedal actuator read out
APA OPE STATS
[On/Off] It displays the activation permission status of accelerator pedal actuator
APA STATS
[READY/NG/TP NG/INIT] It displays the condition of accelerator pedal actuator
Active test item Description
ACCELERATOR PEDAL ACTUATOR TEST1 Drive the accelerator pedal actuator and generate the constant accelerator pedal
actuation force
ACCELERATOR PEDAL ACTUATOR TEST2 Drive the accelerator pedal actuator and generate the vibration
Active test item Operation Description
ACCELERATOR PEDAL AC-
TUATOR TEST1 STOP Finish the test
START Generate the constant accelerator pedal actuation force for accelerator pedal
Active test item Operation Description
ACCELERATOR PEDAL AC-
TUATOR TEST 2 STOP Finish the test
START Generate the vibration for accelerator pedal
Revision: 2010 May2011 QX56
Page 1058 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-93
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
ECU DIAGNOSIS INFORMATION
ADAS CONTROL UNIT
Reference ValueINFOID:0000000006223510
VALUES ON THE DIAGNOSI INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-93
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
ECU DIAGNOSIS INFORMATION
ADAS CONTROL UNIT
Reference ValueINFOID:0000000006223510
VALUES ON THE DIAGNOSI](/manual-img/42/57033/w960_57033-1057.png)
DAS
ADAS CONTROL UNITDAS-93
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
ECU DIAGNOSIS INFORMATION
ADAS CONTROL UNIT
Reference ValueINFOID:0000000006223510
VALUES ON THE DIAGNOSIS TOOL
Monitor item Condition Value/Status
MAIN SW Ignition switch ON When MAIN switch is pressed On
When MAIN switch is not pressed Off
SET/COAST SW Ignition switch ON When SET/COAST switch is pressed On
When SET/COAST switch is not pressed Off
CANCEL SW Ignition switch ON When CANCEL switch is pressed On
When CANCEL switch is not pressed Off
RESUME/ACC SW Ignition switch ON When RESUME/ACCELERATE
switch is pressed On
When RESUME/ACCELERATE switch is not pressed Off
DISTANCE SW Ignition switch ON When DISTANCE swit
ch is pressed On
When DISTANCE switch is not pressed Off
CRUISE OPE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC system is controlling On
When ICC system is not controlling Off
BRAKE SW Ignition switch ON When brake pedal is depressed Off
When brake pedal is not depressed On
STOP LAMP SW Ignition switch ON When brake pedal is depressed On
When brake pedal is not depressed Off
IDLE SW Engine running Idling On
Except idling (depress accelerator pedal) Off
SET DISTANCE Start the engine and turn the
ICC system ON
Press the DISTANCE switch to change the vehi-
cle-to-vehicle distance set-
ting When set to “long” Long
When set to “middle” Mid
When set to “short” Short
CRUISE LAMP Start the engine and press
MAIN switch ICC system ON
(MAIN switch indicator ON)
On
ICC system OFF
(MAIN switch indicator OFF) Off
OWN VHCL Start the engine and press
MAIN switch ICC system ON
(Own vehicle indicator ON)
On
ICC system OFF
(Own vehicle indicator OFF) Off
VHCL AHEAD Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected (vehicle ahead de-
tection indicator ON)
On
When a vehicle ahead is not detected (vehicle ahead
detection indicator OFF) Off
ICC WARNING Start the engine and press
MAIN switch When ICC system is malfunctioning
(ICC system warning lamp ON)
On
When ICC system is normal
(ICC system warning lamp OFF) Off
Revision: 2010 May2011 QX56
Page 1059 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS-94
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed INFINITI QX56 2011 Factory Service Manual
DAS-94
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed](/manual-img/42/57033/w960_57033-1058.png)
DAS-94
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed is set Displays the set
vehicle speed
BUZZER O/P Engine running When the buzzer of the following system operates
Vehicle-to-vehicle distance control mode
DCA system
FCW system
IBA system
On
When the buzzer of the following system not operates
Vehicle-to-vehicle distance control mode
DCA system
FCW system
IBA system Off
THRTL SENSOR NOTE:
The item is indicated, but not monitored
0.0
ENGINE RPM Engine running Equivalent to ta-
chometer read- ing
WIPER SW Ignition switch ON Wiper not operating Off
Wiper LO operation Low
Wiper HI operation High
YAW R AT E NOTE:
The item is indicated, but not monitored
0.0
BA WARNING Engine running IBA OFF indicator lamp ON
When IBA system is malfunctioning
When IBA system is turned to OFF
On
IBA OFF indicator lamp OFF
When IBA system is normal
When IBA system is turned to ON Off
STP LMP DRIVE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC brake hold relay is activated On
When ICC brake hold relay is not activated Off
D RANGE SW Engine running When the selector lever is in “D” position or manual
mode
On
When the selector lever is in any position other than “D”
or manual mode Off
NP RANGE SW Engine running When the selector lever is
in “N”, “P” position On
When the selector lever is in any position other than “N”,
“P” Off
PKB SW Ignition switch ON When the parking brake is applied On
When the parking brake is released Off
PWR SUP MONI Engine running Power supply
voltage value of ADAS control unit
VHCL SPD AT While driving Va l u e o f A / T v e -
hicle speed sen- sor signal
THRTL OPENING Engine running Depress accelerator pedal Displays the
throttle position
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56
Page 1060 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-95
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
GEAR While driving Displays the
gear position
MODE SIG Start the engine and press
MAIN switch When ICC INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-95
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
GEAR While driving Displays the
gear position
MODE SIG Start the engine and press
MAIN switch When ICC](/manual-img/42/57033/w960_57033-1059.png)
DAS
ADAS CONTROL UNITDAS-95
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
GEAR While driving Displays the
gear position
MODE SIG Start the engine and press
MAIN switch When ICC system is deactivated Off
When vehicle-to-vehicle distance control mode is acti-
vated
ICC
When conventional (fixed speed) cruise control mode is
activated ASCD
SET DISP IND Drive the vehicle and acti-
vate the conventional (fixed
speed) cruise control mode
Press SET/COAST switch SET switch indicator ON On
SET switch indicator OFF Off
DISTANCE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the dis-
tance from the
preceding vehi- cle
When a vehicle ahead is not detected 0.0
RELATIVE SPD Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the rel-
ative speed.
When a vehicle ahead is not detected 0.0
DYNA ASIST SW Ignition switch ON When dynamic driver assistance switch is pressed On
When dynamic driver assistance switch is not pressed Off
DCA ON IND Start the engine and press dy-
namic driver assistance switch
(When DCA setting is ON) DCA system OFF
(DCA system switch indicator OFF)
Off
DCA system ON
(DCA system switch indicator ON) On
DCA VHL AHED Drive the vehicle and activate
the DCA system When a vehicle ahead is not detected (vehicle ahead
detection indicator OFF)
Off
When a vehicle ahead is detected (vehicle ahead de-
tection indicator ON) On
IBA SW Ignition switch ON When the IBA OFF switch is pressed On
When the IBA OFF switch is not pressed Off
FCW SYSTEM ON Ignition switch ON When the FCW system is ON
(Warning systems ON indicator ON)
On
When the FCW system is OFF
(Warning systems ON indicator OFF) Off
APA TEMP Engine running Display the ac-
celerato
r pedal
actuator inte- grated motor temperature
APA PWR Ignition switch ON Power supply
voltage value of
accelerator ped- al actuator
LDW SYSTEM ON Ignition switch ON When the LDW system is ON
(Warning systems ON indicator ON)
On
When the LDW system is OFF
(Warning systems ON indicator OFF) Off
LDW ON LAMP Ignition switch ON Warning systems ON indicator ON On
Warning systems ON indicator OFF Off
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56
Page 1061 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS-96
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON INFINITI QX56 2011 Factory Service Manual
DAS-96
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON](/manual-img/42/57033/w960_57033-1060.png)
DAS-96
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON indicator lamp OFF Off
LANE DPRT W/L Drive the vehicle and activate
the LDW system or LDP sys-
tem Lane departure warning lamp ON On
Lane departure warning lamp OFF Off
LDW BUZER OUT-
PUT Drive the vehicle and activate
the LDW/LDP system or BSW
system When the buzzer of the following system operates
LDW/LDP system
BSW system
On
When the buzzer of the following system does not oper-
ate
LDW/LDP system
BSW system Off
LDP SYSTEM ON Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
READY signal Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
Camera lost Drive the vehicle and activate
the LDW system, LDP system Both side lane markers are detected Detect
Deviate side lane marker is lost Deviate
Both side lane markers are lost Both
Shift position Engine running
While driving Displays the
shift position
Turn signal Turn signal lamps OFF
Off
Turn signal lamp LH blinking LH
Turn signal lamp RH blinking RH
Turn signal lamp LH and RH blinking LH&RH
SIDE G While driving Vehicle turning right Negative value
Vehicle turning left Positive value
WARN REQ Drive the vehicle and activate
the LDP system Lane departure warning is operating On
Lane departure warning is not operating Off
STATUS signal Drive the vehicle and activate
the LDP system When the LDP system is ON Stnby
When the LDP system is operating Warn
When the LDP system is canceled Cancl
When the LDP system is OFF Off
Lane unclear While driving Lane marker is unclear On
Lane marker is clear Off
FUNC ITEM Ignition switch ON FUNC1
FUNC ITEM (NV-ICC) Ignition switch ON Off
FUNC ITEM (NV-
DCA) Ignition switch ON
Off
DCA SELECT Ignition switch ON “Distance Control Assist” set with the navigation system
is ON
On
“Distance Control Assist” set with the navigation system
is OFF Off
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56
Page 1062 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-97
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
TERMINAL LAYOUT
PHYSICAL VALUES
LDP SELECT Ignition switch ON “Lane Departure Prevention” set with th INFINITI QX56 2011 Factory Service Manual
DAS
ADAS CONTROL UNITDAS-97
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
TERMINAL LAYOUT
PHYSICAL VALUES
LDP SELECT Ignition switch ON “Lane Departure Prevention” set with th](/manual-img/42/57033/w960_57033-1061.png)
DAS
ADAS CONTROL UNITDAS-97
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
TERMINAL LAYOUT
PHYSICAL VALUES
LDP SELECT Ignition switch ON “Lane Departure Prevention” set with the navigation
system is ON
On
“Lane Departure Prevention” set with the navigation
system is OFF Off
BSI SELECT NOTE:
The item is indicated, but not monitored Off
NAVI ICC SELECT NOTE:
The item is indicated, but not monitored Off
NAVI DCA SELECT NOTE:
The item is indicated, but not monitored
Off
SYS SELECTABILITY Ignition switch ON Items set with the navigation system can be switched
normally
On
Items set with the navigation system cannot be
switched normally Off
WARN SYS SW Ignition switch ON When warning systems switch is pressed On
When warning systems switch is not pressed Off
BSW/BSI WARN LMP Ignition switch ON BSW warning lamp ON On
BSW warning lamp OFF Off
BSW SYSTEM ON Ignition switch ON When the BSW system is ON
(Warning systems ON indicator ON)
On
When the BSW system is OFF
(Warning systems ON indicator OFF) Off
4WD SW Engine running 4WD shift switch position is in AUTO AUTO
4WD shift switch position is in 4H 4H
4WD shift switch position is in 4L 4L
Monitor item Condition Value/Status
JSOIA0213ZZ
Revision: 2010 May2011 QX56
Page 1063 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS-98
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223511
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns INFINITI QX56 2011 Factory Service Manual
DAS-98
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223511
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns](/manual-img/42/57033/w960_57033-1062.png)
DAS-98
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223511
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
+ − Signal name Input/
Output
1
(V/W)
Ground Warning systems
switch
InputIgnition
switch ON When warning systems
switch is not pressed
12 V
When warning systems
switch is pressed 0 V
3
(R/Y) IBA OFF switch Input Ignition
switch
ON When IBA OFF switch is
not pressed
12 V
When IBA OFF switch is
pressed 0 V
4
(LG/B) Warning systems ON
indicator
OutputIgnition
switch ON Warning systems ON indi-
cator ON
0 V
Warning systems ON indi-
cator OFF 12 V
5
(R) ICC brake hold relay
drive signal
OutputIgnition
switch ON —12 V
At “STOP LAMP” test of
“Active test” 0 V
6
(B) Ground — Ignition
switch ON —0 V
7
(L) ITS communication-H — — — —
8
(Y) ITS communication-L — — — —
12
(G/R) Warning buzzer signal Output Ignition
switch ON Warning buzzer operation 0 V
Warning buzzer not oper-
ating
12 V
14
(L) CAN -H — — — —
15
(P) CAN -L — — — —
16
(W/G) Ignition power supply Input Ignition switch ON Battery Voltage
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warn
ing lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
tone
ICC system warn
ing lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
toneIBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
tone
ICC system warn
ing lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56
Page 1064 of 5598
DAS
ADAS CONTROL UNITDAS-99
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
DTC Inspection Priority ChartINFOID:0000000006223512
If multiple DTCs are detected simultaneously, che ck them one by one depending on the following DTC inspec-
tion priority chart.
Lane Departure Prevention (LDP) Low-pitched
toneLane departure warning lamp Cancel
Blind Spot Warning (BSW) — BSW warning lamp Cancel System Buzzer Warning lamp/Indicator lamp Description
Priority Detected items (DTC)
1 U1507: LOST COMM (SIDE RDR R)
U1508: LOST COMM (SIDE RDR L)
2 U1000: CAN COMM CIRCUIT
U1010: CONTROL UNIT (CAN)
3 C1B00: CAMERA UNIT MALF
C1F02: APA C/U MALF
C1A17: ICC SENSOR MALF
C1B53: SIDE RDR R MALF
C1B54: SIDE RDR L MALF
Revision: 2010 May2011 QX56
