2011 INFINITI QX56 Factory Service Manual

buttons seat memory dimensions CD player instrument cluster reset sun roof

Page 3145 of 5598

INFINITI QX56 2011 Factory Service Manual
DIAGNOSIS SYSTEM (HVAC)HAC-39
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
DIAGNOSIS SYSTEM (HVAC)
DescriptionINFOID:0000000006275884
Air conditioning system

DIAGNOSIS SYSTEM (HVAC)HAC-39
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
DIAGNOSIS SYSTEM (HVAC)
DescriptionINFOID:0000000006275884
Air conditioning system performs self-diagnosis, operat ion check, function diagnosis, and various settings
using diagnosis function of each control unit.
CONSULT-III FunctionINFOID:0000000006275885
CONSULT-III performs the following functions via CAN communication with A/C auto amp.
NOTE:
Diagnosis should be performed with engine running. D oor motor operation speeds become slower and NO
results may be returned even for normal operation if battery voltage drops below 12 V during self-diagnosis.
SELF-DIAGNOSIS RESULTS
Refer to HAC-45, "DTC Index".
DATA MONITOR
Display item list
ECU Diagnostic item
(CONSULT-III)
A/C auto amp. HVACSelf Diagnostic Result
Data Monitor
Active Test
Work support
AV c o n t r o l u n i t MULTI AV
Self Diagnostic Result
Multi AV system on board diagnosis function
ECM ENGINESelf Diagnostic Result
Data Monitor
IPDM E/R IPDM E/RSelf Diagnostic Result
Data Monitor
Auto active test
Diagnostic mode Description
Self diagnostic result Displays the diagnosis results judged by A/C auto amp.
Data monitor Displays the input/output signal of A/C auto amp.
Active test The signals used to activate each device are forcibly supplied from A/C auto amp.
Work support Changes the setting for each setting function.
ECU identification Displays the part number of A/C auto amp.
Monitor item [Unit] Description
AMB TEMP SEN [ °C ( °F)] Ambient sensor value converted from ambient sensor signal received from ambient sen-
sor
IN-VEH TEMP [ °C ( °F)] Front in-vehicle sensor value converted from front in-vehicle sensor signal received from
front in-vehicle sensor
INT TEMP SEN [ °C ( °F)] Intake sensor value converted from intake sensor signal received from intake sensor
SUNLOAD SEN [w/m
2]Sunload sensor value converted from sunload sensor signal (driver side) received from
sunload sensor
AMB SEN CAL [ °C ( °F)] Ambient temperature value calculated by A/C auto amp.
IN-VEH CAL [ °C ( °F)] In-vehicle temperature (front side) value calculated by A/C auto amp.
INT TEMP CAL [ °C ( °F)] Front evaporator fin temperature value calculated by A/C auto amp.
SUNL SEN CAL [w/m
2]Sunload value (driver side) calculated by A/C auto amp.
Revision: 2010 May2011 QX56

Page 3146 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-40
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
DIAGNOSIS SYSTEM (HVAC)
ACTIVE TEST
Check each output device
COMP REQ SIG [On/Off] Displays A/C switch ON/OFF status transmitted to other uni

HAC-40
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
DIAGNOSIS SYSTEM (HVAC)
ACTIVE TEST
Check each output device
COMP REQ SIG [On/Off] Displays A/C switch ON/OFF status transmitted to other units via CAN communication
FAN REQ SIG [On/Off]Displays front blower motor ON/OFF status transmitted to other units via CAN commu-
nication
FAN DUTY Duty ratio of front blower motor judged by A/C auto amp.
XM Target discharge front air temperature (driver side) judged by A/C auto amp. depending
on the temperature setting and the value from each sensor
PASS SUNL CAL [w/m
2]Sunload value (passenger side) calculated by A/C auto amp.
PASS SUNLOAD SEN [w/m
2]Sunload sensor value converted from sunload sensor signal (passenger side) received
from sunload sensor
PA TARGET A/TEMP Target discharge front air temperature (passenger side) judged by A/C auto amp. de-
pending on the temperature setting and the value from each sensor
RRIN TEMP SEN [ °C ( °F)] Rear in-vehicle sensor value converted from rear in-vehicle sensor signal received from
rear in-vehicle sensor.
RRIN TEMP CAL [ °C ( °F)] In-vehicle temperature (rear side) value calculated by A/C auto amp.
RR INT TMP CL [ °C ( °F)] Rear evaporator fin temperature value calculated by A/C auto amp.
RRFAN REQ SIG [On/Off] Displays rear blower motor ON/OFF status transmitted to other units via CAN communi-
cation
RR FAN DUTY Duty ratio of rear blower motor judged by A/C auto amp.
RR XM Target discharge rear air temperature (driver side) judged by A/C auto amp. depending
on the temperature setting and the value from each sensor
ENG COOL TEMP [ °C ( °F)] Engine coolant temperature signal value received from ECM via CAN communication
VEHICLE SPEED [km/h
(mph)] Vehicle speed signal value received from combination meter via CAN communication
Monitor item [Unit] Description
Te s t i t e m D e s c r i p t i o n
HVAC TEST The operation check of air conditioning system can be performed by selecting the mode.
Refer to the following table for the conditions of each mode.
Te s t i t e m
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7
Front mode door motor posi-
tion VENT VENT B/L B/L FOOT D/F DEF
Intake door motor position REC REC 20% FRE 20% FRE FRE FRE FRE
Front air mix door motor (driver
side) position FULL COLD FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT
Front air mix door motor (pas-
senger side) position FULL COLD FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT
Front blower motor control sig-
nal duty ratio 35% 35% 59% 59% 89% 89% 35%
Magnet clutch ON ON ON ON OFF OFF ON
Upper ventilator door motor
position OPEN CLOSE OPEN CLOSE CLOSE CLOSE CLOSE
Rear mode door motor posi-
tion VENT VENT B/L B/L FOOT FOOT FOOT
Rear air mix door motor posi-
tion FULL COLD FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT
Rear blower motor control sig-
nal duty ratio 35% 35% 59% 59% 89% 89% 35%
Revision: 2010 May2011 QX56

Page 3147 of 5598

INFINITI QX56 2011 Factory Service Manual
DIAGNOSIS SYSTEM (HVAC)HAC-41
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
*: With ACCS (advanced climate control system)
NOTE:
Perform the inspection of each

DIAGNOSIS SYSTEM (HVAC)HAC-41
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
*: With ACCS (advanced climate control system)
NOTE:
Perform the inspection of each output device after starting the engine because the compressor is operated.
WORK SUPPORT
*: With ACCS (advanced climate control system)
NOTE:
When the battery cable is disconnected from the negative terminal or when the battery voltage becomes 10 V
or less, the setting of WORK SUPPORT may be cancelled.
Rear A/C relay ON ON ON ON OFF OFF ON
Ionizer
*ON ON ON ON ON ON OFF
Front display (Ion mode)
*CLEAN CLEAN QUICK
CLEAN QUICK
CLEAN QUICK
CLEAN QUICK
CLEAN OFF
Te s t i t e m
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7
Work item Description Refer to
TEMP SET CORRECT Setting change of temperature setting trimmer (front) can be per-
formed. HAC-68, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM :
Temperature Setting Trim-
mer (Front)"
BLOWER SET Setting change of foot position setting trimmer can be performed.
HAC-68, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM : Foot
Position Setting Trimmer"
REC MEMORY SET
Setting change of inlet port memory function (REC) can be per-
formed. HAC-69, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM : Inlet Port
Memory Function (REC)"
FRE MEMORY SET
Setting change of inlet port memory function (FRE) can be per-
formed. HAC-69, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM : Inlet Port
Memory Function (FRE)"
GAS SENSOR ADJUSTMENT*Setting change of exhaust gas / outside odor detecting sensor sensi-
tivity adjustment function can be performed. HAC-70, "
ACCS (AD-
VANCED CLIMATE CON-
TROL SYSTEM) :
Exhaust Gas / Outside
Odor Detecting Sensor
Sensitivity Adjustment
Function"
CLEAN SW SET*Setting change of auto intake switch interlocking movement change
function can be performed.
HAC-70, "
ACCS (AD-
VANCED CLIMATE CON-
TROL SYSTEM) : Auto
Intake Switch Interlocking
Movement Change Func-
tion"
REAR TEMP SET CORRECT
Setting change of temperature setting trimmer (rear) can be per-
formed. HAC-68, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM :
Temperature Setting Trim-
mer (Front)"
Revision: 2010 May2011 QX56

Page 3148 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-42
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
ECU DIAGNOSIS INFORMATION
A/C AUTO AMP.
Reference ValueINFOID:0000000006275886
CONSULT-III DATA MONITOR REFERENCE VALUES

HAC-42
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
ECU DIAGNOSIS INFORMATION
A/C AUTO AMP.
Reference ValueINFOID:0000000006275886
CONSULT-III DATA MONITOR REFERENCE VALUES
Monitor item Condition Value/Status
AMB TEMP SEN Ignition switch ON — Equivalent to ambient tem-
perature
IN-VEH TEMP Ignition switch ON — Equivalent to in-vehicle tem-
perature (front side)
INT TEMP SEN Ignition switch ON — Equivalent to front evapora-
tor fin temperature
SUNLOAD SEN Ignition switch ON — Equivalent to sunload (driver
side)
AMB SEN CAL Ignition switch ON — Equivalent to ambient tem-
perature
IN-VEH CAL Ignition switch ON — Equivalent to in-vehicle tem-
perature (front side)
INT TEMP CAL Ignition switch ON — Equivalent to front evapora-
tor fin temperature
SUNL SEN CAL Ignition switch ON — Equivalent to sunload (driver
side)
COMP REQ SIG Engine: Run at idle after
warming up A/C switch: ON
(Compressor operation sta-
tus)
On
A/C switch: OFF Off
FAN REQ SIG Engine: Run at idle after
warming up Front blower motor: ON On
Front blower motor: OFF Off
FAN DUTY Engine: Run at idle after
warming up Front blower motor: ON 25 – 81
Front blower motor: OFF 0
XM Ignition switch ON — Value according to target air
flow temperature (driver
side)
PASS SUNL CAL Ignition switch ON — Equivalent to sunload (pas-
senger side)
PASS SUNLOAD SEN Ignition switch ON — Equivalent to sunload (pas-
senger side)
PA TARGET A/TEMP Ignition switch ON — Value according to target air
flow temperature (passen-
ger side)
RRIN TEMP SEN Ignition switch ON — Equivalent to in-vehicle tem-
perature (rear side)
RRIN TEMP CAL Ignition switch ON — Equivalent to in-vehicle tem-
perature (rear side)
RR INT TMP CL Ignition switch ON — Equivalent to rear evapora-
tor fin temperature
RRFAN REQ SIG Engine: Run at idle after
warming up Rear blower motor: ON On
Rear blower motor: OFF Off
RR FAN DUTY Engine: Run at idle after
warming up Rear blower motor: ON 25 – 81
Rear blower motor: OFF 0
Revision: 2010 May2011 QX56

Page 3149 of 5598

INFINITI QX56 2011 Factory Service Manual
A/C AUTO AMP.HAC-43
< ECU DIAGNOSIS INFORMATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
TERMINAL LAYOUT
PHYSICAL VALUES
RR XM Ignition switch ON — Value according to target

Page 3150 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-44
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
11
(W) GroundCommunication signal
(A/C auto amp.
→Rear A/C
control) Output Ignition switch ON
14
(O/L) GroundFront bl

Page 3151 of 5598

INFINITI QX56 2011 Factory Service Manual
A/C AUTO AMP.HAC-45
< ECU DIAGNOSIS INFORMATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
*1: With ACCS (advanced climate control system)
*2: A/C auto amp. is not used for con

Page 3152 of 5598

INFINITI QX56 2011 Factory Service Manual
HAC-46
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
*1: With ACCS (advanced climate control system)
*2: Perform self-diagnosis under sunshine. When performi
ng indoors, aim

HAC-46
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
*1: With ACCS (advanced climate control system)
*2: Perform self-diagnosis under sunshine. When performi
ng indoors, aim a light (more than 60 W) at sunload
sensor, otherwise self-diagnosis indicates even though the sunload sensor is functioning normally.
NOTE:
If all of door motor DTCs (B2632, B2633, B2634, B2635, B2636, B2637, B2638, B2639, B263D, B263E,
B263F, B2654, B2655, B2661, B2662, B2663, B2664, B 2665, B2666, B2669, and B266A) are detected, check
door motor communication circuit. Refer to HAC-120, "
Diagnosis Procedure".
B262A*1GAS SENSOR HAC-83, "DTC Logic"
B262B*1GAS SENSORHAC-83, "DTC Logic"
B2630*2SUNLOAD SENSORHAC-86, "DTC Logic"
B2631*2SUNLOAD SENSORHAC-86, "DTC Logic"
B2632 DR AIRMIX DOOR MOT HAC-89, "DTC Logic"
B2633 DR AIRMIX DOOR MOTHAC-89, "DTC Logic"
B2634 PASS AIR MIX DOOR MOTHAC-91, "DTC Logic"
B2635 PASS AIR MIX DOOR MOTHAC-91, "DTC Logic"
B2636 DR VENT DOOR FAILHAC-93, "DTC Logic"
B2637 DR B/L DOOR FAILHAC-93, "DTC Logic"
B2638 DR D/F1 DOOR FAILHAC-93, "DTC Logic"
B2639 DR DEF DOOR FAILHAC-93, "DTC Logic"
B263D FRE DOOR FAIL HAC-95, "DTC Logic"
B263E 20P FRE DOOR FAILHAC-95, "DTC Logic"
B263F REC DOOR FAILHAC-95, "DTC Logic"
B2654 D/F2 DOOR FAILHAC-93, "DTC Logic"
B2655 B/L2 DOOR FAILHAC-93, "DTC Logic"
B2657*1GAS SENSOR CIRCUITHAC-83, "DTC Logic"
B2658*1GAS SENSOR CIRCUITHAC-83, "DTC Logic"
B2661 UPPER VENT DOOR MOT HAC-97, "DTC Logic"
B2662 UPPER VENT DOOR MOTHAC-97, "DTC Logic"
B2663 UPPER VENT DOOR MOTHAC-97, "DTC Logic"
B2664 REAR AIR MIX DOOR MOTHAC-99, "DTC Logic"
B2665 REAR AIR MIX DOOR MOTHAC-99, "DTC Logic"
B2666 REAR MODE DOOR MOTHAC-101, "DTC Logic"
B2667*2PASS SUNLOAD SENSORHAC-103, "DTC Logic"
B2668*2PASS SUNLOAD SENSORHAC-103, "DTC Logic"
B2669 REAR MODE DOOR MOT HAC-101, "DTC Logic"
B266A REAR MODE DOOR MOT HAC-101, "DTC Logic"
B266B REAR IN-VEHICLE SENHAC-106, "DTC Logic"
B266C REAR IN-VEHICLE SEN HAC-106, "DTC Logic"
B27B0 A/C AUTO AMP.HAC-109, "DTC Logic"
DTCItems
(CONSULT-III screen terms) Reference
Revision: 2010 May2011 QX56

Load next 8 pages

Page: < prev 1-10 ... 3113-3120 3121-3128 3129-3136 3137-3144 3145-3152 3153-3160 3161-3168 3169-3176 3177-3184 ... 5600 next >

fog light coolant temperature audio sport mode transmission fluid brake fluid
