ELECTRICALLY-CONTROLLED COOLING FAN COUPLINGEC-497
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
6.CHECK CAN COMMUNICATION
Refer to LAN-18, "
Trouble Diagnosis Flow Chart".
Is inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Repair or Replace error-detected parts.
7.CHECK COOLING FAN SPEED SENSOR
Refer to EC-367, "
Diagnosis Procedure".
Is inspection result normal?
YES >> Replace electrically-controlled cooling fan coupling. Refer to CO-16, "Removal and Installation".
NO >> Repair or replace error-detected parts.
Revision: 2010 May2011 QX56
Page 2522 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-498
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
FUEL INJECTOR
FUEL INJECTOR
Component Function CheckINFOID:0000000006218002
1.INSPECTION START
Turn ignition switch to START.
Are any cylinders ignited?
YES > INFINITI QX56 2011 Factory Service Manual
EC-498
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
FUEL INJECTOR
FUEL INJECTOR
Component Function CheckINFOID:0000000006218002
1.INSPECTION START
Turn ignition switch to START.
Are any cylinders ignited?
YES >](/manual-img/42/57033/w960_57033-2521.png)
EC-498
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
FUEL INJECTOR
FUEL INJECTOR
Component Function CheckINFOID:0000000006218002
1.INSPECTION START
Turn ignition switch to START.
Are any cylinders ignited?
YES >> GO TO 2.
NO >> Proceed to EC-498, "
Diagnosis Procedure".
2.CHECK FUEL INJECTOR FUNCTION
WITH CONSULT-III
1. Start engine.
2. Perform “POWER BALANCE” in “A CTIVE TEST” mode with CONSULT-III.
3. Check that each circuit produces a momentary engine speed drop.
WITHOUT CONSULT-III
1. Start engine.
2. Listen to each fuel injector operating sound.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-498, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006218003
1.CHECK FUEL INJECTOR POWER SUPPLY
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform the trouble diagnosis for power supply circuit. Refer to EC-168, "
Diagnosis Procedure".
2.CHECK FUEL INJECTOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector and ECM harness connector.
3. Check the continuity between fuel inje ctor harness connector and ECM harness connector.
Clicking sound should be heard.
PBIB3332E
+
−Voltag e
ECM
Connector Terminal
F 111 46
Ground Battery voltage
51
E80 111
11 2
Revision: 2010 May2011 QX56
Page 2523 of 5598
![INFINITI QX56 2011 Factory Service Manual
FUEL INJECTOREC-499
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> R INFINITI QX56 2011 Factory Service Manual
FUEL INJECTOREC-499
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> R](/manual-img/42/57033/w960_57033-2522.png)
FUEL INJECTOREC-499
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK ECM GROUND CIRCUIT
Check the continuity between ECM harness connector and ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK FUEL INJECTOR
Refer to EC-499, "
Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Replace malfunctioning fuel injector. Refer to EM-49, "
Removal and Installation".
Component InspectionINFOID:0000000006218004
1.CHECK FUEL INJECTOR
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Check the resistance between fuel injector terminals as per the following.
Cylinder +
−
Continuity
Fuel injector ECM
Connector Terminal Connector Terminal
1F123 1
F110 101
Existed
2108
2F124 1
F 111 7
24
3F125 1
F 111 6
23
4F126 1
F110 107
2104
5F127 1
F 111 2
29
6F128 1
F110 102
2109
7F129 1
F110 106
2103
8F130 1
F 111 1
28
+ −Continuity
ECM
Connector Terminal F 111 5 Ground Exsisted
E80 11 4
11 5
Revision: 2010 May2011 QX56
Page 2524 of 5598
EC-500
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
FUEL INJECTOR
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace malfunctioning fuel injector. Refer to
EM-49, "
Removal and Installation".
Injector
Condition Resistance
+ −
Te r m i n a l
1 2 Temperature 10 - 60 °C (50 - 140 °F) 1.44 - 1.73 Ω
Revision: 2010 May2011 QX56
Page 2525 of 5598
![INFINITI QX56 2011 Factory Service Manual
HIGH PRESSURE FUEL PUMPEC-501
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
HIGH PRESSURE FUEL PUMP
Component Function CheckINFOID:0000000006218005
1.CHECK HIGH PRESSURE FUEL PUM INFINITI QX56 2011 Factory Service Manual
HIGH PRESSURE FUEL PUMPEC-501
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
HIGH PRESSURE FUEL PUMP
Component Function CheckINFOID:0000000006218005
1.CHECK HIGH PRESSURE FUEL PUM](/manual-img/42/57033/w960_57033-2524.png)
HIGH PRESSURE FUEL PUMPEC-501
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
HIGH PRESSURE FUEL PUMP
Component Function CheckINFOID:0000000006218005
1.CHECK HIGH PRESSURE FUEL PUMP FUNCTION
WITH CONSULT-III
1. Start engine.
2. Check “FUEL PRES SEN V” in “D ATA MONITOR” mode with CONSULT-III.
WITHOUT CONSULT-III
1. Start engine.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-501, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006218006
1.CHECK HIGH PRESSURE FUEL PUMP SOLENOID CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector and high pressure fuel pump harness connector.
3. Check the continuity between ECM harness connector and high pressure fuel pump harness connector.
Monitor Item Condition Values/Status
FUEL PRES SEN V Engine speed: Idle 980 – 1,200 mV
Engine speed: Revving engine from idle to 4,000 rpm
quickly
1,100 – 2,900 mV
ECM
Condition Voltage
+ −
Connector Terminal Connector Terminal
F110 105 E80 175 [Engine is running]
Warm-up condition
Idle speed
NOTE:
The pulse cycle changes depending
on rpm at idle BATTERY VOLTAGE
(11 - 14 V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14 V)
JPBIA3340ZZ
JPBIA3341ZZ
+
−
Continuity
ECM High pressure fuel pump
Connector Terminal Connector Terminal
F110 105
F24 1
Existed
11 0 2
Revision: 2010 May2011 QX56
Page 2526 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-502
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
HIGH PRESSURE FUEL PUMP
4. Also check harness for short to ground and to power.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace error-det INFINITI QX56 2011 Factory Service Manual
EC-502
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
HIGH PRESSURE FUEL PUMP
4. Also check harness for short to ground and to power.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace error-det](/manual-img/42/57033/w960_57033-2525.png)
EC-502
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
HIGH PRESSURE FUEL PUMP
4. Also check harness for short to ground and to power.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace error-detected parts.
2.CHECK HIGH PRESSURE
FUEL PUMP SOLENOID
Refer to EC-502, "
Component Inspection".
Is inspection result normal?
YES >> GO TO 3.
NO >> Replace high pressure fuel pump. Refer to EM-43, "
Removal and Installation".
3.CHECK HIGH PRESSURE FUEL PUMP INSTALLATION CONDITION
1. Turn ignition switch OFF.
2. Check that the high pressure fuel pump is installed with no backlash and looseness.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK CAMSHAFT
1. Remove camshaft. Refer to EM-75, "
Removal and Installation".
2. Check camshaft. Refer to EM-77, "
Inspection".
Is inspection result normal?
YES >> INSPECTION END
NO >> Replace camshaft. Refer to EM-75, "
Removal and Installation".
Component InspectionINFOID:0000000006218007
1.CHECK HIGH PRESSURE FUEL PUMP SOLENOID
1. Turn ignition switch OFF.
2. Disconnect high pressure fuel pump harness connector.
3. Check the resistance between high pressure fuel pump connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace high pressure fuel pump. Refer to EM-43, "
Removal and Installation".
+−
Condition Resistance
High pressure fuel pump
Te r m i n a l
1 2 Temperature 20 – 30 °C (68 – 86 °F) 9 – 11 Ω
Revision: 2010 May2011 QX56
Page 2527 of 5598
![INFINITI QX56 2011 Factory Service Manual
ICC BRAKE SWITCHEC-503
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ICC BRAKE SWITCH
Component Function CheckINFOID:0000000006218008
1.CHECK ICC BRAKE SWITCH FUNCTION
WITH CONS INFINITI QX56 2011 Factory Service Manual
ICC BRAKE SWITCHEC-503
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ICC BRAKE SWITCH
Component Function CheckINFOID:0000000006218008
1.CHECK ICC BRAKE SWITCH FUNCTION
WITH CONS](/manual-img/42/57033/w960_57033-2526.png)
ICC BRAKE SWITCHEC-503
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ICC BRAKE SWITCH
Component Function CheckINFOID:0000000006218008
1.CHECK ICC BRAKE SWITCH FUNCTION
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DATA MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
WITHOUT CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-503, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006218009
1.CHECK DTC WITH ADAS CONTROL UNIT
Refer to DAS-21, "
CONSULT-III Function (ICC/ADAS)" and DAS-38, "DTC Index".
Are any DTCs detected?
YES >> Perform the Diagnosis Procedur e corresponding to the detected DTC.
NO >> GO TO 2.
2.CHECK OVERALL FUNCTION
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “BRAKE SW1” in “DATA MONITOR” mode with CONSULT-III.
3. Check “BRAKE SW1” indication under the following conditions.
WITHOUT CONSULT-III
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector terminals under the following conditions.
Monitor item Condition Indication
BRAKE SW1
(ICC brake switch) Brake pedalSlightly depressed OFF
Fully released ON
ECM
Condition Voltage
Connector +–
Terminal Terminal
E80 147
(ICC brake switch signal) 175 Brake pedalSlightly depressed Approx. 0 V
Fully released Battery voltage
Monitor item Condition Indication
BRAKE SW1
(ICC brake switch) Brake pedalSlightly depressed OFF
Fully released ON
Revision: 2010 May2011 QX56
Page 2528 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-504
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ICC BRAKE SWITCH
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT-I
1. Turn ignition switch INFINITI QX56 2011 Factory Service Manual
EC-504
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ICC BRAKE SWITCH
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT-I
1. Turn ignition switch](/manual-img/42/57033/w960_57033-2527.png)
EC-504
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
ICC BRAKE SWITCH
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF.
2. Disconnect ICC brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ICC brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 4.
4.CHECK ICC BRAKE SWITCH POWER SUPPLY CIRCUIT-II
Check the voltage between ICC brake switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
Fuse block (J/B) connector E103
10 A fuse (No. 3)
Harness for open or short between ICC brake switch and fuse
>> Repair open circuit or short to ground in harness or connectors.
6.CHECK ICC BRAKE SWITCH
Refer to EC-445, "
Component Inspection (ICC Brake Switch)".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace ICC brake switch. Refer to BR-20, "
Removal and Installation".
7.CHECK ICC BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ICC brake s witch harness connector and ECM harness connector.
ECM
Condition Voltage (V)
Connector +–
Te r m i n a l Te r m i n a l
E80 147
(ICC brake switch signal) 175 Brake pedalSlightly depressed Approx. 0
Fully released Battery voltage
ICC brake switch
Ground Voltage
Connector Terminal
E68 2 Ground Battery voltage
ICC brake switch Ground Voltage
Connector Terminal
E68 1 Ground Battery voltage
Revision: 2010 May2011 QX56
