P0327, P0328, P0332, P0333 KS
EC-297
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0327, P0328, P0332, P0333 KS
DTC LogicINFOID:0000000006217842
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confi rm that battery voltage is 10 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and run it for at least 5 seconds at idle speed.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-297, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217843
1.CHECK KNOCK SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Disconnect knock sensor harness connector and ECM harness connector.
2. Check the continuity between knock sens or harness connector and ECM harness connector.
3. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detected condition Possible cause
P0327 KNOCK SEN/CIRC-B1
[Knock sensor (bank 1) circuit
low input] An excessively low voltage from the sensor
is sent to ECM.
Harness or connectors(The knock sensor circuit is open or
shorted.)
Knock sensor
P0328
KNOCK SEN/CIRC-B1
[Knock sensor (bank 1) circuit
high input] An excessively high voltage from the sensor
is sent to ECM.
P0332 KNOCK SEN/CIRC-B2
[Knock sensor (bank 2) circuit
low input] An excessively low voltage from the sensor
is sent to ECM.
P0333 KNOCK SEN/CIRC-B2
[Knock sensor (bank 2) circuit
high input] An excessively high voltage from the sensor
is sent to ECM.
DTC
Knock sensor ECM
Continuity
Bank Connector Terminal Connector Terminal
P0327, P0328 1 F203 2 F111 35 Existed
P0332, P0333 2 F204 2
Revision: 2010 May2011 QX56
Page 2322 of 5598
![INFINITI QX56 2011 Factory Service Manual
EC-298
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0327, P0328,
P0332, P0333 KS
Harness for open or short between knock sensor and ECM
Loose or poor connection for each connector and harness
>> Repair op INFINITI QX56 2011 Factory Service Manual
EC-298
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0327, P0328,
P0332, P0333 KS
Harness for open or short between knock sensor and ECM
Loose or poor connection for each connector and harness
>> Repair op](/manual-img/42/57033/w960_57033-2321.png)
EC-298
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0327, P0328,
P0332, P0333 KS
Harness for open or short between knock sensor and ECM
Loose or poor connection for each connector and harness
>> Repair open circuit or short to power in harness or connectors.
3.CHECK KNOCK SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between knock sens or harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and knock sensor
Loose or poor connection for each connector and harness
>> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK KNOCK SENSOR
Refer to EC-298, "
Component Inspection (Knock Sensor)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace malfunctioning knock sensor. Refer to EM-106, "
Exploded View".
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (Knock Sensor)INFOID:0000000006217844
1.CHECK KNOCK SENSOR
1. Turn ignition switch OFF.
2. Disconnect knock sensor harness connector.
3. Check resistance between knock sensor terminals as per the following. NOTE:
It is necessary to use an ohmmeter which can measure more than 10 MΩ.
CAUTION:
Never use any knock sensors that have been dropp ed or physically damaged. Use only new ones.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace malfunctioning knock sensor. Refer to EM-106, "
Exploded View".
DTCKnock sensor ECM
Continuity
Bank Connector Terminal Connector Terminal
P0327, P0328 1 F203 1 F 11129
Existed
P0332, P0333 2 F204 1 33
Terminals Resistance
1 and 2 Approx. 532 - 588 k Ω [at 20 °C (68 °F)]
Revision: 2010 May2011 QX56
