Page 2105 of 5598

INFINITI QX56 2011 Factory Service Manual ECM EC-81 < ECU DIAGNOSIS INFORMATION > [VK56VD] C D E F G H I J K L M A EC NP O 23 (V) 45 (L/O) Low fuel pressure sensor Input [Engine is running]  Warm-up condition  Idle speed 2.4 - 3.6 V [Engin

Page 2106 of 5598

INFINITI QX56 2011 Factory Service Manual EC-82 < ECU DIAGNOSIS INFORMATION >[VK56VD] ECM 37 (V) 175 (B) Cooling fan speed Input [Ignition switch: ON]  Engine stopped 5 V [Engine is running]  Idle speed  After warm-up condition BATTERY VO

Page 2107 of 5598

INFINITI QX56 2011 Factory Service Manual ECM EC-83 < ECU DIAGNOSIS INFORMATION > [VK56VD] C D E F G H I J K L M A EC NP O 48 (L/W) 175 (B) A/F sensor 1 heater (bank 1) Input [Engine is running]  Warm-up condition  Idle speed (More than 14

Page 2108 of 5598

INFINITI QX56 2011 Factory Service Manual EC-84 < ECU DIAGNOSIS INFORMATION >[VK56VD] ECM 54 (G/R) 175 (B) Intake valve timing control sole- noid valve (bank 2) Output[Engine is running]  Warm-up condition  Idle speed BATTERY VOLTAGE (11 -

Page 2109 of 5598

INFINITI QX56 2011 Factory Service Manual ECM EC-85 < ECU DIAGNOSIS INFORMATION > [VK56VD] C D E F G H I J K L M A EC NP O 64 (V/W) 175 (B) EVAP canister purge volume control solenoid valve Output[Engine is running]  Idle speed  Accelerat

Page 2110 of 5598

INFINITI QX56 2011 Factory Service Manual EC-86 < ECU DIAGNOSIS INFORMATION >[VK56VD] ECM 78 (L/R) 175 (B) A/F sensor 1 (bank 2) Input [Engine is running]  Warm-up condition  Engine speed: 2,000 rpm2.2 - 2.8V Output voltage varies with air

Page 2111 of 5598

INFINITI QX56 2011 Factory Service Manual ECM EC-87 < ECU DIAGNOSIS INFORMATION > [VK56VD] C D E F G H I J K L M A EC NP O 91 (R) 97 (W) Throttle position sensor 1 Input [Ignition switch: ON]  Engine: Stopped  Selector lever: D position

Page 2112 of 5598

INFINITI QX56 2011 Factory Service Manual EC-88 < ECU DIAGNOSIS INFORMATION >[VK56VD] ECM 101 (R) 102 (R) 175 (B) Fuel injector No. 1 (HI) Fuel injector No. 6 (HI) Input[Engine is running]  Warm-up condition  Idle speed NOTE: The pulse cyc
