Page 441 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-53
< ECU DIAGNOSIS INFORMATION >
C
D E
F
G H
I
J
K L
B A
O P
N
90
(Y) Ground Push-button ignition
switch illumination OutputPush-button ig-
nition switch illu-
mination ON 12 V
OFF 0 V
9

Page 442 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-54
< ECU DIAGNOSIS INFORMATION >
BCM
*: For Canada
Fail-safeINFOID:0000000006274820
FAIL-SAFE CONTROL BY DTC
BCM performs fail-safe control when any DTC are detected.
102
(BR) Ground P/N position

BCS-54
< ECU DIAGNOSIS INFORMATION >
BCM
*: For Canada
Fail-safeINFOID:0000000006274820
FAIL-SAFE CONTROL BY DTC
BCM performs fail-safe control when any DTC are detected.
102
(BR) Ground P/N position Input Selector lever P or N position 12 V
Except P and N positions 0 V
104
(R/B) Ground A/T shift selector
(detention switch)
power supply Output Ignition switch ON 12 V
105
(O/L) Ground Stop lamp switch 2 Input Ignition switch OFF Battery voltage
106
(Y/G) Ground
Blower fan motor re-
lay control Output Ignition switch OFF or ACC 0 V
ON 12 V
107 (L) Ground
Steering lock condi-
tion No. 1 Input Steering lock LOCK status 0 V
UNLOCK status 12 V
108 (P) Ground
Steering lock condi-
tion No. 2 Input Steering lock LOCK status 12 V
UNLOCK status 0 V
109
(L/W) Ground ACC indicator lamp Output Ignition switch OFF (LOCK indicator is
not illuminated)
Battery voltage
ACC 0 V
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
Signal name Input/
Output
+ −
Display contents of CONSULT Fail-safe Cancellation
B2013: ID DISCORD BCM-S/ L Inhibit engine cranking When communication between BCM and steering lock unit are commu-
nicated normally.
B2014: CHAIN OF S/L-BCM Inhibit engine cranking When communication between BCM and steering lock unit are commu-
nicated normally.
B2192: ID DISCORD BCM-ECM Inhibit engine cranking Erase DTC
B2193: CHAIN OF BCM-ECM Inhibit engine cranking Erase DTC
B2195: ANTI-SCANNING Inhibit engine cranking Ignition switch ON → OFF
B2198: NATS ANTENNA AMP Inhibit engine cranking Erase DTC
B2557: VEHICLE SPEED In hibit steering lockWhen the following CAN signal status (vehicle speed signal) becomes
consistent
Vehicle speed signal (ABS)
Vehicle speed signal (Meter)
B2601: SHIFT POSITION Inhibit steering lock 500 ms after the following signal reception status becomes consistent
Selector lever P position switch signal
P range signal (CAN)
B2602: SHIFT POSITION Inhibit steering lock 5 seconds after the following BCM recognition conditions are fulfilled
Ignition switch is in the ON position
Selector lever P position switch signal: Except P position (battery volt-
age)
Vehicle speed: 4 km/h (2.5 MPH) or more
Revision: 2010 May2011 QX56

Page 443 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-55
< ECU DIAGNOSIS INFORMATION >
C
D E
F
G H
I
J
K L
B A
O P
N
B2603: SHIFT POSI STATUS Inhibit steering lock
500 ms after any of the following BCM recognition conditions are fulfilled
S

BCS
BCM
BCS-55
< ECU DIAGNOSIS INFORMATION >
C
D E
F
G H
I
J
K L
B A
O P
N
B2603: SHIFT POSI STATUS Inhibit steering lock
500 ms after any of the following BCM recognition conditions are fulfilled
Status 1
- Ignition switch is in the ON position
- Selector lever P position switch signal: Except P position (12 V)
- Selector lever P/N position signal: Except P and N positions (0 V)
Status 2
- Ignition switch is in the ON position
- Selector lever P position switch signal: P position (0 V)
- Selector lever P/N position signal: P or N positions (12 V)
B2604: PNP/CLUTCH SW Inhibit steering lock 500 ms after any of the following BCM recognition conditions are fulfilled
Status 1
- Ignition switch is in the ON position
- Selector lever P/N position signal: P or N position (12 V)
- Shift position signal (CAN): P or N position
Status 2
- Ignition switch is in the ON position
- Selector lever P/N position signal: Except P and N positions (0 V)
- Shift position signal (CAN): Except P and N position
B2605: PNP/CLUTCH SW Inhibit steering lock 500 ms after any of the following BCM recognition conditions are fulfilled
Status 1
- Power position: IGN
- Selector lever P/N position signal: Except P and N positions (0 V)
- Interlock/PNP switch signal (CAN): OFF
Status 2
- Ignition switch is in the ON position
- Selector lever P/N position signal: P or N position (12 V)
- Interlock/PNP switch signal (CAN): ON
B2608: STARTER RELAY Inhibit engine cranking 500 ms after the following signal communication status becomes con-
sistent
Starter motor re
lay control signal
Starter relay status signal (CAN)
B2609: S/L STATUS Inhibit engine crank-
ing
Inhibit steering lock When the following steering lock conditions agree
BCM steering lock control status
Steering lock condition No. 1 signal status
Steering lock condition No. 2 signal status
B260B: STEERING LOCK UNIT Inhibit steering lock Erase DTC
B260D: STEERING LOCK UNIT Inhibit steering lock Erase DTC
B260F: ENG STATE SIG LOST Inhibit engine cranking When any of the following conditions are fulfilled
Power position changes to ACC
Receives engine status signal (CAN)
B2612: S/L STATUS Inhibit engine crank-
ing
Inhibit steering lock When any of the following conditions are fulfilled
Steering lock unit status signal (CAN) is received normally
The BCM steering lock control status matches the steering lock status
recognized by the steering lock unit status signal (CAN from IPDM E/
R)
B2619: BCM Inhibit engine cranking 1 second after the steering lock unit power supply output control inside
BCM becomes normal
B26EF: STRG LCK RELAY OFF Inhibit engine cranking When the following conditions are fulfilled
Steering lock relay signal (CAN): ON
Steering lock unit status signal (CAN): ON
B26F0: STRG LCK RELAY ON Inhibit engine cranking When the following conditions are fulfilled
Steering lock relay signal (CAN): OFF
Steering lock unit status signal (CAN): OFF
B26F1: IGN RELAY OFF Inhibit engine cranking When the following conditions are fulfilled
Ignition switch ON signal (CAN: Transmitted from BCM): ON
Ignition switch ON signal (CAN: Transmitted from IPDM E/R): ON
B26F2: IGN RELAY ON Inhibit engine cranking When the following conditions are fulfilled
Ignition switch ON signal (CAN: Transmitted from BCM): OFF
Ignition switch ON signal (CAN: Transmitted from IPDM E/R): OFF
Display contents of CONSULT Fail-safe Cancellation
Revision: 2010 May2011 QX56

Page 444 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-56
< ECU DIAGNOSIS INFORMATION >
BCM
FAIL-SAFE CONTROL BY RAIN SENSOR MALFUNCTION
BCM detects the light and rain sensor serial link error and the rain sensor malfunction.
BCM controls the followi

BCS-56
< ECU DIAGNOSIS INFORMATION >
BCM
FAIL-SAFE CONTROL BY RAIN SENSOR MALFUNCTION
BCM detects the light and rain sensor serial link error and the rain sensor malfunction.
BCM controls the following fail-safe when rain sensor has a malfunction.
Front wiper switch AUTO and sensing rain drop: The condition just before the activation of fail-safe is main-
tained until the front wiper switch is turned OFF.
Front wiper switch AUTO and not sensing rain drop: Front wiper is LO operation until the front wiper switch is
turned off.
REAR WIPER MOTOR PROTECTION
BCM detects the rear wiper stopping position acco rding to the rear wiper stop position signal.
When the rear wiper stop position signal does not c hange for more than 5 seconds while driving the rear
wiper, BCM stops power supply to protect the rear wiper motor.
Condition of cancellation
1. More than 1 minute is passed after the rear wiper stop.
2. Turn rear wiper switch OFF.
3. Operate the rear wiper swit ch or rear washer switch.
FAIL-SAFE CONTROL OF COMBINATION SWITCH READING FUNCTION CAUSED BY LOW
POWER SUPPLY VOLTAGE
If voltage of battery power supply lower, BCM maintain s combination switch reading to the status when input
voltage is less than approximately 9 V.
NOTE:
When voltage of battery power supply is approximately 9 V or more, combination switch reading function
returns to normal operation.
DTC Inspection Priority ChartINFOID:0000000006274821
If some DTCs are displayed at the same time, perfo rm inspections one by one based on the following priority
chart.
B26F3: START CONT RLY ON Inhibit engine cranking When the following conditions are fulfilled
Starter control relay signal (CAN: Transmitted from BCM): OFF
Starter control relay signal (CAN: Transmitted from IPDM E/R): OFF
B26F4: START CONT RLY OFF Inhibit engine cranking When the following conditions are fulfilled
Starter control relay signal (CAN: Transmitted from BCM): ON
Starter control relay signal (CAN: Transmitted from IPDM E/R): ON
B26F7: BCM Inhibit engine cranking
by Intelligent Key sys-
temWhen room antenna and luggage room antenna functions normally
U0415: VEHICLE SPEED Inhibit steering lock When vehicle speed signal (Meter) (CAN) is received normally
Display contents of CONSULT Fail-safe Cancellation
Priority DTC
1 B2562: LOW VOLTAGE
2 U1000: CAN COMM
U1010: CONTROL UNIT (CAN)
3 B2192: ID DISCORD BCM-ECM
B2193: CHAIN OF BCM-ECM
B2195: ANTI-SCANNING
B2198: NATS ANTENNA AMP
Revision: 2010 May2011 QX56

Page 445 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-57
< ECU DIAGNOSIS INFORMATION >
C
D E
F
G H
I
J
K L
B A
O P
N
DTC IndexINFOID:0000000006274822
NOTE:
The details of time display are as follows.
CRNT: A malfunction is detected now.

Page 446 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-58
< ECU DIAGNOSIS INFORMATION >
BCM
CONSULT display Fail-safeFreeze Frame Data
Vehicle Speed
Odo/Trip Meter
Vehicle Condition Intelligent Key warn-
ing lamp ON Reference
page
No DTC is detec

Page 447 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS
BCM
BCS-59
< ECU DIAGNOSIS INFORMATION >
C
D E
F
G H
I
J
K L
B A
O P
N
B26E9: LOCK MALFUNCTION —
××
(Turn ON for 15 sec-
onds) SEC-106
B26EF: STRG LCK RELAY OFF
××× SEC-107
B26F0: STRG LC

Page 448 of 5598

INFINITI QX56 2011 Factory Service Manual
BCS-60
< WIRING DIAGRAM >
BCM
WIRING DIAGRAM
BCM
Wiring DiagramINFOID:0000000006274823
JCMWM8293GB
Revision: 2010 May2011 QX56
