Page 2505 of 5598

INFINITI QX56 2011 Factory Service Manual
P2138 APP SENSOREC-481
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 1

Page 2506 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-482
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2138 APP SENSOR
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ACCELERATOR PEDAL ASSEMBLY
Replace accelerator pedal assembly. Refer to ACC-3, "
MODELS WITHO

Page 2507 of 5598

INFINITI QX56 2011 Factory Service Manual
P2539, P2541, P2542 LOW FUEL PRESSURE SENSOR
EC-483
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2539, P2541, P2542 LOW
FUEL PRESSURE SENSOR
DTC LogicINFOID:0000000006288355
D

P2539, P2541, P2542 LOW FUEL PRESSURE SENSOR
EC-483
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2539, P2541, P2542 LOW
FUEL PRESSURE SENSOR
DTC LogicINFOID:0000000006288355
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 60 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-483, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288356
1.CHECK LOW FUEL PRESSURE SENSOR POWER SUPPLY-I
1. Turn ignition switch OFF.
2. Disconnect low fuel pressure sensor connector.
3. Turn ignition switch ON.
4. Check the voltage between low fuel pressure sensor harness connector terminals.
Inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK LOW FUEL PRESSURE SENSOR POWER SUPPLY-II
Check the voltage between low fuel pressure sensor harness connector and the ground.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2539 LOW FUEL PRES SEN
(Low fuel pressure sensor
circuit low input and high in-
put) Signal voltage from the low fuel pressure
sensor remains at more than 4.84 V / less
than 0.3 V for 5 seconds or more. Harness or connectors
(Low fuel pressure sensor circuit is open
or shorted.)
(Power steering pressure sensor circuit is
open or shorted.)
(Cooling fan speed sensor circuit is open
or shorted.)
(FRP sensor circuit is open or shorted.)
Low fuel pressure sensor
Power steering pressure sensor
Cooling fan speed sensor
FRP sensor
P2541
LOW FUEL PRES SEN
(Low fuel pressure sensor
circuit low input) Signal voltage from the low fuel pressure
sensor remains at less than 0.49 V for 5 sec-
onds or more.
P2542 LOW FUEL PRES SEN
(Low fuel pressure sensor
circuit high input) Signal voltage from the low fuel pressure
sensor remains at more than 4.1 V for 5 sec-
onds or more.
Low fuel pressure sensor
Vo l ta g e
(Approx.)
Connector +
−
terminal
F25 3 1 5 V
Revision: 2010 May2011 QX56

Page 2508 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-484
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2539, P2541, P2542 LOW
FUEL PRESSURE SENSOR
Is inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition

Page 2509 of 5598

INFINITI QX56 2011 Factory Service Manual
P2539, P2541, P2542 LOW FUEL PRESSURE SENSOR
EC-485
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
NO >> Repair or replace error-detected parts.
6.CHECK LOW FUEL PRESSURE SENSOR S

Page 2510 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-486
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2539, P2541, P2542 LOW
FUEL PRESSURE SENSOR
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Replace low fuel pressure sensor. Refer to EM-43

Page 2511 of 5598

INFINITI QX56 2011 Factory Service Manual
P2A00, P2A03 A/F SENSOR 1EC-487
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2A00, P2A03 A/F SENSOR 1
DTC LogicINFOID:0000000006217987
DTC DETECTION LOGIC
To judge the malfunct

P2A00, P2A03 A/F SENSOR 1EC-487
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P2A00, P2A03 A/F SENSOR 1
DTC LogicINFOID:0000000006217987
DTC DETECTION LOGIC
To judge the malfunction, the A/F signal computed by ECM fr
om the A/F sensor 1 signal is monitored so it will
not shift to LEAN side or RICH side.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Clear the mixture ratio self-learning value. Refer to EC-152, "
Work Procedure".
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Start engine and keep the engine speed between 3,500 and 4,000 rpm for 1 minute under no load.
6. Let engine idle for 1 minute.
7. Keep engine speed between 2,500 and 3,000 rpm for 20 minutes.
8. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-487, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217988
1.RETIGHTEN A/F SENSOR 1
Loosen and retighten the A/F sensor 1. Refer to EX-5, "
Exploded View".
>> GO TO 2.
2.CHECK A/F SENSOR 1 CONNECTOR
1. Disconnect A/F sensor 1 harness connector.
2. Check that water is not inside connectors.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness connector.
3.CHECK FOR INTAKE AIR LEAKAGE
1. Reconnect A/F sensor 1 harness connector.
2. Start engine and run it at idle.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P2A00 A/F SENSOR1 (B1)
(Air fuel ratio (A/F) sensor 1 (bank 1)
circuit range/performance) The output voltage computed by ECM from
the A/F sensor 1 signal shifts to the lean side
for a specified period.
The A/F signal computed by ECM from the
A/F sensor 1 signal shifts to the rich side for
a specified period. A/F sensor 1
A/F sensor 1 heater
Fuel pressure
Fuel injector
Intake air leaks
P2A03 A/F SENSOR1 (B2)
(Air fuel ratio (A/F) sensor 1 (bank 2)
circuit range/performance)
Revision: 2010 May2011 QX56

Page 2512 of 5598

INFINITI QX56 2011 Factory Service Manual
EC-488
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2A00, P2A03 A/F SENSOR 1
3. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
YES >> Repair or replace malfunc

EC-488
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P2A00, P2A03 A/F SENSOR 1
3. Listen for an intake air leakage after the mass air flow sensor.
Is intake air leakage detected?
YES >> Repair or replace malfunctioning part.
NO >> GO TO 4.
4.CLEAR THE MIXTURE RATIO SELF-LEARNING VALUE
1. Clear the mixture ratio self-learning value. Refer to EC-152, "
Work Procedure".
2. Run engine for at least 10 minutes at idle speed.
Is the 1st trip DTC P0171, P0172, P0174 or P 0175 detected? Is it difficult to start engine?
YES >> Perform trouble diagnosis for DTC P0171, P0174 or P0172, P0175. Refer to EC-264, "Diagnosis
Procedure" or EC-268, "Diagnosis Procedure".
NO >> GO TO 5.
5.CHECK AIR FUEL RATIO SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect air fuel ratio (A/F) sensor 1 harness connector.
2. Turn ignition switch ON.
3. Check the voltage between A/F sensor 1 harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHECK A/F SENSOR 1 INPUT SIGN AL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between A/F sensor 1 harness connector and ECM harness connector.
4. Check the continuity between A/F sensor 1 harness connector and ground, or ECM harness connector
and ground.
5. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
7.CHECK A/F SENSOR 1 GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between A/F sensor 1 harness connector and ECM harness connector.
DTCA/F sensor 1
Ground Voltage
Bank Connector Terminal
P2A00 1 F67 4 Ground 3.0 V
P2A03 2 F68 4
DTC A/F sensor 1 ECM
Continuity
Bank Connector Terminal Connector Terminal
P2A00 1 F67 3 F11088
Existed
P2A03 2 F68 3 78
DTC A/F sensor 1 ECM
Ground Continuity
Bank Connector Terminal Connector Terminal
P2A00 1 F67 3 F11088
Ground Not existed
P2A03 2 F68 3 78
Revision: 2010 May2011 QX56
